The Administration Tab - Log

On the Log screen, you can select which PC will receive the specified type of activity logs.
NOTE: The PC that receives these logs must be running a SYSLOG application. Linksys offers free
software that can view system logs. You can download Logviewer software at www.linksys.com.
Log
Log Level. There are a variety of log levels available, from most urgent to least urgent. Select the appropriate
level: Panic, Alert, Critical, Error, Warning, Notice, Info, or Debug, from the drop-down menu.
Add an IP Address. In this field, enter the fixed IP address of the PC that will receive the logs. Then click the
Add button. The Phone Adapter will now send updated logs to that PC.
Select a logging destination. If you add an IP address, then that IP address automatically becomes the logging
destination. If you want to delete a destination, then select it and click the Delete button.
When you have finished making changes to this screen, click the Save Settings button to save the changes, or
click the Cancel Changes button to undo your changes.
Chapter 5: Using the Phone Adapter's Web-based Utility
The Administration Tab - Log
Phone Adapter with 2 Ports for Voice-over-IP

Figure 5-5: Administration Tab - Log

21
