Cisco TelePresence System Quick Set C20 Administrator's Manual page 39

Cisco TelePresence System Quick Set C20 and Profiles using C20
Contents Introduction
Conference [1..1] Encryption Mode
Set the conference encryption mode. A padlock with the text "Encryption On" or "Encryption Off"
displays on screen for a few seconds when the conference starts.
Requires user role: ADMIN
Value space: <BestEffort/On/Off>
BestEffort: The system will use encryption whenever possible.
> In Point to point calls: If the far end system supports encryption (AES-128), the call will be
encrypted. If not, the call will proceed without encryption.
> In MultiSite calls: In order to have encrypted MultiSite conferences, all sites must support
encryption. If not, the conference will be unencrypted.
On: The system will only allow calls that are encrypted.
Off: The system will not use encryption.
Example: Conference 1 Encryption Mode: BestEffort
Conference [1..1] DefaultCall Protocol
Set the Default Call Protocol to be used when placing calls from the system.
Requires user role: ADMIN
Value space: <H323/Sip>
H.323: Select H.323 to ensure that calls are set up as H.323 calls.
Sip: Select SIP to ensure that calls are set up as SIP calls.
Example: Conference 1 DefaultCall Protocol: H323
Conference [1..1] DefaultCall Rate
Set the Default Call Rate to be used when placing calls from the system.
Requires user role: ADMIN
Value space: <64..6000>
Range: Select a value between 64 and 6000 kbps
Example: Conference 1 DefaultCall Rate: 768
Conference [1..1] MaxTransmitCallRate
Specify the maximum transmit call rate to be used when placing or receiving calls.
Requires user role: ADMIN
Value space: <64..6000>
Range: Select a value between 64 and 6000 kbps.
Example: Conference 1 MaxTransmitCallRate: 6000
D14637.08 Profile C20 and Quick Set C20 Administrator Guide TC5.1, February 2012.
Copyright © 2010-2012 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
Conference [1..1] MaxReceiveCallRate
Specify the maximum receive call rate to be used when placing or receiving calls.
Requires user role: ADMIN
Value space: <64..6000>
Example: Conference 1 MaxReceiveCallRate: 6000
Conference [1..1] VideoBandwidth Mode
Set the conference video bandwidth mode.
Requires user role: ADMIN
Value space: <Dynamic/Static>
Example: Conference 1 VideoBandwidth Mode: Dynamic
Conference [1..1] VideoBandwidth MainChannel Weight
The available transmit video bandwidth is distributed on the main channel and presentation channel
according to "MainChannel Weight" and "PresentationChannel Weight" . If the main channel
weight is 2 and the presentation channel weight is 1, then the main channel will use twice as much
bandwidth as the presentation channel.
Requires user role: ADMIN
Value space: <1..10>
Example: Conference 1 VideoBandwidth MainChannel Weight: 5
Conference [1..1] VideoBandwidth PresentationChannel Weight
The available transmit video bandwidth is distributed on the main channel and presentation channel
according to "MainChannel Weight" and "PresentationChannel Weight" . If the main channel
weight is 2 and the presentation channel weight is 1, then the main channel will use twice as much
bandwidth as the presentation channel.
Requires user role: ADMIN
Value space: <1..10>
Example: Conference 1 VideoBandwidth PresentationChannel Weight: 5
39
Password protection
Range: Select a value between 64 and 6000 kbps.
Dynamic: The available transmit bandwidth for the video channels are distributed among the
currently active channels. If there is no presentation, the main video channels will use the
bandwidth of the presentation channel.
Static: The available transmit bandwidth is assigned to each video channel, even if it is not
active.
Range: 1 to 10.
Range: 1 to 10.
Administrator guide
Appendices Contact us
