4. Click the Applications & Gaming tab, and then click the Port Range Forwarding tab.
5. For each port range you must specify, enter a different name in the Application field. Then enter the
number or range of external port(s) used by the Phone Adapter.
6. Select the protocol you will be using, UDP.
7. Enter the IP address of the Phone Adapter. For example, if the Phone Adapter's IP address is
192.168.1.100, you would enter 100 in the field provided.
8. Repeat steps 5-7 until you have entered all four port ranges for the Phone Adapter.
Application Start and End
Internet phone 1 5060 to 5061
Internet phone 2 53 to 53
Internet phone 3 69 to 69
Internet phone 4 10000 to 20000
9. Check the Enable option for the port services you want to use.
10. When you have completed the configuration, click the Save Settings button.
Appendix A: Troubleshooting
Common Problems and Solutions
Protocol IP Address
UDP (IP address of
Phone Adapter)
UDP (IP address of
Phone Adapter)
UDP (IP address of
Phone Adapter)
UDP (IP address of
Phone Adapter)
Phone Adapter with 2 Ports for Voice-over-IP
Enable
X
X
X
X
