3.3 L90 CHANNEL COMMUNICATION

3.3 L90 CHANNEL COMMUNICATION
The L90 relay requires a special communications module which is plugged into slot "W" for UR-Horizontal or slot "R" for
UR-Vertical. This module is available in several varieties. Relay to relay channel communication is not the same as the
10Base-F interface (available as an option with the CPU module). Channel communication is used for sharing data among
relays.
Table 3–5: CHANNEL COMMUNICATION OPTIONS
MODULE
SPECIFICATION
TYPE
7A
820 nm, multi-mode, LED, 1 Channel
7B
1300 nm, multi-mode, LED, 1 Channel
7C
1300 nm, single-mode, ELED, 1 Channel
3
7D
1300 nm, single-mode, LASER, 1 Channel
7E
Channel 1: G.703; Channel 2: 820 nm, multi-mode, LED
7F
Channel 1: G.703; Channel 2: 1300 nm, multi-mode, LED
7G
Channel 1: G.703; Channel 2: 1300 nm, single-mode, ELED
7Q
Channel 1: G.703; Channel 2: 1300 nm, single-mode, LASER
7H
820 nm, multi-mode, LED, 2 Channels
7I
1300 nm, multi-mode, LED, 2 Channels
7J
1300 nm, single-mode, ELED, 2 Channels
7K
1300 nm, single-mode, LASER, 2 Channels
7L
Ch 1 - RS422, Ch 2 - 820 nm, multi-mode, LED
7M
Ch 1 - RS422, Ch 2 - 1300 nm, multi-mode, LED
7N
Ch 1 - RS422, Ch 2 - 1300 nm, single-mode, ELED
7P
Ch 1 - RS422, Ch 2 - 1300 nm, single-mode, LASER
7R
G.703, 1 Channel
7S
G.703, 2 Channels
7T
RS422, 1 Channel
7W
RS422, 2 Channels
72
1550 nm, single-mode, LASER, 1 Channel
73
1550 nm, single-mode, LASER, 2 Channel
74
Channel 1 - RS422; Channel 2 - 1550 nm, single-mode, LASER
75
Channel 1 - G.703; Channel 2 - 1550 nm, single-mode, LASER
The above table shows the various Channel Communication interfaces available for the L90 relay. All of the fiber modules
use ST type connectors. For 2-Terminal applications, each L90 relay requires at least one communications channel.
The L90 Current Differential Function must be "Enabled" for the Communications Module to work. Refer to
ÖØ
SETTINGS
NOTE
OBSERVING ANY FIBER TRANSMITTER OUTPUT MAY CAUSE INJURY TO THE EYE.
CAUTION
3-20
Ö
CONTROL ELEMENTS
LINE DIFFERENTIAL
L90 Line Differential Relay
Ö
menu.
CURRENT DIFFERENTIAL
3 HARDWARE

3.3.1 DESCRIPTION

GE Power Management
