Xilinx Spartan-6 FPGA SP605 Embedded Kit Getting Started page 31

The SP605_Embedded_Kit directories and their content are explained in
X-Ref Target - Figure 27
Table 6: SP605 Embedded Kit Directory Structure Contents
SP605 Getting Started Guide
UG727 (v1.1) June 21, 2010
Figure 27: SP605 Embedded Kit Directory Structure
Directory
Includes the data sheet, tutorials, and other supporting
Documentation
documentation provided with this Embedded Kit.
Base MicroBlaze Processor Subsystem including the software
SP605_System
applications and platforms.
Test_Images Images for testing the Video Demo.
Final state of files after the Hardware and Software Tutorials have
Tutorial_Completed
been completed.
Working directory to use for executing the Hardware and
Software Tutorials. The tutorials start with the base MicroBlaze
Tutorial Sandbox
Processor Subsystem plus addition files needed to build the Video
Demo. Perform the tutorials in this directory.
Base MicroBlaze Processor Subsystem with the Video Pipeline
Video_Demo
cores. Source files for the video demo are included here.
www.xilinx.com
Next Steps
Table
UG727_29_111309
Purpose
6.
31
