MITSUBISHI ELECTRIC
GOT 1000
Graphic Operation Terminal
Connection Manual
(Ethernet connection with FXCPU)
Art. no:
SH(NA)-080719ENG
MITSUBISHI ELECTRIC
INDUSTRIAL AUTOMATION
01102008
Version B

Advertisement

Table of Contents
loading

Related Manuals for Mitsubishi Electric GOT 1000

Summary of Contents for Mitsubishi Electric GOT 1000

  • Page 1 MITSUBISHI ELECTRIC GOT 1000 Graphic Operation Terminal Connection Manual (Ethernet connection with FXCPU) Art. no: SH(NA)-080719ENG MITSUBISHI ELECTRIC INDUSTRIAL AUTOMATION 01102008 Version B...

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS (Always read these precautions before using this equipment.) Before using this product, please read this manual and the relevant manuals introduced in this manual carefully and pay full attention to safety to handle the product correctly. The precautions given in this manual are concerned with this product. In this manual, the safety precautions are ranked as "DANGER"...
  • Page 4 [DESIGN PRECAUTIONS] DANGER Incorrect operation of the touch switch(s) may lead to a serious accident if the GOT backlight is gone out. When the GOT backlight goes out, the POWER LED flickers (green/orange) and the display section turns black and causes the monitor screen to appear blank, while the input of the touch switch(s) remains active.

  • Page 5: Wiring Precautions

    [MOUNTING PRECAUTIONS] CAUTION When loading the communication unit to the GOT, fit it to the connection interface of the GOT and tighten the mounting screws in the specified torque range. Overtightening can cause a drop, failure or malfunction due to the damage of the screws or unit. When mounting the multi-color display board onto the GOT, tighten the mounting screws within the specified torque range.
  • Page 6 [WIRING PRECAUTIONS] CAUTION Always ground the FG terminal, LG terminal, and protective ground terminal of the GOT power to the protective ground conductors dedicated to the GOT. Not doing so may cause an electric shock or malfunction. Be sure to tighten any unused terminal screws with a torque of 0.5 to 0.8N•m. Failure to do so may cause a short circuit due to contact with a solderless terminal.
  • Page 7 [TEST OPERATION PRECAUTIONS] DANGER Before performing the test operations of the user creation monitor screen (such as turning ON or OFF bit device, changing the word device current value, changing the settings or current values of the timer or counter, and changing the buffer memory current value), read through the manual carefully and make yourself familiar with the operation method.
  • Page 8 [STARTUP/MAINTENANCE PRECAUTIONS] CAUTION Do not disassemble or modify the unit. Doing so can cause a failure, malfunction, injury or fire. Do not touch the conductive and electronic parts of the unit directly. Doing so can cause a unit malfunction or failure. The cables connected to the unit must be run in ducts or clamped.
  • Page 9 [DISPOSAL PRECAUTIONS] CAUTION When disposing of the product, handle it as industrial waste. [TRANSPORTATION PRECAUTIONS] CAUTION When transporting lithium batteries, make sure to treat them based on the transport regulations. (For details on models subject to restrictions, refer to the User's Manual for the GOT you are using.) Make sure to transport the GOT main unit and/or relevant unit(s) in the manner they will not be exposed to the impact exceeding the impact resistance described in the general specifications of the User's Manual, as they are precision devices.

  • Page 10: Revisions

    This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses. Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may occur as a result of using the contents noted in this manual.

  • Page 11: Table Of Contents

    INTRODUCTION Thank you for choosing Mitsubishi Graphic Operation Terminal (Mitsubishi GOT). Read this manual and make sure you understand the functions and performance of the GOT thoroughly in advance to ensure correct use. CONTENTS SAFETY PRECAUTIONS ..........................A - 1 REVISIONS...............................A - 8 INTRODUCTION...............................A - 9 CONTENTS ..............................A - 9 ABOUT MANUALS ............................

  • Page 12: About Manuals

    ABOUT MANUALS The following manuals are also related to this product. In necessary, order them by quoting the details in the tables below. The manual in PDF-format is included in the GT Works2 and GT Designer2 products. Related Manuals Manual Number Manual Name (Model Code) GT16 User's Manual...

  • Page 13: Abbreviations And Generic Terms

    ABBREVIATIONS AND GENERIC TERMS Abbreviations and generic terms used in this manual are as follows: Abbreviations and generic terms Description GT SoftGOT1000 Abbreviation of GT SoftGOT1000 GT1695 GT1695M-X Abbreviation of GT1695M-XTBA, GT1695M-XTBD GT1685 GT1685M-S Abbreviation of GT1685M-STBA, GT1685M-STBD Abbreviation of GT1695, GT1685 GT16 , GT16 GT1595...
  • Page 14 Communication unit Abbreviations and generic terms Description GT15-QBUS, GT15-QBUS2, GT15-ABUS, GT15-ABUS2, Bus connection unit GT15-75QBUSL, GT15-75QBUS2L, GT15-75ABUSL, GT15-75ABUS2L Serial communication unit GT15-RS2-9P, GT15-RS4-9S, GT15-RS4-TE RS-422 conversion unit GT15-RS2T4-9P, GT15-RS2T4-25P Ethernet communication unit GT15-J71E71-100 MELSECNET/H communication unit GT15-J71LP23-25, GT15-J71BR13 MELSECNET/10 communication unit GT15-75J71LP23-Z , GT15-75J71BR13-Z CC-Link IE controller network communication...
  • Page 15 Option Abbreviations and generic terms Description GT05-MEM-16MC, GT05-MEM-32MC, GT05-MEM-64MC, GT05-MEM-128MC, Memory card CF card GT05-MEM-256MC Memory card adaptor GT05-MEM-ADPC GT16-MESB, GT15-FNB, GT15-QFNB, GT15-QFNB16M, Option function board GT15-QFNB32M, GT15-QFNB48M, GT15-MESB48M, GT11-50FNB Battery GT15-BAT, GT11-50BAT GT16-90PSCB, GT16-90PSGB, GT16-90PSCW, GT16-90PSGW, GT16-80PSCB, GT16-80PSGB, GT16-80PSCW, GT16-80PSGW, GT15-90PSCB, GT15-90PSGB,...
  • Page 16 License key (for GT SoftGOT1000) Abbreviations and generic terms Description License GT15-SGTKEY-U, GT15-SGTKEY-P License key (for GT SoftGOT2) Abbreviations and generic terms Description License key A9GTSOFT-LKEY-P (For DOS/V PC) License key FD SW5D5F-SGLKEY-J (For PC CPU module) Others Abbreviations and generic terms Description OMRON PLC Abbreviation of PLC manufactured by OMRON Corporation...
  • Page 17 HOW TO READ THIS MANUAL About each of functions This manual includes information of GT Designer2 Version2.90U. For additional functions of upgraded version, refer to the List of functions added by version upgrade. Symbols Following symbols are used in this manual. Connectable model name Not connectable model name Applicable model name...
  • Page 18 MEMO A - 16...

  • Page 19: Overview

    OVERVIEW This manual describes the specifications, system configuration, setting method, connection cables, and others for connecting the GOT to the FXCPU via the Ethernet connection. For applying the setting examples in this manual to the actual system, make sure that the target system has no troubles on the control.
  • Page 20 Relevant Manuals The following manuals are available for GOT1000 series. Refer to each manual suitable for the intended purpose. The following manuals describe that the GOT cannot connect to the FXCPU (FX ) via the Ethernet connection because the manuals are written for commercially available products. For referring to each manual, read the manuals so that the GOT can connect to the FXCPU (FX ) via the Ethernet connection.
  • Page 21 (2) Installing a GOT Connecting with a PLC For the operations from installing a GOT to communicating with a PLC CPU, refer to the following manuals. (Included) GT16 General Description GT16 User's Manual GOT1000 Series Purpose GT15 General Description GT15 User's Manual Connection Manual GT11 General Description GT11 User's Manual...
  • Page 22 1.1 Ethernet Connection with FXCPU Ethernet connection with FXCPU The GOT can monitor devices of the FXCPU via the Ethernet connection (TCP/IP communication). The user can create a network with commercially-available products, including hubs and cables. System configuration for Ethernet connection The following shows the system configuration.

  • Page 23: Ethernet Connection With Fxcpu

    ETHERNET CONNECTION WITH FXCPU 2.1 System Configuration ..page 2-2 This section describes devices and cables required for the Ethernet connection. Select a system suitable for the application. 2.2 Preparatory Procedures for Monitoring ..

  • Page 24: System Configuration

    2.1 System Configuration Select a system configuration suitable for the application. Conventions used in this section Numbers (e.g. ) of System configuration and connection conditions correspond to the numbers (e.g. ) of System equipment. Refer to the numbers for checking models and applications. Communication driver Ethernet(FX) 2.1.1...
  • Page 25 System equipment (1) GOT Image Name Model name Model Ethernet Ethernet interface - (Built into GOT) • For Ethernet communication Ethernet Ethernet communication unit GT15-J71E71-100 • For Ethernet communication (2) Programmable controller Image Name Model *1 *2 -ENET Ethernet module For the system configuration of the Ethernet module, refer to the following manual.

  • Page 26: Preparatory Procedures For Monitoring

    2.2 Preparatory Procedures for Monitoring The following shows the procedures before monitoring and corresponding reference sections. Section 2.2.1 Install the OS on the GOT. Installing OS on GOT Section 2.2.2 Make sure that the OS is installed on the GOT. Checking OS installation on GOT Section 2.2.3 Set the communication interface.

  • Page 27: Installing Os On Got

    2.2.1 Installing OS on GOT Install the standard monitor OS, communication driver, and option OS on the GOT. For how to install the OS, refer to the following manual. GT Designer2 Version Basic Operation/Data Transfer Manual Check the following in the communication driver. •...

  • Page 28: Checking Os Installation On Got

    2.2.2 Checking OS installation on GOT Check if the OS is correctly installed on the GOT with the Drive information tab of GT Designer2. For the operations on the Drive information tab, refer to the following manual. GT Designer2 Version Basic Operation/Data Transfer Manual The OS is correctly installed on the GOT when the following can be checked.

  • Page 29: Setting Communication Interface (Communication Settings)

    2.2.3 Setting communication interface (Communication settings) Set the GOT communication interface with [Communication Settings] and [Ethernet] of GT Designer2. Select the communication driver installed on the GOT for drivers to be set for each communication interface. For details on [Communication Settings] and [Ethernet] of GT Designer2, refer to the following manual. GT Designer2 Version Screen Design Manual Communication settings...

  • Page 30: Communication Detail Settings

    Communication detail settings (1) GT16 Item Description Range Set the network No. of the GOT. GOT NET No. 1 to 239 <Default: 1> Set the station No. of the GOT. GOT PLC No. 1 to 64 <Default: 1> Set the IP address of the GOT. 0.0.0.0 to 255.255.255.255 GOT IP Address <Default: 192.168.3.18>...
  • Page 31 Click the button and perform the setting in the [GOT IP Address Setting] screen. Seting 2 - 9 2.2 Preparatory Procedures for Monitoring 2.2.3 Setting communication interface (Communication settings)
  • Page 32 (2) GT15 Item Description Range Set the network No. of the GOT. GOT NET No. 1 to 239 <Default: 1> Set the station No. of the GOT. GOT PLC No. 1 to 64 <Default: 1> Set the IP address of the GOT. GOT IP Address 0.0.0.0 to 255.255.255.255 <Default: 192.168.0.18>...
  • Page 33 Examples of communication detail settings For examples of communication detail settings, refer to the following. Section 2.3 Programmable Controller Settings 2 - 11 2.2 Preparatory Procedures for Monitoring 2.2.3 Setting communication interface (Communication settings)
  • Page 34 Ethernet settings (1) Ethernet settings Item Description Range The host station is displayed. Host (“*” is displayed for the host station.) Set the network No. of the connected Ethernet module. N/W No. 1 to 239 <Default: blank> Set the station No. of the connected Ethernet module. PLC No.
  • Page 35 (1) Communication interface settings with utility The communication interface setting can be changed on [Communication Setting] in the utility after downloading [Communication Settings] of the project data. For details on the utility, refer to the following manual. User's Manual (2) Precedence in communication settings When the communication settings are set with GT Designer2 or the utility, the GOT operates with the latest setting.

  • Page 36: Downloading Project Data

    2.2.4 Downloading project data Download the project data on the GOT. For how to download the project data, refer to the following manual. GT Designer2 Version Basic Operation/Data Transfer Manual Check items to be downloaded, and then click the button. Download Download 2 - 14...

  • Page 37: Mounting Communication Unit And Connecting Cable

    2.2.5 Mounting communication unit and connecting cable Precautions for mounting communication unit and connecting cable Shut off all phases of the GOT power before mounting the communication unit and connecting the cable. Mounting communication unit Mount the Ethernet communication unit on the extension unit connector of the GOT.

  • Page 38: Checking If Got Recognizes Controllers

    2.2.6 Checking if GOT recognizes controllers Check if the GOT recognizes controllers with [Communication Setting] of the utility. • Assignment status of the channel number and communication driver corresponding to the communication interface • Communication unit installation status Remark How to display utility (at factory default) When using GT16 or GT1595 Utility call key 1-point press on GOT screen upper-left corner...
  • Page 39 (1) GT16 After powering up the GOT, touch [Main Menu] [Comm. Setting] from the Utility. The [Comm. Setting] appears. Touch [Assign Ethernet I/F]. The [Assign Ethernet I/F] appears. Verify that the following communication driver name is displayed in the box for the Ethernet interface to be used.
  • Page 40 (2) GT15 After turning on the GOT, touch [Main Menu] [Communication Setting] from the utility. The Communication Setting screen is displayed. Check that the following communication driver name is displayed in the box for the communication interface to be used. •...

  • Page 41: Checking If Got Correctly Monitors Controllers

    2.2.7 Checking if GOT correctly monitors controllers Checking errors on GOT Errors occurred with the GOT, programmable controller CPU, servo amplifier, communications, and others can be checked with the utility of the GOT. For how to use the utility of the GOT, refer to the following manual. User’s Manual (When using GT15) Communication...
  • Page 42 Checking communication state of GOT (1) When using Command Prompt of Windows Execute a Ping command with Command Prompt of Windows . (a) With normal communication C:\>Ping 192.168.0.18 Reply from 192.168.0.18: bytes=32 time<1ms TTL=64 (b) With abnormal communication C:\>Ping 192.168.0.18 Request timed out.
  • Page 43 Checking programmable controller settings For connecting the FXCPU to the GOT, programmable controller settings are required. Check if the programmable controller settings are correct. Section 2.3 Programmable Controller Settings Checking communication state with each station (Station monitoring function) The station monitoring function detects errors (communication timeout) of the stations monitored by the GOT.
  • Page 44 (b) Faulty station information (GS231) • The bit of the Ethernet setting No. corresponding to the faulty station turns on. 0: Normal 1: Abnormal • When the error is recovered, the bit turns off. GS231 bit 0 GS231 bit 1 GS231 bit 2 GS231 bit 3 Ethernet setting No.

  • Page 45: Programmable Controller Settings

    2.3 Programmable Controller Settings This section describes the settings of the GOT and Ethernet module (FX -ENET) given for the system con- figuration shown at Ethernet module (FX -ENET) For details of the Ethernet module (FX -ENET), refer to the following manual. -ENET USER'S MANUAL System configuration Communication settings and Ethernet settings of GT...
  • Page 46 Ethernet parameter settings of FX Configurator-EN Set the Ethernet parameter with FX Configurator-EN. For using FX Configurator-EN, install GX Developer Ver. 8.25B or later on the personal computer. For details on FX Configurator-EN, refer to the following manual. FX Configurator-EN USER’S MANUAL (1) Ethernet settings Setting Item...
  • Page 47 (2) Operational settings Setting Item Setting (with GOT connected) (Use default value.) Communication date code IP address 192.168.0.19 Initial timing (Use default value.) Send frame setting TCP Existence confirmation setting : Required : Set if necessary : Not required Because the port No. 5551 is fixed, the GOT operates as follows, regardless of the setting for the item. •...
  • Page 48 (3) Open settings Setting Item Setting (with GOT connected) Protocol Open system MELSOFT connection Fixed buffer Fixed buffer communication procedure Pairing open Existence confirmation (Use default value.) Host station Port No. (DEC.) Transmission target device IP address Transmission target device Port No. (DEC.) When connecting to multiple GOTs and peripheral devices The number of protocols equivalent to that of the GOTs and devices must be set.
  • Page 49 Communication settings and Ethernet settings of GT Designer2 (1) Communication settings Item Setting (Use default value.) GOT NET No. GOT PLC No. GOT IP Address 192.168.0.18 GOT Port No. (Communication) 5019 GOT Port No. (Ethernet Download) 5014 Default Gateway 0.0.0.0 Subnet Mask 255.255.255.0 Retry...
  • Page 50 Checking communication state of Ethernet module (1) When using Command Prompt of Windows Execute a Ping command with Command Prompt of Windows . (a) With normal communication C:\>Ping 192.168.0.19 Reply from 192.168.0.19: bytes=32 time<1ms TTL=64 (b) With abnormal communication C:\>Ping 192.168.0.19 Request timed out.

  • Page 51: Precautions

    2.4 Precautions When connecting to multiple GOTs (1) Setting [PLC No.] When the FXCPU is connected to multiple GOTs in the Ethernet network, set a different [PLC No.] for each GOT. Section 2.2.3 Setting communication interface (Communication settings) (2) Setting IP address Do not use the IP address "192.168.0.18"...

  • Page 52: List Of Functions Added By Version Upgrade

    2.5 List of Functions Added by Version Upgrade The following describes the function added by version upgrade of GT Designer2 or OS. For using the function below, use the GT Designer2 or OS of the stated version or later. Version of GT Item Description Version of OS...
  • Page 53 WARRANTY Please confirm the following product warranty details before using this product. 1. Gratis Warranty Term and Gratis Warranty Range If any faults or defects (hereinafter "Failure") found to be the responsibility of Mitsubishi occurs during use of the product within the gratis warranty term, the product shall be repaired at no cost via the sales representative or Mitsubishi Service Company.
  • Page 54 Microsoft Windows, Microsoft Windows NT, Windows Vista are registered trademarks of Microsoft Corporation in the United States and other countries. Adobe and Adobe Reader are registered trademarks of Adobe Systems Incorporated. Pentium and Celeron are a registered trademarks of Intel Corporation in the United States and other countries. Ethernet is a trademark of Xerox Co., Ltd.
  • Page 56 Phone: +370 (0)5 / 232 3101 Fax: +370 (0)5 / 232 2980 MITSUBISHI ELECTRIC Mitsubishi Electric Europe B.V. /// FA - European Business Group /// Gothaer Straße 8 /// D-40880 Ratingen /// Germany Tel.: +49(0)2102-4860 /// Fax: +49(0)2102-4861120 /// info@mitsubishi-automation.com /// www.mitsubishi-automation.com FACTORY AUTOMATION...
