Cisco TelePresence SX20 Codec
Contents
Introduction
xConfiguration Video OSD InputMethod Cyrillic
Set the Cyrillic mode for the menu input language in the menus on screen.
Requires user role: ADMIN
Value space: <Off/On>
Off: Cyrillic mode is NOT available as a menu input language in the menus on screen.
On: Cyrillic mode is available as a menu input language in the menus on screen. This will enable
the setting Video OSD InputMethod InputLanguage.
Example: xConfiguration Video OSD InputMethod Cyrillic: Off
xConfiguration Video OSD LoginRequired
Determine if the system should require the user to login before accessing the On Screen Display
(OSD). If enabled, the user must enter his username and his PIN. After the user has logged in he can
only execute to the configurations changes and commands allowed by his Role.
Requires user role: ADMIN
Value space: <Off/On>
Off: No login to the OSD is required.
On: The user must log in to access the On Screen Display (OSD).
Example: xConfiguration Video OSD LoginRequired: Off
xConfiguration Video AllowWebSnapshots
Allow or disallow snapshots being taken of the local input sources, remote sites and presentation
channel. If allowed, the web interface Call Control page will show snapshots both when idle and in
a call.
NOTE: This feature is disabled by default, and must be enabled from the On Screen Display (OSD),
from a directly connected Touch controller, or via the codec's serial port (USB port and RS-232
adapter).
Requires user role: ADMIN
Value space: <Off/On>
Off: Capturing web snapshots is not allowed.
On: Web snapshots can be captured and displayed on the web interface.
Example: xConfiguration Video AllowWebSnapshots: Off
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API
xConfiguration
xConfiguration
xConfiguration Video Output HDMI [1,2] RGBQuantizationRange
xConfiguration Video Output HDMI [1,2] CEC Mode
71
xCommand
All devices with HDMI outputs should follow the rules for RGB video quantization range defined in
CEA-861. Unfortunately some devices do not follow the standard and this configuration may be
used to override the settings to get a perfect image with any display. The default value is set to Full
because most HDMI displays expects full quantization range.
Requires user role: ADMIN
Value space: <Auto/Full/Limited>
Auto: RGB quantization range is automatically selected based on the RGB Quantization Range bits
(Q0, Q1) in the AVI infoframe. If no AVI infoframe is available, RGB quantization range is selected
based on video format according to CEA-861-E.
Full: Full quantization range. The R, G, B quantization range includes all code values (0 - 255). This
is defined in CEA-861-E.
Limited: Limited Quantization Range. R, G, B quantization range that excludes some code values at
the extremes (16 - 235). This is defined in CEA-861-E.
Example: xConfiguration Video Output HDMI 1 RGBQuantizationRange: Full
The HDMI outputs support Consumer Electronics Control (CEC). When set to on (default is off), and
the monitor connected to the HDMI output is CEC compatible and CEC is configured, the system
will use CEC to set the monitor in standby when the system enters standby. Likewise the system
will wake up the monitor when the system wakes up from standby. Please note that the different
manufacturers uses different marketing names for CEC, for example Anynet+ (Samsung); Aquos
Link (Sharp); BRAVIA Sync (Sony); HDMI-CEC (Hitachi); Kuro Link (Pioneer); CE-Link and Regza Link
(Toshiba); RIHD (Onkyo); HDAVI Control, EZ-Sync, VIERA Link (Panasonic); EasyLink (Philips); and
NetCommand for HDMI (Mitsubishi).
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable CEC control.
On: Enable CEC control.
Example: xConfiguration Video Output HDMI 1 CEC Mode: Off
API Reference Guide
xStatus
Appendices
Copyright © 2013 Cisco Systems, Inc. All rights reserved.
