Table 3-3 Telnet Commands and Parameters (continued)
get-cmnty-name
set-cmnty-name
default-get-cmnty
SNMP Traps
auth-trap
trap-dest
IPX/SPX
ipx-config
ipx-unitname
Address
ENWW
CAUTION Disabling SNMP will disable all SNMP agents (SNMP v1, v2, v3)
as well as communications with management applications, such as HP Web
Jetadmin. In addition, firmware upgrades through current HP downloading
utilities will be disabled.
Specifies a password that determines which SNMP GetRequests the HP Jetdirect print
server will respond to. This is optional. If a user-specified get community name is set,
the print server will respond to either a user-specified community name or the factory-
default. The community name must be ASCII characters. The maximum length is 255
characters.
Specifies a password that determines which SNMP SetRequests (control functions) the
HP Jetdirect print server will respond to. The community name of an incoming SNMP
SetRequest must match the print server's "set community name" for the print server to
respond. (For additional security, you may limit configuration access through the print
server's host access list.) Community names must be ASCII characters. The maximum
length is 255 characters.
Enables or disables the default Get community name.
0 disables, 1 (default) enables.
Disabling this parameter may prohibit communications with SNMP management
applications.
Configures the print server to send (on) or not send (off) SNMP authentication traps.
Authentication traps indicate that an SNMP request was received, but the community
name check failed. 0 is off, 1 (default) is on.
Enters a host IP address into the HP Jetdirect print server's SNMP trap destination list.
The command format is:
trap-dest: ip-address [community name] [port number]
The default community name is 'public'; the default SNMP port number is '162'. The
port number cannot be specified without a community name.
To delete the table, use 'trap-dest: 0'.
If the list is empty, the print server does not send SNMP traps. The list may contain up
to three entries. The default SNMP Trap Destination List is empty. To receive SNMP
traps, the systems listed on the SNMP trap destination list must have a trap daemon to
listen to those traps.
Enables or disables IPX/SPX protocol operation on the print server. 0 disables, 1
(default) enables. For example,
ipx-config 0 will disable IPX/SPX operation.
(Print Server Name) A user-assigned alphanumeric name assigned to the print server
(31 characters maximum). By default, the name will be NPIxxxxxx, where xxxxxx are
the last six digits of the LAN hardware address.
(Read-only parameter) Identifies the IPX network and node numbers detected on the
network, in the form NNNNNNNN:hhhhhhhh (hexadecimal), where NNNNNNNN is the
network number and hhhhhhhh is the LAN hardware address of the print server.
