APPENDIX A - HANDHELD INTERROGATOR
The following message is displayed while the calibration operation is being performed:
If the calibration is successful, the following message is displayed for a period of three seconds:
Force mA
This option allows the system s analogue output signal to be adjusted to a fixed level, e.g. when
setting up a system controller. The following message is displayed:
where:
mmmmm
This is adjusted using the
After adjustment the output is forced to the set level and the following message is displayed:
where:
mmmmm
Normal mA
This menu option returns the system to its normal analogue output state, irrespective of its
previous state. If successful, the following message is displayed for three seconds:
Show Status
This menu option displays the calibration and configuration status of the system. The status
information is displayed in the following format:
where: cccccccc... Title of the calibration status field.
sssssssss
The different settings from the list are selected using the
Processing Data
Please Wait...
Zero Calibrated
O/P current mA
Current to output.
and keys over the range 1mA to 21mA in steps of 0.1mA.
Fixed:
Analogue output current previously set.
4-20mA Released
cccccccccccccccc
Current state of calibration.
mmmmm
mmmmm mA
Press Enter
ssssssss
112
and keys on the keypad.
