- Page 1 INSTRUCTION MANUAL Cordless Telescopic Pole Saw UA004G Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: UA004G Overall length 2,516 - 3,748 mm (without guide bar and battery) Rated voltage D.C. 36 V - 40 V max Net weight 7.8 kg 7.8 - 8.5 kg Standard guide bar length 300 mm Recommended guide bar... -
Page 3: Intended Use
Saw chain type 91PX Number of drive links Guide bar Guide bar length 300 mm Cutting length 296 mm Pitch 3/8″ Gauge 1.3 mm Type Sprocket nose bar Sprocket Number of teeth Pitch 3/8″ WARNING: Use appropriate combination of the guide bar and saw chain. Otherwise personal injury may result. Guaranteed sound power level according Symbols to EU Outdoor Noise Directive. - Page 4 Do not expose power tools to rain or wet con- ditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
- Page 5 Battery tool use and care Do not use the tool in bad weather conditions, especially when there is a risk of lightning. Recharge only with the charger specified by This decreases the risk of being struck by the manufacturer. A charger that is suitable for lightning.
- Page 6 If the tension is loose, tighten it. condition before continuing work. If there is 28. When you use the tool on muddy ground, wet any damage or doubt, ask Makita authorized slope, or slippery place, pay attention to your service center for the inspection and repair.
- Page 7 If operating time has become excessively has become blunt and cutting performance is shorter, stop operating immediately. It may poor, ask Makita authorized service center to result in a risk of overheating, possible burns sharpen it or replace it with new one.
-
Page 8: Parts Description
Charge the battery cartridge if you do not use also void the Makita warranty for the Makita tool and it for a long period (more than six months). charger. PARTS DESCRIPTION Fig.1... -
