NetworkServices SIP Mode
Determine whether the system should be able to place and receive SIP calls or not. NOTE:
Requires a restart of the codec.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the possibility to place and receive SIP calls (default).
Off: Disable the possibility to place and receive SIP calls.
Example: NetworkServices SIP Mode: On
NetworkServices SNMP Mode
SNMP (Simple Network Management Protocol) is used in network management systems to monitor
network-attached devices (routers, servers, switches, projectors, etc) for conditions that warrant
administrative attention. SNMP exposes management data in the form of variables on the managed
systems, which describe the system configuration. These variables can then be queried (set to
ReadOnly) and sometimes set (set to ReadWrite) by managing applications.
Requires user role: ADMIN
Value space: <Off/ReadOnly/ReadWrite>
Off: Disable the SNMP network service.
ReadOnly: Enable the SNMP network service for queries only.
ReadWrite: Enable the SNMP network service for both queries and commands.
Example: NetworkServices SNMP Mode: ReadWrite
NetworkServices SNMP Host [1..3] Address
Enter the address of up to three SNMP Managers.
The system's SNMP Agent (in the codec) responds to requests from SNMP Managers (a PC
program etc.), e.g. about system location and system contact. SNMP traps are not supported.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: NetworkServices SNMP Host 1 Address: ""
NetworkServices SNMP CommunityName
Enter the name of the Network Services SNMP Community. SNMP Community names are used
to authenticate SNMP requests. SNMP requests must have a password (case sensitive) in order
to receive a response from the SNMP Agent in the codec. The default password is "public" . If
you have the Cisco TelePresence Management Suite (TMS) you must make sure the same SNMP
Community is configured there too. NOTE: The SNMP Community password is case sensitive.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: NetworkServices SNMP CommunityName: "public"
D14637.08 Profile C20 and Quick Set C20 Administrator Guide TC5.1, February 2012.
Copyright © 2010-2012 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
NetworkServices SNMP SystemContact
Enter the name of the Network Services SNMP System Contact.
Requires user role: ADMIN
Value space: <S: 0, 50>
Example: NetworkServices SNMP SystemContact: ""
NetworkServices SNMP SystemLocation
Enter the name of the Network Services SNMP System Location.
Requires user role: ADMIN
Value space: <S: 0, 50>
Example: NetworkServices SNMP SystemLocation: ""
NetworkServices SSH Mode
SSH (or Secure Shell) protocol can provide secure encrypted communication between the codec
and your local computer.
Requires user role: ADMIN
Value space: <On/Off>
Example: NetworkServices SSH Mode: On
NetworkServices SSH AllowPublicKey
Secure Shell (SSH) public key authentication can be used to access the codec.
Requires user role: ADMIN
Value space: <On/Off>
Example: NetworkServices SSH AllowPublicKey: On
NetworkServices Telnet Mode
Telnet is a network protocol used on the Internet or Local Area Network (LAN) connections.
Requires user role: ADMIN
Value space: <On/Off>
Example: NetworkServices Telnet Mode: Off
49
Password protection
Format: String with a maximum of 50 characters.
Format: String with a maximum of 50 characters.
On: The SSH protocol is enabled.
Off: The SSH protocol is disabled.
On: The SSH public key is allowed.
Off: The SSH public key is not allowed.
On: The Telnet protocol is enabled.
Off: The Telnet protocol is disabled. This is the factory setting.
