Video OSD Output
The Video OSD (On Screen Display) Output lets you define which monitor should display the on
screen menus, information and icons. By default the OSD is sent to the monitor connected to the
Video OSD Output 1. If you cannot see the OSD on screen, then you must re-configure the OSD
Output. You can do this by entering a key sequence on the remote control, from the web interface,
or by a command line interface.
Using the remote control: Press the Disconnect key followed by: * # * # 0 x # (where x is output 1
to 2).
Using the web interface: Open a web browser and enter the IP address of the codec. Open the
Advanced Configuration menu and navigate to Video OSD Output and select the video output.
Using a command line interface: Open a command line interface and connect to the codec (if in
doubt of how to do this, see the API Guide for the codec). Enter the command: xConfiguration
Video OSD Output [1..2] (select the OSD Output)
Requires user role: ADMIN
Value space: <1/2>
Range: Select 1 for HDMI output, or select 2 for DVI-I output.
Example: Video OSD Output: 1
Video OSD InputMethod InputLanguage
The codec can be enabled for Cyrillic input characters in the menus on screen. NOTE: Requires
that xConfiguration Video OSD inputMethod Cyrillic is set to On.
Requires user role: ADMIN
Value space: <Latin/Cyrillic>
Latin: Latin characters can be entered when using the remote control (default).
Cyrillic: Cyrillic characters can be entered using the remote control. NOTE: Requires a Cisco
TelePresence Remote Control with Cyrillic fonts.
Example: Video OSD InputMethod InputLanguage: Latin
Video OSD InputMethod Cyrillic
Set the Cyrillic mode for the menu input language in the menus on screen.
Requires user role: ADMIN
Value space: <On/Off>
On: Cyrillic mode is available as a menu input language in the menus on screen. This will enable
the setting xConfiguration Video OSD InputMethod InputLanguage.
Off: Cyrillic mode is NOT available as a menu input language in the menus on screen.
Example: Video OSD InputMethod Cyrillic: Off
D14637.08 Profile C20 and Quick Set C20 Administrator Guide TC5.1, February 2012.
Copyright © 2010-2012 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
Video OSD LoginRequired
Determine if the system should require the user to login before accessing the On Screen Display
(OSD). If enabled, the user must enter his username and his PIN. After the user has logged in he
can only execute to the configurations changes and commands allowed by his Role.
Requires user role: ADMIN
Value space: <On/Off>
Example: Video OSD LoginRequired: Off
Video AllowWebSnapshots
Allow or disallow that snapshots captured by the video input main source can be displayed in the
web interface Call Control page.
NOTE: This feature is disabled by default, and must be enabled from the On Screen Display (OSD),
from a directly connected Touch controller, or when connected directly to the serial port (COM 1
port) on the codec.
Requires user role: ADMIN
Value space: <On/Off>
Example: Video AllowWebSnapshots: Off
Video Output HDMI [1..2] CEC Mode
The HDMI outputs support Consumer Electronics Control (CEC). When set to on (default is off),
and the monitor connected to the HDMI output is CEC compatible and CEC is configured, the
system will use CEC to set the monitor in standby when the system enters standby. Likewise the
system will wake up the monitor when the system wakes up from standby. Please note that the
different manufacturers uses different marketing names for CEC: Anynet+ (Samsung); Aquos Link
(Sharp); BRAVIA Sync (Sony); HDMI-CEC (Hitachi); Kuro Link (Pioneer); CE-Link and Regza Link
(Toshiba); RIHD (Onkyo); SimpLink (LG); HDAVI Control, EZ-Sync, VIERA Link (Panasonic); EasyLink
(Philips); and NetCommand for HDMI (Mitsubishi).
Requires user role: ADMIN
Value space: <On/Off>
Example: Video Output HDMI 1 CEC Mode: Off
63
Password protection
On: The user must log in to access the On Screen Display (OSD).
Off: No login to the OSD is required.
On: If set to on, a web snapshot can be generated and displayed on the web interface.
Off: The generation of web snapshots is not allowed.
On: Enable CEC control.
Off: Disable CEC control.
