A.1 PARAMETER LIST
Table A–1: FLEXANALOG PARAMETERS (Sheet 4 of 4)
A
SETTING
DISPLAY TEXT
9350
Terminal 1 IA Mag
9352
Terminal 1 IB Mag
9354
Terminal 1 IC Mag
9356
Terminal 2 IA Mag
9358
Terminal 2 IB Mag
9360
Terminal 2 IC Mag
9362
Diff Curr IA Mag
9364
Diff Curr IB Mag
9366
Diff Curr IC Mag
9368
Local IA Angle
9369
Local IB Angle
9370
Local IC Angle
9371
Terminal 1 IA Angle
9372
Terminal 1 IB Angle
9373
Terminal 1 IC Angle
9374
Terminal 2 IA Angle
9375
Terminal 2 IB Angle
9376
Terminal 2 IC Angle
9377
Diff Curr IA Angle
9378
Diff Curr IB Angle
9379
Diff Curr IC Angle
9380
Op Square Curr IA
9382
Op Square Curr IB
9384
Op Square Curr IC
9386
Rest Square Curr IA
9388
Rest Square Curr IB
9390
Rest Square Curr IC
32768
Tracking Frequency
39425
FlexElement 1 OpSig
39427
FlexElement 2 OpSig
39429
FlexElement 3 OpSig
39431
FlexElement 4 OpSig
39433
FlexElement 5 OpSig
39435
FlexElement 6 OpSig
39437
FlexElement 7 OpSig
39439
FlexElement 8 OpSig
39441
FlexElement 9 OpSig
39443
FlexElement 10 OpSig
39445
FlexElement 11 OpSig
39447
FlexElement 12 OpSig
39449
FlexElement 13 OpSig
39451
FlexElement 14 OpSig
39453
FlexElement 15 OpSig
39455
FlexElement 16 OpSig
40960
Communications Group
40971
Active Setting Group
A-4
DESCRIPTION
Remote1 IA Magnitude (A)
Remote1 IB Magnitude (A)
Remote1 IC Magnitude (A)
Remote2 IA Magnitude (A)
Remote2 IB Magnitude (A)
Remote2 IC Magnitude (A)
Differential Current IA Magnitude (A)
Differential Current IB Magnitude (A)
Differential Current IC Magnitude (A)
Local IA Angle (°)
Local IB Angle (°)
Local IC Angle (°)
Remote1 IA Angle (°)
Remote1 IB Angle (°)
Remote1 IC Angle (°)
Remote2 IA Angle (°)
Remote2 IB Angle (°)
Remote2 IC Angle (°)
Differential Current IA Angle (°)
Differential Current IB Angle (°)
Differential Current IC Angle (°)
Op Square Current IA ()
Op Square Current IB ()
Op Square Current IC ()
Restraint Square Current IA ()
Restraint Square Current IB ()
Restraint Square Current IC ()
Tracking Frequency (Hz)
FlexElement 1 Actual
FlexElement 2 Actual
FlexElement 3 Actual
FlexElement 4 Actual
FlexElement 5 Actual
FlexElement 6 Actual
FlexElement 7 Actual
FlexElement 8 Actual
FlexElement 9 Actual
FlexElement 10 Actual
FlexElement 11 Actual
FlexElement 12 Actual
FlexElement 13 Actual
FlexElement 14 Actual
FlexElement 15 Actual
FlexElement 16 Actual
Communications Group
Current Setting Group
L90 Line Differential Relay
APPENDIX A
