Starting a Menu Directed Inspection

1
– Select to begin the MDI process.
2
– Select any loaded inspection.
3
– Select to browse for and Resume a previously active inspection.
4
– Resume the Last active inspection.
5
– Indicates a newly loaded inspection.
6
– Indicates the last active inspection.

Entering Study Level Information

At the start of an MDI inspection, you are prompted to enter the study level information
and to select the directory (folder) into which your inspection results will be saved.
7
– Study Level Information (varies for each MDI) is entered at the start of an inspection.
Information marked * is required before collecting results.
8
– To enter information, simply choose the corresponding line and the Virtual Keyboard
will automatically launch.
9
– Use the keyboard to enter information or choose from a user-generated set of
Preset entries.
10
– Select when finished entering all Study Level Information.
11
– You must then identify the Folder (directory) into which results acquired during the
MDI process are saved. Either Create a New Folder or choose an existing one.
12
– Select to complete the information input process.
