Introduction
2.
X-Ref Target - Figure 2
3.
Table 1: SP605 Jumper Settings
Jumper REFDES
4.
5.
X-Ref Target - Figure 3
12
Connect either a DVI monitor to the SP605 board connector shown in
the provided DVI/VGA adapter to connect to a VGA monitor. Ensure that the monitor
is turned ON and its input selected to DVI or VGA appropriately.
Figure 2: SP605 DVI Connector
Confirm that the SP605 jumper settings are at default, as shown in
J19 Exclude FMC LPC connector J2
J22 SFP Full BW
J44 SFP Enabled
J46 SPI Select SPI X4 Memory U32
J60 System ACE CF Error LED DS18 Enabled
Insert the provided Compact Flash card into the board as shown in
Set the System ACE DIP switches shown in
Figure 3: Compact Flash Card Installation and DIP Switch Settings
www.xilinx.com
Function
FMC JTAG Bypass
SFP Module
SPI Memory Select
System ACE CF Error LED
Figure 3 to the settings listed in
UG727_03_111309
Figure 2 or use
UG727_02_111309
Table 1.
Default
Jump 1-2
Jump 1-2
Jump 1-2
Jump 1-2
Jump 1-2
Figure 3.
Table 2.
SP605 Getting Started Guide
