Running The Video Demo - Xilinx Spartan-6 FPGA SP605 Embedded Kit Getting Started

Table 2: Video Demo System ACE DIP Switch Settings
Now you are ready to run the pre-built Video Demo provided with this kit. Follow the next
set of instructions to run the demo.

Running the Video Demo

1.
2.
3.
4.
.
X-Ref Target - Figure 4
SP605 Getting Started Guide
UG727 (v1.1) June 21, 2010
DIP Switch
1
2
3
4
If the SP605 board is not already powered on, plug in the power adapter to local AC
power. Plug the 12V power cable into the board connector on J18. Turn on the power
by switching the SW2 to the "ON" position.
After a couple of seconds, the Xilinx logo should be displayed on the DVI (or VGA)
monitor.
Open a web browser on the host computer and set the URL to 192.168.1.10.
You should see the web page shown in
page and the operation performed are described in
Figure 4: Video Demo Web Page
www.xilinx.com
Switch Position
Off
Off
Off
On
Figure 4. The various selections in the Web
Table 3
Introduction
UG727_04_111309
13
