Brake Bleeding / Fluid Change - Polaris RZR PRO R Service Manual

2. Install new stat-o-seal, front brake line banjo fitting
new stat-o-seal, front brake line banjo fitting
stat-o-seal, and brake pressure switch to the front
port on the master cylinder.
IMPORTANT
Lubricate seals with a thin film of DOT 4 brake fluid
prior to installation.
3. Rotate the brake lines until they are orientated as
shown. Torque banjo bolt and brake pressure switch
to specification.
ITEM
DESCRIPTION
q Rear Brake Line
w Front Right Brake Line
e Front Left Brake Line
TORQUE
Banjo Bolt / Brake Pressure Switch:
15 ft-lbs (20 Nm)
9940259 R02 - 2022 RZR PRO R / PRO R 4 Service Manual
© Copyright Polaris Industries Inc.
e
, 4. Install the master cylinder retaining bolts
w
, new Torque bolts to specification.
5. Reconnect the main harness to the brake pressure
switch.
6. Align the operating rod clevis to the brake pedal.
Install the operating rod fastener and nut to retain the
operating rod to the pedal.
ANGLE
7. Perform the BRAKE BLEEDING / FLUID CHANGE
page procedure.
125°
105°

BRAKE BLEEDING / FLUID CHANGE

105°
Bleed the right rear caliper first, followed by the left rear,
front right, and finally the front left caliper.
Always wear safety glasses when handling chemicals
BRAKE SYSTEM
TORQUE
Master Cylinder Mounting Bolts:
23 ft-lbs (31 Nm)
IMPORTANT
CAUTION
and fluids.
r
and nuts.
10
10.13
