User Manual for the NETGEAR 7200 Series Layer 2 Managed Switch Software
Transmit Discards
Protocol Statistics
Switching Commands
Underrun Errors - The total number of frames discarded
because the transmit FIFO buffer became empty during frame
transmission.
Total Discards - The sum of single collision frames discarded,
multiple collision frames discarded, and excessive frames dis-
carded.
Single Collision Frames - A count of the number of successfully
transmitted frames on a particular interface for which transmis-
sion is inhibited by exactly one collision.
Multiple Collision Frames - A count of the number of success-
fully transmitted frames on a particular interface for which trans-
mission is inhibited by more than one collision.
Excessive Collisions - A count of frames for which transmission
on a particular interface fails due to excessive collisions.
Port Membership - The number of frames discarded on egress
for this port due to egress filtering being enabled.
VLAN Viable Discards - The number of frames discarded on
this port when a lookup on a particular VLAN occurs while that
entry in the VLAN table is being modified, or if the VLAN has
not been configured.
BPDU's received - The count of BPDU's (Bridge Protocol Data
Units) received in the spanning tree layer.
BPDU's Transmitted - The count of BPDU's (Bridge Protocol
Data Units) transmitted from the spanning tree layer.
802.3x Pause Frames Received - A count of MAC Control
frames received on this interface with an opcode indicating the
PAUSE operation. This counter does not increment when the
interface is operating in half-duplex mode.
GVRP PDU's Received - The count of GVRP PDU's received in
the GARP layer.
GVRP PDU's Transmitted - The count of GVRP PDU's trans-
mitted from the GARP layer.
GVRP Failed Registrations - The number of times attempted
GVRP registrations could not be completed.
GMRP PDU's received - The count of GMRP PDU's received in
the GARP layer.
