  • Page 1 Akku-Hochentaster BETRIEBSANLEITUNG Elettrosega telescopica a ISTRUZIONI PER L’USO batteria Accustoksnoeizaag GEBRUIKSAANWIJZING Sierra de Extensión MANUAL DE Inalámbrica INSTRUCCIONES Motopoda a Bateria MANUAL DE INSTRUÇÕES Akku stangsav BRUGSANVISNING Φορητό κονταροπρίονο ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ Akülü Yüksek Dal Budama KULLANMA KILAVUZU Testeresi UA003G...
  • Page 2 Fig.1 Fig.3 Fig.2 Fig.4...
  • Page 3 Fig.5 Fig.9 Fig.6 Fig.10 Fig.7 Fig.11 Fig.8 Fig.12...
  • Page 4 Fig.16 Fig.13 Fig.17 Fig.14 Fig.18 Fig.15...
  • Page 5 Fig.21 Fig.19 Fig.22 Fig.20...
  • Page 6 Fig.27 Fig.23 Fig.28 Fig.24 Fig.29 Fig.25 Fig.30 Fig.26...
  • Page 7 Fig.31 Fig.35 Fig.32 Fig.36 Fig.33 Fig.37 Fig.34...
  • Page 8 Fig.42 Fig.38 Fig.43 Fig.39 Fig.44 Fig.40 Fig.45 Fig.41...
  • Page 9 Fig.46 Fig.47 Fig.48...

  • Page 10: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model: UA003G Overall length 2,230 mm (without guide bar, battery, and attachment) Rated voltage D.C. 36 V - 40 V max Net weight 6.1 kg 6.1 - 7.8 kg Standard guide bar length 300 mm Recommended guide bar...

  • Page 11: Intended Use

    Saw chain, guide bar, and sprocket combination Saw chain type 90PX Number of drive links Guide bar Guide bar length 300 mm Cutting length 296 mm Pitch 3/8″ Gauge 1.1 mm Type Sprocket nose bar Sprocket Number of teeth Pitch 3/8″...

  • Page 12: Safety Warnings

    Noise WARNING: Wear ear protection. WARNING: The noise emission during actual The typical A-weighted noise level determined accord- use of the power tool can differ from the declared ing to ISO22868(ISO11680-1): value(s) depending on the ways in which the Sound pressure level (L ) : 90 dB (A) tool is used especially what kind of workpiece is Sound power level (L...
  • Page 13 Before assembling or adjusting the tool, switch condition before continuing work. If there is off the tool and remove the battery cartridge. any damage or doubt, ask Makita authorized Before handling the saw chain or adjusting the service center for the inspection and repair.
  • Page 14 Move all tools and goods from work. the escape area to another safe place. Always use Makita genuine spare parts and 20. Before cutting branches and limbs, check accessories only. Using parts or accessories the falling direction of them, considering the...

  • Page 15: Parts Description

    Do not use a damaged battery. also void the Makita warranty for the Makita tool and 10. The contained lithium-ion batteries are subject charger. to the Dangerous Goods Legislation require- ments.

  • Page 16: Functional Description

    Let the machine and battery(ies) cool down. 50% to 75% If no improvement can be found by restoring protection 25% to 50% system, then contact your local Makita Service Center. Main power switch 0% to 25% WARNING: Always turn off the main power Charge the battery.

  • Page 17: Adjusting Saw Chain Tension

    Installing the saw chain NOTE: The main power lamp blinks in green when you turn on the main power switch while holding down To install the saw chain, perform the following steps: the lock-off lever and pulling the switch trigger. In this Loosen the chain adjusting screw, then the retain- case, release the switch trigger and the lock-off lever, ing nut. and then turn on the main power switch. ► Fig.6: 1.

  • Page 18: Operation

    NOTICE: Make sure that the saw chain does not loose at the Use the saw chain oil exclusively for Makita lower side. chain saws or equivalent oil available in the market. Tighten the retaining nut to secure the sprocket...

  • Page 19: Maintenance

    To maintain product SAFETY and RELIABILITY, If you try to cut off thick branches from the top without a repairs, any other maintenance or adjustment should shallow undercut, the branch may splinter. be performed by Makita Authorized or Factory Service ► Fig.32 Centers, always using Makita replacement parts. 19 ENGLISH...

  • Page 20: Replacing The Sprocket

    If the sprocket is worn or damaged, ask — Sharpen the shortest cutter first. Then the length Makita Authorized Service Centers for replacement. of this shortest cutter becomes the standard for all ► Fig.48: 1. Sprocket 2. Areas to be worn out other cutters on the saw chain.

  • Page 21: Storing The Tool

    Storing the tool Clean the tool before storing. Remove any chips and sawdust from the tool after removing the sprocket cover. After cleaning the tool, run it under no load to lubri- cate the saw chain and guide bar. Cover the guide bar with the guide bar cover. Empty the oil tank.

  • Page 22: Troubleshooting

    TROUBLESHOOTING Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to dismantle the tool. Instead, ask Makita Authorized Service Centers, always using Makita replace- ment parts for repairs. Malfunction status Cause Action The tool does not start. Battery cartridge is not installed. Install a charged battery cartridge.
