6 Reference information
20
Physical data
Internal volume
Pos 1 LOAD
Port 1–7
Port 2–3
Port 4–6
Pos 2 INJECT
Port 1–2
Port 3–5
Port 6–7
Pos 3 WASH
Port 2–4
Port 5–7
Flow channel diameter
Valve principle
Functions
Degree of protection
Wetted materials
Chemical resistance
Power requirement
Power consumption
UniNet 2 address
Inlet and outlet tubing
Dimensions,
H × W × D
Weight
EMC Standards
9 μl
5 μl
8 μl
7 μl
6 μl
9 μl
8 μl
9 μl
0.8 mm
Motor controlled valve
Switching 3 positions controlled
from UNICORN
IP 43
PEEK (polyetheretherketone)
The wetted parts are resistant to organic
solvents and salt buffers commonly used
in chromatography of biomolecules, except
100% ethylacetate, 100% hexane and
100% tetrahydrofuran (THF)
32 V DC ±10% from the system pump
Up to 9 W
0–9
UNF 10–32 2B "Fingertights" for capillary
tubing 1/16" outer diameter
135 × 80 × 120 mm
1.2 kg
This device meets the requirement of the
EMC Directive 89/336/EEC through the
following harmonized standards:
•
EN 61326 (emission and immunity)
•
EN 55011, GR 2, Class A (emission)
•
This device complies with part 15 of
the FCC rules (emission). Operation is
subject to the following two conditions:
1
The device may not cause harmful
interference.
2
This device must accept any
interference recieved, including
interference that may cause
undesired operation.
Valve INV-907 Instructions 56-8101-01 Edition AE
