- Page 1 INSTRUCTION MANUAL Cordless Mixer UT001G UT002G Read before use.
-
Page 2: Specifications
Read instruction manual. The typical A-weighted noise level determined accord- ing to EN62841-2-10: Do not use the tool in the rain. Model UT001G Sound pressure level (L ) : 81 dB (A) Sound power level (L ) : 92 dB (A) Do not clean the tool with water. -
Page 3: Ec Declaration Of Conformity
The vibration total value (tri-axial vector sum) deter- Work area safety mined according to EN62841-2-10: Keep work area clean and well lit. Cluttered or Model UT001G dark areas invite accidents. Work mode: operation without load Do not operate power tools in explosive atmo- Vibration emission (a ) : 2.5 m/s... - Page 4 Personal safety Power tool use and care Stay alert, watch what you are doing and use Do not force the power tool. Use the correct common sense when operating a power tool. power tool for your application. The correct Do not use a power tool while you are tired or power tool will do the job better and safer at the under the influence of drugs, alcohol or med- rate for which it was designed.
- Page 5 Do not use a battery pack or tool that is dam- 12. Hold the tool firmly. aged or modified. Damaged or modified batteries 13. Keep hands away from rotating parts. may exhibit unpredictable behaviour resulting in 14. Do not leave the tool running. Operate the tool fire, explosion or risk of injury.
-
Page 6: Parts Description
Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting Switch trigger Lock-off button causing fires, personal injury and damage. It will Lock button Speed adjusting dial also void the Makita warranty for the Makita tool and Speed change knob Battery cover charger. Handle Chuck Tips for maintaining maximum... -
Page 7: Preparation Before Use
Things you need to know before use PREPARATION BEFORE USE Hold the handle when using or carrying the tool. Indicating the remaining battery capacity Press the check button on the battery cartridge to indi- cate the remaining battery capacity. The indicator lamps light up for a few seconds. -
Page 8: How To Use
Insert the shaft into the chuck as far as it will go. Fig.5 Assembly Installing the shaft Optional accessory For UT001G Tighten the shaft into the shaft holder. Fig.8 ► 1 . Shaft 2. Chuck Tighten the chuck by hand, and then place the chuck key in each of three holes and tighten it clock- wise. -
Page 9: Installing Or Removing Battery Cartridge
Fig.12 ► 1 . Hex bolt 2. Shaft 3. Flat surface 4. Mixing blade NOTE: Ask your local Makita Service Center about which is mixing blades are allowed. 9 ENGLISH... - Page 10 NEVER use the tool if it runs when you simply pull the switch trigger without pressing the lock-off button. A switch in need of repair may result in unintentional operation and serious personal injury. Return tool to a Makita service center for proper repairs BEFORE further usage. Fig.16 WARNING: Do not install the battery cartridge ► 1 .
-
Page 11: Basic Operations
Operation of speed adjusting dial Basic operations The tool speed can be adjusted steplessly by turning CAUTION: Do not mix flammable materials or the speed adjusting dial. The no load speed when the operate the tool around flammable materials such switch trigger is fully pulled can be adjusted 270 min as paint with thinner used as solvent. Failure to do to 500 min at low speed mode, 500 min to 920 min so may cause an injury. - Page 12 Loosen the screw securing the standard equipped country specific battery cover. Then remove the screw, sleeve and the battery cover. For UT001G Install one of the shaft holders optionally available to fit your screw size of the shaft. Fig.19 ► 1 . Screw 2. Sleeve 3. Battery cover (standard equipped) Fig.21...
-
Page 13: Optional Accessories
ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 16 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885997-228 www.makita.com 20220802...
