Video Output HDMI [1..2] MonitorRole
The HDMI monitor role describes what video stream will be shown on the monitor connected to the
video output HDMI connector. Applicable only if the "Video > Monitors" configuration is set to dual.
Requires user role: ADMIN
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: Video Output HDMI 1 MonitorRole: First
Video Output HDMI [1..2] OverscanLevel
Some TVs or other monitors may not display the whole image sent out on the systems video
output, but cuts the outer parts of the image. In this case this setting can be used to let the system
not use the outer parts of video resolution. Both the video and the OSD menu will be scaled in this
case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: Video Output HDMI 1 OverscanLevel: None
Video Output HDMI [1, 2] Resolution
Select the preferred resolution for the monitor connected to the video output HDMI connector. This
will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_5
0/1280_720_60/1920_1080_50/1920_1080_60/1280_768_60/1360_768_60/1366_768_6
0/1600_1200_60/1680_1050_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with
the connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1680x1050@60p, 1920x1200@60p
Example: Video Output HDMI 1 Resolution: 1920_1080_60
D14637.08 Profile C20 and Quick Set C20 Administrator Guide TC5.1, February 2012.
Copyright © 2010-2012 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
Video Selfview
Determine if the main video source (selfview) shall be displayed on screen.
Requires user role: USER
Value space: <On/Off>
Example: Video Selfview: On
Video WallPaper
Select a background image for the video screen when idle. The background image on the Touch
controller is not changed.
Requires user role: USER
Value space: <None/Growing/Summersky/Custom/Waves>
Example: Video Wallpaper: Summersky
64
Password protection
On: Display selfview on screen.
Off: Do not display selfview on screen.
None: There will not be a background image on the screen.
Summersky, Growing, Waves: The selected background image will be shown on the screen.
Custom: If a custom wallpaper is uploaded to the codec, it will be used as background image on
the screen. If not, there will be no background image.
Use the web interface to upload a custom wallpaper to the codec.
1) On the codec: With a remote control, open the menu on screen and go to Home > Settings
> System information to find the IP address. With a Touch controller, tap More > Settings >
System Information to find the IP address.
2) On your computer: Open a web browser and enter the IP address of the codec in the
address bar. Hover the mouse over the Configuration tab and select "Wallpaper" . Browse for
the file and press the "Upload" button. The maximum supported resolution is 1920x1200.
