5 SETTINGS
b) GROUND DISTANCE (GROUND DISTANCE OVERCURRENT: ANSI 21G)
ÖØ
PATH: SETTINGS GROUPED ELEMENTS
„
GROUND DISTANCE Z2
„
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
MESSAGE
GE Power Management
Ö ÖØ
SETTING GROUP 1(8) DISTANCE
GND DIST Z2
FUNCTION: Disabled
GND DIST Z2
DIRECTION: Forward
GND DIST Z2
SHAPE: Mho
GND DIST Z2
Z0/Z1 MAG: 2.70
GND DIST Z2
Z0/Z1 ANG: 0°
GND DIST Z1
ZOM/Z1 MAG: 0.00
GND DIST Z1
ZOM/Z1 ANG: 0°
GND DIST Z2
REACH: 2.00 Ω
GND DIST Z2
RCA: 85°
GND DIST Z2
COMP LIMIT: 90°
GND DIST Z2
DIR RCA: 85°
GND DIST Z2
DIR COMP LIMIT: 90°
GND DIST Z2 QUAD
RGT BLD: 10.00 Ω
GND DIST Z2 QUAD
RGT BLD RCA: 85°
GND DIST Z2 QUAD
LFT BLD: 10.00 Ω
GND DIST Z2 QUAD
LFT BLD RCA: 85°
GND DIST Z2
SUPV: 0.200 pu
GND DIST Z2 VOLT
LEVEL: 0.000 pu
GND DIST Z2
DELAY:0.000 s
GND DIST Z2 BLK:
Off
GND DIST Z2
TARGET: Self-Reset
L90 Line Differential Relay
5.5 GROUPED ELEMENTS
ÖØ
GROUND DISTANCE Z2
Range: Disabled, Enabled
Range: Forward, Reverse
Range: Mho, Quad
Range: 0.50 to 7.00 in steps of 0.01
Range: –90 to 90° in steps of 1
Range: 0.00 to 7.00 in steps of 0.01
Range: –90 to 90° in steps of 1
Range: 0.02 to 250.00 Ω in steps of 0.01
Range: 30 to 90° in steps of 1
Range: 30 to 90° in steps of 1
Range: 30 to 90° in steps of 1
Range: 30 to 90° in steps of 1
Range: 0.02 to 500.00 Ω in steps of 0.01
Range: 60 to 90° in steps of 1
Range: 0.02 to 500.00 Ω in steps of 0.01
Range: 60 to 90° in steps of 1
Range: 0.050 to 30.000 pu in steps of 0.001
Range: 0.000 to 5.000 pu in steps of 0.001
Range: 0.000 to 65.535 s in steps of 0.001
Range: FlexLogic™ operand
Range: Self-Rest, Latched, Disabled
