Blomberg WM 26110 NBL00 Owner's Manual

Front-loading automatic washer
Hide thumbs
Table of Contents

Advertisement

Quick Links

To prevent accidents and machine damage, read these
instructions before installation or use. Use the washer only as
instructed in this owner's guide and installation instructions
included with your washer. Keep this guide for future
reference
Front-Loading Automatic Washer
WM 26110 NBL00
Owner's Guide & Installation Instructions
As an ENERGY STAR® partner,
BLOMBERG has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.

Advertisement

Table of Contents
loading

Related Manuals for Blomberg WM 26110 NBL00

Summary of Contents for Blomberg WM 26110 NBL00

  • Page 1 Keep this guide for future reference Front-Loading Automatic Washer WM 26110 NBL00 Owner’s Guide & Installation Instructions As an ENERGY STAR® partner, BLOMBERG has determined that this product meets the ENERGY STAR® guidelines for energy efficiency.
  • Page 2 Please read this guide first! Dear Customer, We hope that your product which has been manufactured in modern facilities and passed through a strict quality control procedure will give you the best results. Therefore, we advise you to read through this document carefully before using your product and keep it for future reference.

  • Page 3: Table Of Contents

    First Use ..... . 15 FOR THE BLOMBERG CLOTHES Laundry Tips ....15 WASHERS Sorting the laundry .

  • Page 4: Your Washer

    Overview � � � � � � 1 - Detergent Dispenser 4 - Control Panel 2 - Loading Door 5 - Filter Cap 3 - Top Lid 6 - Height-adjustable Feet...

  • Page 5: Specifications

    Specifications Front Loading Automatic Washer Models WM 26110 NBL00 Height (in/cm) 33 (84) Width (in/cm) 24 (60) Depth (in/cm) 22 (54) Net Weight (lbs/kg) 157 (71) Electricity (V/Hz.) 208-240 V / 60 Total Current (A) Total Power (W) 2000-2350 Spinning cycle (rpm max.)

  • Page 6: Important Safety Instructions

    Important Safety Instructions B WARNING - To reduce the risk of fire, weather and direct sunlight. electric shock or injury to persons • Do not tamper with controls. while using your appliance follow • Do not repair or replace any basic safety precautions, including part of the appliance or attempt the following: any servicing unless specifically recommended in the user-...
  • Page 7 fume which may cause death. • Always be sure to empty all foreign • Do not operate this appliance if it is materials from the pockets of your damaged, malfunctioning, partially clothing as small items such as coins, disassembled, or has missing or pins etc could severely damage the broken parts, including a damaged appliance.
  • Page 8 • All broken and faulty components, panels and parts must only be replaced with original Blomberg spare parts by a Blomberg Service technician. • Do not force the washer door open when it is locked. The door must be closed any time during the programme cycle.

  • Page 9: Installation Instructions

    Installation Instructions Read this first ! floor or soft floor. If you have to install your washer on a wooden or frame This washer can be individually installed construction floor, the floor must be in free-standing and built-in installations. reinforced properly and the washer You can also install your washer with must be located in the corner of the your dryer as a free-standing or built-in...

  • Page 10: Allowable Clearances For Undercounter Installation

    Tilt the washer to remove the packaging reinforcement. Remove the packaging reinforcement by pulling the ribbon. Minimum counter width should be 50” (127 cm) for a pair of Blomberg washer & dryer. Custom undercounter installation – Washer & Dryer Removing shipping bolts...

  • Page 11: Levelling The Washer

    (208-240V, 60Hz) located on the appliance. For this purpose, a junction box (as seen in picture below) must be obtained. Junction box is supplied with Blomberg Electrical Connection Clothes Dryer (model no: DV 16540 NBL00) and it works as a...

  • Page 12: Power Supply And Circuit

    individual branch circuit outlet. bolted connection. B WARNING – Be sure to unplug A WARNING – Be sure that the water the power cable before attempting maintenance or cleaning of your connection of this washer is handled appliance to minimize the risk of by a qualified service technician or a electric shock.

  • Page 13: Drainage

    An additional clip etc can be used for connections). safe connection. • Always use genuine “Blomberg” • Drain hose may also be connected to water supply hoses when connecting a minimum 1.26 in (32 mm) diameter with this washer. Old or worn-out stand pipe.

  • Page 14: Installation Checklist

    Installation Checklist appliance are potentially dangerous for children. Materials such as plastic • Water inlet hoses and accessory bags, films or wrappings must be bags must be removed from the kept away from children or disposed wash drum. properly to prevent the danger of • Transportation/shipping bolts must suffocation.

  • Page 15: Operating Instructions

    Operating Instructions C Wash the items which are care First Use labeled as “machine-washable”. Do B WARNING – To reduce the risk of fire, not machine wash items that are electric shock, or injury to persons, having symbol on fabric care read the IMPORTANT SAFETY label.

  • Page 16: Preparing The Laundry

    extended contact of damp clothes capacity of the selected program before or after washing to prevent dye cycle. Washing results are adversely transfer. affected by an overloaded drum. Overloading may also cause wrinkling C Wash heavily and lightly soiled items and abrasion on clothes.

  • Page 17: Detergent Use

    Detergent Use Light soiling No visible stains or soiling About Detergent Normal soiling C Your washer is designed to use only A few visible light stains or soiling HE (high efficiency) detergents. You Heavy soiling should always look for the following Highly visible stains or soiling symbol on the label of detergents: If you use a non-HE detergent with this...

  • Page 18: Water Consumption

    dosing cup and follow the instructions right compartment of the dispenser. on the package. This container ensures dispensing and dilution of bleach during the first rinse If you use a liquid detergent, be sure of wash cycle. There is a maximum fill to use a HE (High efficiency) detergent line on the container.

  • Page 19: Selecting A Cycle And Operating Your Washer

    Selecting a Cycle and Operating Your Washer Control panel 7- Power Button 8 - Cycle Selector Knob 9 - Spin Speed Selector Knob 10 - Start/Pause/Cancel Button 11 - Time Delaying Button and Indicator 12 - Program Follow-up Indicator 13 - Auxiliary Function Buttons Turning the washer on Program cycle selection Prepare the washer for program Select the appropriate program cycle selection by pressing the “Power”...

  • Page 20: Program Cycle Selection Table

    Program Cycle Selection Table White and colorfast items made of cotton and linen (baby 163F / Sanitary clothes, garments, Heavy 1100 Full • R,S,Q 73°C sheets, pillowcases, kitchen towels, tablecloths) Temp 145F / Cottons/ Heavy 1100 Full • R,S,Q Boost 63°C Regularwash White and colorfast...

  • Page 21: Wash Cycles

    that particular type of load. label of items. 3. Maximum load capacities are •Delicates suggested for various load types. You can wash your delicate easy- Wash cycles of full load (cottons/ care and wrinkle-free items on this regularwash,permanent press) should program.

  • Page 22: Auxiliary Functions (Options)

    C You can use “No spin” selection dispenser. in order to drain the water without 2. Set the washing program, spinning at the end of program cycle. temperature, spin speed and, if required, the auxiliary functions. For Cottons/Regularwash cycles, 3. When the time delaying button is spin speed can be adjusted between pressed once, a 3 hour delay is 800-1100 rpm (including no spin).

  • Page 23: Changing The Selections After The Program Has Started

    The “Wash” light on the program follow- 3. Press “Start/Pause/Cancel” button to up indicator lights up when “Start/ start the program. Pause/Cancel” button is pressed after selecting the washing program. “Spin” C The selection to be made must be lamp will light up at the final spin step. in accordance with the step the The “Ready”...

  • Page 24: Cancelling A Program

    lock, press on the Quick wash and Extra rinse auxiliary function keys from the left simultaneously for 3 seconds after the washing program has started. Quick wash auxiliary function light will start flashing. To start a new program after the program is over or to interfere the program, childproof lock should be deactivated.

  • Page 25: Quick Instructions For Daily Use

    Quick instructions for daily use Preparation Re-spinning the laundry 1. Turn on both hot and cold water The control system for an unbalanced faucets fully. Check and be sure the load can pause the spinning in cases water connection is tight. when the distribution of the laundry in 2. Place the laundry in the drum.

  • Page 26: User Maintenance Instructions

    User maintenance instructions A WARNING – Be sure to unplug abrasive scrubbing agent when cleaning the power cable before attempting rubber seal. maintenance or cleaning of your appliance to minimize the risk of electric shock. Cleaning detergent dispenser Remove any powder/liquid residue buildup in the dispenser drawer.

  • Page 27: Cleaning The Water Inlet Strainers

    clean the control panel. the pump filter may be clogged. You C Never use a sponge or scrubbing may have to clean it occasionally to material. These will damage the prevent any clogging. Water must be painted and plastic parts. drained completely to clean the pump filter.

  • Page 28: Descaling The Washer

    abrasive materials such as metal wool while cleaning the drum. Take the manufacturer’s instructions into account if you are using a descaling agent. Descaling agents may contain materials that are hazardous for washer components. Use descaling agents compatible for use in clothes washers. • Pull out the emergency drain hose When using a powder descaling from its housing.

  • Page 29: Troubleshooting

    Troubleshooting Problem Cause Explanation / Suggestion There may be some water in your appliance when you It is not harmful to your washer. You should run a Water in the receive it. This is from the “sanitary” cycle without any clothes and laundry washer.
  • Page 30 Inlet hose connections may be Be sure the strainers and rubber seals of the leaking. water inlet hoses are solid and securely fitted. End of the drain hose may be Tightly attach the drain hose to the waste pipe or loosely inserted into the waste sink (See “Installation Instructions, Drainage”).
  • Page 31 The washer will wait until there is a sufficient amount of water, which may lengthen the Water pressure may be low. cycle time to avoid poor washing results due to insufficient water. Cycle time is lengthened to avoid poor washing Supply voltage may be low.
  • Page 32 The automatic spin correction system might have been activated due to the unbalanced distribution of the laundry in the drum. It continuously The laundry in the drum may be tangled up too spins. Remaining There may be an imbalance of much.
  • Page 33 The automatic spin correction system might have been activated due to the unbalanced distribution of the laundry in the drum. No spinning is performed when the laundry is not evenly There may be an imbalance of distributed in the drum to prevent any damage to load in the drum.
  • Page 34 Wrong program cycle and Select the proper program cycle and temperature temperature might have been for the laundry to be washed (See “Laundry Tips” selected. & “Program Cycle Selection”). Use the recommended amount of HE detergent Using insufficient amount of appropriate for water hardness and soil level of detergent.
  • Page 35 If the water hardness is higher, using insufficient Using insufficient amount of amount of detergent can cause the laundry to detergent. become stiff in time. Use appropriate amount of detergent according to the water hardness. You may have added too much softener beyond max fill line.
  • Page 36 Detergent (powder) may have Dry the dispenser drawer before putting in been put in wet dispenser powder detergent. drawer. Detergent or Detergent (powder) may have Store detergent in a cool and dry place. Do not softener residue gotten damp. keep them under high temperatures. in the dispenser/ Too much Softener may be too dense or...
  • Page 37 Excessive laundry might have Do not load the washer in excess. been loaded in. Wrong program cycle and Select the proper program cycle and temperature temperature might have been for the laundry to be washed (See “Laundry Tips” selected. & “Program Cycle Selection”). Use the recommended amount of HE detergent Using insufficient amount of appropriate for water hardness and soil level of...

  • Page 38: Warranty Statement

    5 business days after delivery of the product to the home, whichever is later. Lifetime limited warranty from date of first installation * ++ (parts only) Blomberg will repair ++Parts replaced will assume the identity of the or replace to the original owner the stainless original parts + their original warranty.

  • Page 39: How To Get Service

    HOW TO GET SERVICE Please contact the Distributor for your State or Province as listed on the Distributor Contact List, or call our Toll Free Number at 1 800 459 9848 for direction to an Authorized Blomberg Service Agent.
