Connecting And Charging - Oral-B Triumph 9000 Manual

Description
a Oral-B ® FlossAction™ brushhead
b On/off button
c Mode button
d Handle
e SmartDisplay
f SmartPlug charger (includes charging ring and SmartPlug)
g Base plate
h Base station
i Protective cover
®
j Oral-B Pro White™ brushhead (not with all models)

Connecting and charging

Your toothbrush has a waterproof handle, is electrically safe
and is designed for use in the bathroom.
To assemble the base station (h) as a charging unit, detach
the base plate (g) first (
the base station and attach the base plate as shown (
3
, page 3). Then insert the protective cover (i) on the back of
your base station (see diagram
• Plug the SmartPlug into an electrical outlet and place the
toothbrush handle (d) on the charging unit. Alternatively,
Oral-B Triumph can be charged by placing the handle
directly into the charging ring while the SmartPlug is
plugged in.
• A battery symbol should appear in the SmartDisplay (e). The
battery symbol will fill up while the handle is being charged.
Once the handle is fully charged, the battery symbol is
completely filled with three bars. A full charge takes at least
12 hours and enables approximately two weeks of regular
brushing (twice a day, 2 minutes).
Please note: If the battery symbol is not displayed
immediately, continue charging. It will appear in 10–15
minutes.
• When the rechargeable battery is low, the battery symbol
with one remaining bar starts flashing. Your toothbrush will
slow down and then stop. It is time to recharge your tooth-
brush. When the battery is fully discharged, the empty frame
of the battery symbol flashes. It will then need a 15-minute
charge before you can use it for a 2-minute brushing.
• For everyday use, the toothbrush handle can be stored on
the charging unit to maintain it at full power. There is no risk
of overcharging the battery.
1
, page 3). Place the charging ring into
4
, page 3).
English
2
and
12 h 12 h
5
