Contents Introduction
Configurations that are removed
xConfiguration Network Assignment
Replaced by xConfiguration Network IPv4 Assignment
Configurations that are modified
xConfiguration Network IPStack
OLD: <IPv4/IPv6>
NEW: <Dual/IPv4/IPv6>
xConfiguration Video MainVideoSource
OLD: <1/2>
NEW: <1/2/3>

xCommand changes

Commands that are modified
xCommand Message FarendMessage
OLD: CallId was required
NEW: CallId is optional
xCommand Phonebook Search
ADDED: ContactType: <Any/Folder/Contact>
xStatus changes
New status
xStatus Conference Site Hold
xStatus Conference Site Preserved
xStatus ICE Configured
xStatus ICE Defaultcandidate
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration
xStatus ICE Turn IP
xStatus ICE Turn Hostname
xStatus ICE Turn Username
xStatus ICE Call Result
xStatus ICE Call Local Candidate
xStatus ICE Call Local IP
xStatus ICE Call Remote Candidate
xStatus ICE Call Remote IP
xStatus SIP Profile Turn ServerAddress
xStatus SIP Profile 1 DirectoryURI Primary URI
xStatus SIP Profile 1 DirectoryURI Alias URI
xStatus Video Layout Mode
xStatus Video Input Source [1..n] MediaChannelId
xStatus Video Input Source 3 Resolution Height
xStatus Video Input Source 3 Resolution Width
xStatus Video Input Source 3 Resolution RefreshRate
xStatus Video Input Source 3 Resolution FormatType
xStatus Video Input Source 3 Resolution FormatStatus
xStatus Video Input USB 3 Connected
xStatus Video Input USB 3 SignalState
Status that is modified
xStatus Call Status
OLD: <Idle/Dialling/Ringing/Connecting/Connected/
Disconnecting/OnHold>
NEW: <Idle/Dialling/Ringing/Connecting/Connected/
Disconnecting/OnHold/EarlyMedia/Preserved/
RemotePreserved>
7
xCommand xStatus
xStatus H320 Gateway Status
OLD: <OK/OKWithWarning/Error/Inactive>
NEW: <OK/OKWithWarning/Error/Inactive/Warning>
xStatus SystemUnit Diagnostics Message Type
OLD: <ValidAdminPassword/CamerasDetected/
H320GatewayStatus/ISDNLinkCompatibility/
SIPProfileRegistration/SIPListenPortAndOutboundMode/
TLSVerifyRequiredCerts/DefaultCallProtocolRegistered/
NetSpeedAutoNegotiated/HasValidReleaseKey/
EthernetDuplexMatches/IPv4Assignment/
IPv6Assignment>
NEW: <ValidAdminPassword/CamerasDetected/
H320GatewayStatus/ISDNLinkCompatibility/
SIPProfileRegistration/SIPListenPortAndOutboundMode/
TLSVerifyRequiredCerts/DefaultCallProtocolRegistered/
NetSpeedAutoNegotiated/HasValidReleaseKey/
EthernetDuplexMatches/IPv4Assignment/
IPv6Assignment/SIPProfileType/
CallProtocolIPStackPlatformCompatability/
CameraStatus/CameraPairing/CameraSoftwareVersion/
SelectedVideoInputSourceConnected/OSDVideoOutput/
VideoFromInternalCamera/H323GatekeeperStatus>
xStatus MediaChannels Call IncomingVideoChannel Video
Protocol
OLD: <Off/Raw/H261/H263/H263p/H263pp/H264/MP4V/
JPEG>
NEW: <Off/Raw/H261/H263/H263p/H263pp/H264/MP4V/
JPEG/HEVC>
xStatus MediaChannels Call OutgoingVideoChannel Video
Protocol
OLD: <Off/Raw/H261/H263/H263p/H263pp/H264/MP4V/
JPEG>
NEW: <Off/Raw/H261/H263/H263p/H263pp/H264/MP4V/
JPEG/HEVC>
