6.2 STATUS
PATH: ACTUAL VALUES
„

DIRECT INPUTS

„
The present state of the Direct Inputs from communications channels 1 and 2 are shown here. The state displayed will be
that of the remote point unless channel 1 or 2 has been declared to have "failed", in which case the value shown is the pro-
grammed default state defined in the
PATH: ACTUAL VALUES
„

CONTACT OUTPUTS

„
6
The present state of the contact outputs is shown here.
The first line of a message display indicates the ID of the contact output. For example, 'Cont Op 1' refers to the contact out-
put in terms of the default name-array index. The second line of the display indicates the logic state of the contact output.
For Form-A outputs, the state of the voltage(V) and/or current(I) detectors will show as: Off, VOff, IOff, On,
VOn, and/or IOn. For Form-C outputs, the state will show as Off or On.
NOTE
PATH: ACTUAL VALUES
„

VIRTUAL OUTPUTS

„
The present state of up to 64 virtual outputs is shown here. The first line of a message display indicates the ID of the virtual
output. For example, 'Virt Op 1' refers to the virtual output in terms of the default name-array index. The second line of the
display indicates the logic state of the virtual output, as calculated by the FlexLogic™ equation for that output.
6-4
Ø ÖØ
STATUS DIRECT INPUTS
DIRECT INPUT 1-1:
Off
DIRECT INPUT 1-8:
MESSAGE
Off
DIRECT INPUT 2-1:
MESSAGE
Off
DIRECT INPUT 2-8:
MESSAGE
Off
ÖØ
SETTINGS
Ö ÖØ
STATUS CONTACT OUTPUTS
Cont Op 1
Off
Cont Op xx
MESSAGE
Off
Ö ÖØ
STATUS VIRTUAL OUTPUTS
Virt Op 1
Off
Virt Op 64
MESSAGE
Off
L90 Line Differential Relay
Range: On, Off
↓
↓
Range: On, Off
Range: On, Off
↓
↓
Range: On, Off
ÖØ Ö
INPUTS/OUTPUTS DIRECT
↓
↓
6 ACTUAL VALUES
6.2.4 DIRECT INPUTS
menu.
DIRECT INPUTS
6.2.5 CONTACT OUTPUTS
6.2.6 VIRTUAL OUTPUTS
