OPERATION AND SERVICE MANUAL Process Gas Chromatograph PGC2000 2000-OSM F2: October 2008...
Page 2
ABB has no obligation with respect to any ABB equipment which: (a) has been improperly installed, repaired or altered, (b) has been subjected to misuse, negligence or accident, or (c) has been used in a manner contrary to ABB’s instructions and requirements.
Page 3
LIST OF EFFECTIVE PAGES—PGC2000 MANUAL DATE OF ISSUE FOR EACH VERSION OF THIS MANUAL: February 2000 January 2002 April 2006 August 2000 August 2002 September 2006 January 2001 November 2002 July 2007 March 2001 August 2004 September 2007 August 2001...
Title Page GLOSSARY .............................. G-1 SECTION 1. INTRODUCTION EQUIPMENT DESCRIPTION ........................1-1 PGC2000 WITH FLAME PHOTOMETRIC DETECTOR ................1-2 AIR PURGE SYSTEMS ..........................1-2 SYSTEM VARIATIONS ..........................1-3 SPECIFICATIONS ............................. 1-3 Physical ............................... 1-3 Safety Area Classification ........................1-3 Power ..............................1-4 Instrument Air ............................
Page 5
TABLE OF CONTENTS (continued) Title Page EQUIPMENT STARTUP .......................... 2-15 Initial Power On ..........................2-15 Verify GCC Operation ........................2-19 Calibration Run ..........................2-21 Checking Streams ..........................2-23 Chroma I/O PCB Setup ........................2-23 Analytical Operation .......................... 2-26 Verify Zero Baseline on Chromatogram .................... 2-26 Time Cycle Check..........................
Page 6
TABLE OF CONTENTS (continued) Title Page CIRCUIT BOARDS ..........................4-11 Power Supply PCB ..........................4-11 Chroma I/O PCB ..........................4-11 Single Board Computer (SBC) PCB ....................4-11 DC Solenoid Driver PCB ........................4-11 Front Panel PCB ..........................4-11 FID Amplifier PCB..........................4-11 TCD Amplifier PCB ...........................
Page 7
TABLE OF CONTENTS (continued) Title Page Regular Report ..........................4-33 Short Report ............................4-34 Standard Calibration Report ......................4-34 AIR PURGING ............................4-34 Y and Z Purge ............................ 4-34 X Purge Operation ..........................4-35 X Purge Override Option ........................4-36 X Purge Override Contacts ........................
Page 9
TABLE OF CONTENTS (continued) Title Page Oven Temperature is Greater Than T-Rating ................... 6-16 Reasonableness ..........................6-16 AC Zero Crossing Loss ........................6-17 Over Temp Trial Test Fail ........................6-18 Controller Housing Internal Temperature Greater Than 80 Degrees C ..........6-18 Set Point Unacceptable ........................
Page 10
TABLE OF CONTENTS (continued) Title Page SECTION 7. TEST PROCEDURES TP 1: CARRIER, MAKEUP, AND UTILITY GAS SUPPLIES ..............7-1 TP 2: CARRIER AND MAKEUP GAS FLOW ADJUSTMENTS ..............7-1 TP 3: SAMPLE VALVE LEAKING/COLUMN FLOODING ................ 7-1 TP 4: CARRIER OR MAKEUP GAS REGULATOR ................. 7-2 TP 5: TC DETECTOR BALANCE ......................
Page 11
TABLE OF CONTENTS (continued) Title Page SECTION 8. REPAIR REPLACING HEATERS ..........................8-1 Isothermal Temperature Oven Heater ....................8-1 Sample Valve Heater ........................... 8-2 SAMPLE VALVE REPAIR .......................... 8-3 Disassembly on the Analyzer ......................8-5 Reassembly on the Analyzer ....................... 8-6 Removing the LSV from the Analyzer ....................
Page 12
TABLE OF CONTENTS (continued) Title Page Removing the Catalytic Tubes ......................8-36 Installing the Catalytic Tubes ......................8-36 Packing the Housing .......................... 8-37 Installing the Methanizer/Air Cleanup Assembly ................8-37 Air Cleanup Testing ........................... 8-38 Air Cleanup Final Preparation ......................8-38 REPAIRING THE CARRIER GAS PANEL (ANALOG) ................
Page 13
TABLE OF CONTENTS (continued) Title Page Information Display ..........................8-66 Menu Items ............................8-67 Statistical Display..........................8-69 DUAL AIR CLEANUP REPAIR ........................ 8-72 Removing the Dual Air Cleanup Assembly ..................8-72 Removing the Air Cleanup Tubes...................... 8-73 Installing the Air Cleanup Tubes ......................8-74 Packing the Housing ..........................
Page 14
TABLE OF CONTENTS (continued) Title Page SECTION 10. VISTA BASIC INTRODUCTION ............................10-1 Using the Editor ..........................10-1 Vista BASIC Line Format ........................10-2 Character Set ............................. 10-2 Constants ............................10-2 Variables ............................10-3 Arrays ..............................10-3 Expressions and Operators ....................... 10-4 ALPHABETIC LISTING ..........................
Page 15
TABLE OF CONTENTS (continued) Title Page GET OUTSTANDING REQUESTS Function .................. 10-13 GET PEAK TYPE PARAMETER Function ..................10-13 GET PERCENT OFF FOR A TEMPERATURE Command ............. 10-13 GET PERCENT OFF FOR A TIME Command ................10-13 GET PERCENT OFF TABLE Command ..................10-14 GET PRESSURE OF A ZONE Command ..................
Page 16
TABLE OF CONTENTS (continued) Title Page POWER FAIL ALARM Function ...................... 10-24 PREVIOUS INJECT TIME Function ....................10-24 PREVIOUS INJECT UCT Function ....................10-24 PREVIOUS METHOD Function ....................... 10-24 PREVIOUS STREAM Function ....................... 10-24 PURGING STREAM Command ...................... 10-24 PURGING STREAM Function ......................10-24 PUT ACTUAL RETENTION TIME Command .................
Page 17
TABLE OF CONTENTS (continued) Title Page VALVE Command ........................... 10-34 WRITE DIGITAL OUTPUT Command..................... 10-34 WRITE TREND OUTPUT Command ....................10-34 Y2X Function ........................... 10-35 ZERO OUTSTANDING REQUESTS Command ................10-35 Vista BASIC Support for VistaNET Communications ..............10-35 SUBJECT LISTING ..........................10-37 General Statements .........................
Page 18
ILLUSTRATIONS Figure Title Page Typical Process Gas Chromatograph PGC2000 ..............1-1 PGC with Flame Photometric Detector .................. 1-2 LSV Connection Methods, Early Analyzers ................2-3 LSV Connection Methods, New Analyzers ................2-4 Side View of Analyzer, Showing Manifold Vent Location ............2-6 Analyzer Adjustments ......................
GLOSSARY A/D converter device that converts an analog signal to a digital value analyzer process gas chromatograph ASCII American Standard Code for Information Interchange; standardized computer coding for printed characters Auto Zero procedure bringing the detector signal as close to electrical zero as possible; brings the signal into the most sensitive area of the A/D baseline reference point from which peak height or peak area is measured on a...
Page 24
GLOSSARY (continued) Digital I/O Digital Input/Output PCB; enables the use of additional stream valves and/or alarm sensors DIP switch PCB switch that is used to set values through hardware instead of software drift the variances from the baseline or the norm; generally associated with uncontrolled or unwanted changes in pressure or temperature Electronic Instrument Association elution time...
Page 25
GLOSSARY (continued) host link serial communications link which allows the transmitting of analysis results to the host computer integer whole numbers that do not contain decimal points Input/Output Liquid Crystal Display Light Emitting Diode Low Limits, entered into a component table; when a component's measured and calculated value falls below the LL value, an alarm is generated LO COMM...
Page 26
GLOSSARY (continued) Post Analysis the portion of the controller program that calculates the value for the routine components from the collected data, after completion of the analysis Postan abbreviation for the post analysis routine PROM Programmable Read Only Memory PSFC Process Supercritical Fluid Analyzer psia pounds per square inch absolute...
Page 27
GLOSSARY (continued) trend output analog signal related to concentration of specified component VistaNET; analytical network that links analyzers, DCS, and support people using the data VNSA VistaNET Name Service Administrator; PC software that serves as the address book for the VistaNET watchdog timer hardware circuit alarm that indicates when the software fails to cycle through its entire task structure within a set period of time...
Page 28
(EMI) which could affect the performance of the analyzer. In order for the analyzers produced by ABB Lewisburg to maintain their EMC integrity, the installation methods employed are of equal importance. The grounded...
SECTION 1. INTRODUCTION EQUIPMENT DESCRIPTION The Process Gas Chromatograph PGC2000 separates and measures the individual components of gas or liquid samples. It automatically samples and analyzes process streams, using the analyzer's Gas Chromatograph Controller (GCC) to control analytical functions. The analyzer (see Figure 1-1) may be mounted on a wall, a rack, or a floor stand.
This manual refers to these data sheets and drawings as the “Data Package.” PGC2000 WITH FLAME PHOTOMETRIC DETECTOR When the analyzer has a flame photometric detector (FPD), a panel attached to the left side of the analyzer contains the detector, the detector amplifier, and the high-voltage transformer that provides the spark to ignite the FPD (see Figure 1-2).
SYSTEM VARIATIONS This manual supports the PGC2000 basic analyzer. An appendix to the main manual presents additional instructions for special applications such as PGC2002 (simulated distillation), PGC2003 (PNA), PGC2005 (temperature programmed GC), PGC2007 (fuel sulfur), PGC2008 (olefins), and PGC2030 (Sparging Sample Conditioning System).
Power WARNING The Neutral and Ground (Earth) connections to the PGC2000 must be at earth (0 Volts) potential. Failure to maintain earth (0 volts) potential at these connection points constitutes a serious safety hazard. Voltage and Frequency: 100 VAC (+15, -6 VAC), 50/60 Hz ± 10% 120 VAC ±...
Temperature Control Method: Closed loop PID Ambient Oven Temperature: + 30° to 180° C (Settings and display in °C only) Setpoint Resolution: 1° C Temperature Stability: Steady Ambient: ±0.1° C Ambient Range: ±1.0° C Gas Control (Analog) Control Method: Mechanical regulators Filtration: 2 microns at inlet, provided Inlet Pressure:...
Gas Control (Digital) Control Method: Closed loop PID; temperature stabilized Number of Zones: 1 to 5 Filtration: 2 microns at inlet, provided Inlet Pressure: Minimum: Setpoint + 10 psig (69 kPa, 0.7 bar) Maximum: 100 psig (689 kPa, 6.89 bar) NOTE It is the customer's responsibility to set relief devices used to protect the analyzer and prevent hazardous releases at a maximum of 200 psig (1380 kPa, 13.80 bar).
SECTION 2. INSTALLATION AND START-UP SAFETY CONSIDERATIONS Before starting to install the analyzer, read the safety information below. WARNING Before beginning installation, repair, or maintenance on the analyzer, contact the local Safety Department to ensure that all safety guidelines, regulations and procedures are followed.
3/16-inch flat blade screwdriver 1/8-inch flat blade screwdriver 9/64-inch ball driver 7/16-inch open end wrenches (2) 1/2-inch open end wrenches (2) 9/16-inch open end wrenches (2) 5/8-inch open end wrenches (2) 6-inch adjustable wrench 12-inch adjustable wrench 3/8-inch drive socket set with ratchet handle and leverage bar 5/16-inch (8 mm) hex key wrench (supplied with Analyzer) 5/64-inch (2 mm) hex key wrench (supplied with Analyzer) Equipment:...
Purge Air Alarm The analyzer contains circuits that detect the loss of purge air to the analyzer and generate alarm signals to the operator. The customer has the responsibility to connect the purge alarm to a visual or audible annunciator located in a constantly monitored area, as required by NFPA 496 (1993). Liquid Sample Valve The Liquid Sample Valve (LSV) utilizes two different connection methods for the sample lines.
New analyzers have the sample lines connected to a mounting plate attached to the LSV's mounting flange, as shown in Figure 2-2. Customer Connections Figure 2-2. LSV CONNECTION METHODS, NEW ANALYZERS You must take extreme care to avoid having the sample lines exert force on the sample connections of the Liquid Sample Valve.
1. Do not remove the tube caps, provided at the analyzer tubing ports to prevent deterioration of the columns, until immediately before making each connection. 2. Use an anticorrosion material for the lines and fittings. 3. To ensure using proper size tubing and pipe, refer to the Outline and Mounting Dimensions Diagram contained in the Data Package.
The manifold vent must be plumbed from the analyzer to a safe area at 0 psia or atmospheric vent. To do this, connect appropriate tubing to the manifold vent (see Figure 2-3) and run this tubing to a hazard-free area. MANIFOLD VENT Figure 2-3.
• Contact output Error alarms, timing signal, status signal, and annunciator • Contact input Operation start/stop, mode-selection request, etc. • Analog output (4 to 20 mA) Analog hold output, chromatogram recorder output • Analog input (-10 to +10 volts) • Detector output (10 volts) Refer to the applicable drawings in your Data Package for specific interconnection wiring information.
Sample System Checkout Verify that the sample system has been leak and flow checked and is known to be operating correctly. GCC Pre-Checks CAUTION Before opening any analyzer doors, ensure the area is safe and hazard-free and will remain so the entire time the analyzer is open. 1.
5. Refer to Figure 2-4 (when EPC is installed, the Pressure Control Panel will be blank). The purge air and heater air pressures should be as specified on the label below the corresponding regulator. Purge Air Panel Pressure Control Panel Figure 2-4.
MATCHING COLUMN FLOWS When you are matching column flows, refer to the Data Package for flow rates and valve configurations. Although methods of matching column flows vary with valve configurations, the following procedures apply to most configurations. Verify flows using a flow meter connected to the point being checked (e.g., cell vent).
Checking Total Column Flow To check column flow using a 10-port sample valve and an 8-port selector valve, perform the following steps (other valve configurations use similar procedures): 1. Turn all valves off as described in the previous paragraph. 2. See Figure 2-6. To check total column flow, set Valves One and Two to ON. 3.
Checking Analytical Flow Adjust 1. Set Valve One to OFF; Valve Two remains ON (see Figure 2-7). CARRIER COLUMN PRESSURE AIR IN AIR OUT AIR OUT AIR IN VALVE "OFF" VALVE "ON" SAMPLE VENT SELECTOR FLOW ADJ SELECTOR SAMPLE VENT COLUMN ANALYTICAL FLOW ADJ...
Checking Backflush Flow 1. Connect the flow-measuring device to the Backflush Vent and verify that Valves One and Two are OFF (see Figure 2-8). 2. Adjust the Backflush Vent restrictor to the flow rate stated in the Data Package. CARRIER COLUMN PRESSURE AIR IN...
Checking Selector Flow Adjust 1. See Figure 2-9. Set Valve One to ON and Valve Two to OFF. CARRIER COLUMN PRESSURE AIR OUT AIR IN AIR IN AIR OUT VALVE "ON" VALVE "OFF" SAMPLE VENT SELECTOR FLOW ADJ SELECTOR SAMPLE VENT COLUMN ANALYTICAL...
EQUIPMENT STARTUP CAUTION Before opening any analyzer doors, ensure the area is safe and hazard-free and will remain so the entire time the analyzer is open. The following instructions assume that all equipment has been properly installed and checked, that the analyzer has been application engineered, and that temperature controllers, alarm switches and other adjustments have been properly set.
Page 50
CAUTION It is the customer’s responsibility to ensure that the hydrogen supply to the analyzer does not exceed 100 psig (689 kPa, 6.89 bar) and that the customer’s pressure relieving devices are set to relieve at 200 psig (1380 kPa, 13.8 bar). Failure to control the hydrogen pressure within these specifications may cause loss of property and loss of life.
Page 51
CAUTION Do not ignite FPD/FID flame if the isothermal oven temperature is below operational level. Low oven temperature will result in condensation damage to the flame cell. Check oven temperature on the Temperature Control screen (see "Temperature Control Table" in Section 4). 13.
b. On the Chroma Board screen, verify that the FPD Temp Zone is the same as that specified in the Data Package (see Figure 2-10). c. On the Chroma Board screen, observe the "Ignitor" line. "Manual" should be underlined. d. Press the F1 (Exit) soft key. e.
g. On the Manual Temperature Control Mode screen (see Figure 2-11), verify that the actual temperature for the FPD is at least 120 degrees. **** Manual Temperature Control Mode **** Zone Config Actual Rate ISO-OVEN 79.9 80.0 PROG. OVEN PROG/C 220.1 220.0 120.2...
This restores to main memory the tables that were most recently saved to E PROM. If ABB Lewisburg provided Applications Engineering, verify all method tables by comparing them to those in the Data Package. This is done most easily by printing the tables (if a printer is connected to the analyzer).
4. Press the F2 (Test Printer) soft key. A string of characters should print. If characters print go to step 5. If a string of characters does not print go to step 9. 5. Verify that the cursor is on PRINTER. 6.
8. On the Request Analysis screen (see Figure 2-13), select the method number for a calibration run. ****** Request Analysis ****** Analysis Requests: For a benchmark or calibration enter the method#, otherwise enter the stream#:[1 None Stream Bench PENDING: Accept Clear Escape Request...
20. On the Commands screen cursor to ANALYSIS CONTROL, if necessary, and press the F4 (Start/Stop Analysis) soft key. 21. On the Start/Stop Analysis screen, cursor to “At End of Analysis?” and then press the F2 (Stop Analyzer) soft key. 22.
NOTE Each time one of these address switches is changed, you must initialize the switch selections. To do this, open the GCC Front Panel, press and release the RESET switch on the Single Board Computer PCB, and then close the Front Panel. Additionally, you must restore the tables from E PROM (see "Verify GCC Operation").
• The screen saver option lets you blank the display screen when it is not being used. SW1-8 OFF activates the screen saver, while SW1-8 ON disables this feature. If the GCC has user nameable inputs option, you may insert names for up to five sensor inputs (digital inputs on the Chroma I/O Board).
2. On the Manual Control Mode screen (see Figure 2-16), cursor down to CHROMA, then left to OFF. ****** Manual Control Mode ****** Valves:- - - - - - - - Time:00000 Enter Valve: [0] Cycle Time:00000 RECORDER: Method Tbl: Offset Stream: Attn...
3. A message line appears above the soft key, similar to the following: “Zero Offset Used 004%.” A value less than 10% is good. 4. When you have completed the zero offset check, press the F1 soft key as necessary to return to the Background screen.
3. Press F2 (Printer Report Type) soft key to display Printer Report Type screen (see Figure 2-17). Highlighted or underlined items on this screen indicate current selections. 4. Cursor right or left to the report type you want to print: Raw Data, Regular, or Short (see "OTHER TABLES AND REPORTS"...
Page 64
Component Definition screen and the benchmark stream must be defined (see "Preparing a Method Table" in Section 4). To run a benchmark test: 1. On the Background screen press the F1 (Exit to Commands) soft key. 2. On the Commands screen cursor to TABLE EDIT and then press the F2 (Methods) soft key. 3.
21. On the Start/Stop Analysis screen, cursor to “At End of Analysis?” and then press the F2 (Stop Analyzer) soft key. 22. Press the F1 soft key as necessary to return to the Background screen. TCD Zero Adjust (Filament TCD Only) To adjust the Thermal Conductivity Detector (TCD) zero, perform the following steps: 1.
4. Press the F1 soft key as necessary to return to the Background screen. CONNECTING THE ANALYZER TO VISTANET If the analyzer is connected to ABB's VistaNET, you must connect the GCC to the VistaNET PC as described in the VistaNET 2.0 Installation Guide (2300-IG). After the connections have been completed and verified you must set up the GCC to work on this network.
5. On the VN Menu screen (see Figure 2-19), cursor to STARTUP and then press the F2 (Essential Addresses) soft key. ************ VN Menu ********** TABLES STARTUP TESTING Essential Access Refresh Escape Addresses Level VNSA Tables Figure 2-19. VN MENU SCREEN (STARTUP HIGHLIGHTED) 6.
13. When you have completed and verified your entries, press the F2 (Exit and Update) soft key to save your entries. ******* VistaNET Essential Addresses ******* Name: [GCC10 Tag: GCC10 Board Address: 0.10 Domain 1: Domain 2: VNSA Address: 0.1.0.199 Router Address: 0.1.0.199 Exit...
1. At the VN MENU screen, cursor to STARTUP and press the F3 (Access Level) soft key (see Figure 2-21). 2. Select level desired from scroll list and select Exit and Update. ***** VistaNET Access Level ***** Access Level: Unrestricted Exit Escape Update...
1. At the VN MENU screen cursor to TABLES (see Figure 2-22). **** VN Menu ***** TABLES STARTUP TESTING Subscriber Escape List Config Table Figure 2-22. VN MENU SCREEN (TABLES HIGHLIGHTED) 2-36 2000-OSM, F1...
2. Press the F2 (Subscriber List) soft key to access the VistaNET Subscriber List (see Figure 2-23). ***** VistaNET Subscriber List ***** Command: Previous Next Add Delete Type: Primary Address: 0.1.0.100 Secondary Address: 0.2.0.100 Time Out: 7000 This Entry: 1 Total Entries: 3 Exit Accept...
1. On the VN Menu screen with Startup highlighted, press the F4 (Refresh VNSA Tables) soft key and then press the Escape soft key to return to the Commands screen. 2. On the Commands screen, cursor to TESTING/SETUP and then press the F4 (Status Display) soft key.
SECTION 3. OPERATION CONTROLS AND INDICATORS Gas Chromatograph Controller (GCC) The GCC’s internal controls and indicators are as shown in Figure 3-1. Single Board Computer Chroma I/O PCB (SBC) PCB Reset Switch (resets SBC PCB) Halt Time Out Highway 2 Transmit Highway 2 Receive Highway 1 Transmit Highway 1 Receive...
Regulator and Gauge Panels The Purge Air Panel contains the pressure regulators and gauges for controlling the purge air and heater air (see Figure 3-3). Purge Air Panel Pressure Control Panel Figure 3-3. REGULATOR AND GAUGE PANELS If the analyzer has mechanical regulators and gauges, the Pressure Control Panel will have the analytical regulators and gauges.
(see Figure 3-4). Screen Title ********** B A C K G R O U N D ********** ABB Analytical GCC Remote 0.1 803V029-1R (Std GCC) (C) 2001 **ALARM** **ALARM**...
1. On the Background screen press the F1 (Exit to Commands) soft key. 2. On the Commands screen cursor to ANALYSIS CONTROL, if necessary, and then press the F2 (Request Analysis) soft key. 3. On the Request Analysis screen (see Figure 3-5) select the method number to be calibrated. ****** Request Analysis ******...
Checking Streams To verify the operation of each stream, perform a single analysis on each one, as follows: 1. On the Background screen press the F1 (Exit to Commands) soft key. 2. On the Commands screen cursor to ANALYSIS CONTROL, if necessary, and then press the F3 (Streams) soft key.
4. On the Start/Stop Analysis screen press the F2 (Start Analyzer) soft key. The analyzer will run the stream for which it is purging, according to the method designated in the Stream Assignment screen. The analyzer will continue in analytical operation until you command it to stop.
Alarm messages are of two primary types: main alarms and subordinate alarms. Main alarms identify a major alarm category. These alarms appear on the alarm screen at the left margin (e.g., “Post Analysis Error:” in Figure 3-6). If a main alarm has subordinate alarms, the main alarm title will include a colon (:).
6. If the chromatogram is too large for the recorder or too small to read, press the F1 soft key as necessary to return to the Manual Control Mode screen. 7. On the Manual Control Mode screen, cursor down to the attenuation line (Attn:) and change the attenuation value as necessary to obtain the desired chromatogram size.
COMMAND TREE The menu system (command tree) branches out from general to specific topics, eventually leading you to a screen that allows you to view or edit the desired parameters. The soft key selections move you down the command tree one level at a time. Figure 3-8 shows the command tree. REQUEST ANALYSIS BACKGROUND STREAMS...
SECTION 4. TECHNICAL DESCRIPTION FUNCTIONAL DESCRIPTION Figure 4-1 shows a typical analytical flow system, using the flame ionization detector for illustration. Connections at the right side of the analyzer cabinet provide all gas and air inputs. Sliding plate valves, liquid sample valves, or a combination of both, provide control and measurement of the sample.
The carrier gas has three purposes: to purge the columns and cell prior to introducing a sample, to sweep the sample into the detector cell, and to backflush the backflush column. An externally mounted pressure regulator and gauge regulate the input flow. The sample system, together with the GCC, controls the calibration sample input.
4. If, after six attempts to light the flame, it still is not lit, the ignition sequence terminates and the hydrogen is shut off. ***** Chroma Board ***** Detector: FID Flame: Lit Ignitor: Off H2: None Hardware Zero: 5.10mV ( 4.7%) Software Zero: 3.18mV...
The cell consists of a polarized jet, a collector, and a chamber in which hydrogen fuel and sample are burned in air. A current, whose magnitude is proportional to the concentration of the sample, flows between the jet and the collector. This current goes to the FID Amplifier Assembly. The FID Amplifier Assembly provides ignition control for the FID cell and amplification of the detector cell output signal prior to routing the signal to the control section for signal processing.
Flame Photometric Detector (FPD) Flame photometric detection works on the principle that when sulfur is burned in a hydrogen-rich atmosphere, luminescence (light) characteristic to sulfur is produced. The FPD cell (see Figure 4-5) consists of a teflon burner chamber equipped with a spark ignition system, and a photomultiplier tube which is thermoelectrically temperature controlled.
Simultaneous Dual Detectors Simultaneous dual detectors function in parallel using any two detectors. To accomplish this simultaneous processing requires one Chroma I/O Board in the analyzer for each detector. Chroma I/O Board #1 is in GCC Card Cage slot 2 and Chroma I/O Board #2 is in slot 1. Stream assignments and method tables determine which detector processes each stream and method.
Figure 4-6). While the Background screen provides information on both detectors, other screens will show the data from only one of the two detectors at a time. ********** B A C K G R O U N D ********** ABB Analytical GCC Remote 0.1 803V031-1R (Sim Dual Det) (C) 2001 19-JUN-2002...
To view the data from the second Chroma I/O Board, enter "2" in the highlighted box on the screen and then press the F2 (Select Chroma Bd and View) soft key. The Chroma Board #2 screen will appear (see Figure 4-8) and all screens showing Chroma I/O Board data will now show the data from Chroma Board #2.
Parameters) soft key. On the Control Parameters screen (see Figure 4-9), cursor down the selections until "Detector 1 Mode" and "Detector 2 Mode" appear. Select the desired mode for Detector 2 and then press the F2 (Exit and Update) soft key to save this setting. ********** Control Parameters **********...
Since there is no dummy stream in Master/Master mode, all Link column entries are "00". In Master/Slave mode, the Link column in the Stream Assignment screen shows which stream the slave is using. Because only the Master detector controls the actual streams used, this slave stream is a "dummy"...
• Vista Basic commands identify the detector by placing the Chroma I/O Board number after the alarm name (e.g., CUR_STRM (1) or INTEGER = RAI (1,0), where the first digit identifies the Chroma I/O Board). Before starting an analysis, the GCC prompts for the Chroma I/O Board to use during the analysis. The selected Chroma I/O Board must be in Master mode or the analysis will not start.
TCD Amplifier PCB The TCD Amplifier PCB, on the left side wall of the GCC, amplifies the thermal conductivity detector output signal and provides it to the Chroma I/O Board for processing. FPD Amplifier and Interface PCBs The FPD Amplifier PCB linearizes and amplifies the flame photometric detector output signal and applies it to the Chroma I/O Board for processing.
Communications PCB (Option) The Communications PCB, in any open slot in the GCC Card Cage, provides a two-channel interface between the GCC and the VistaNET. This PCB is not used when the analyzer has the optional Ethernet PCB. See "VISTANET OPTION" for a detailed explanation of the VistaNET option. VistaNET Interconnect PCB (Option) The VistaNET Interconnect PCB, located on the side of the GCC Card Cage, provides low-speed interface between the GCC and the VistaNET.
Page 95
RF = CC/A, for peak area analysis of a given component RF = CC/H, for peak height analysis of a given component • Normalized, in which the controller calibrates the analyzer against the external standard, then calculates the sum of all peak areas and determines the percent contribution of each component peak Normalized calibration requires you to provide the component concentration value of each component to be analyzed in a calibration stream.
between the various components is established (at installation), only the K-factor is changed during calibration. Preparing a Method Table This subsection explains how to prepare a method table by constructing a sample method table. Figure 4-12 shows a chromatogram of the analysis to be controlled. This analysis is 90 seconds long and has three components to measure: A, B, and C.
2. On the Commands screen, cursor down to TABLE EDIT and then press the F2 (Methods) soft key. 3. The Method Table #?? screen will appear (see Figure 4-14). Use the number keys on the GCC front panel to enter the number “1” for this method (the method number given in Figure 4-13 data).
5. Cursor to the Calibration Type line. The current choice is underlined. To change the choice, cursor right or left to the desired type (in this case Ext Std) and then cursor to the next line. Moving the cursor up or down sets the new choice. 6.
14. Enter “30” for Component #1’s time and then cursor right to select “Component.” Since this is the first component entered into the table, “Undefined” will appear in the Value column. 15. Cursor right to the Value column. The Component Definition screen will appear (see Figure 4- 17), which will allow you to define this component.
3. In steps 4 through 7, review the Cal Define & Cycle Time screen and make changes as necessary. 4. When the Method Table #01 (or other number you have chosen) appears, locate the specific line you want to change. 5.
4. On the second Print Tables screen, enter the Method Table number and then press the F2 (Print Selected Table) soft key. The Method Table and Component Table will print (see Figure 4-19). METHOD TABLE #01 8:25:29 Fri 30 Sep 1994 Cycle Time = 00140 TIME FUNCTION...
method has forced gating and slope detection on at the same time, the controller uses the one turned on first, ignoring the second one and sending an alarm to tell you that both peak detection methods were on. Forced Gating When a component's elution time is known, forced gating can measure the peak.
higher number causes the system to respond less quickly but is more sensitive. For that reason the default is set at 8, a median value that provides both good response and sensitivity for most applications. Peak width only has meaning when slope detect is running. Slope Detect On tells the method that slope detection will be used for this analysis.
peak which begins on a valley point (see Figure 4-22). Since the tangent skim termination search operates only during a single peak, it is activated by setting Tangent Skim at the proper time in the method table (no On/Off is required). To use tangent skim, choose a time in the method table that occurs at a point before the peak in question and set Tangent Skim.
different peak areas in adjacent analyses (see Figure 4-23). By selecting “Pk End =Vly” you can force the routine to call it a valley each time it occurs, thus removing the indecision and stabilizing the calculations. “Pk End =Base” is used the same way as “Pk End =Vly.” Selecting “Pk End =Vly” or “Pk End=Base”...
“Proj Reverse” is a reverse projection flag that identifies the end of a desired peak or group of peaks. It is set in the baseline after the end of the peak (see “HBR” in Figure 4-25). With reverse projection, “Proj Term” is set before the start of the peak—and before “Proj Reverse” (see “HBT” in Figure 4-25). The system then measures the peak that occurs between HBT and HBR.
Another method for handling badly tailing peaks is “End=Crest+” (see Figure 4-27). This code forces the end of the peak to be the crest time plus the time specified in the code, providing a reproducible end to the peak even if the crest of the peak is moving. To use this command, insert “End = Crest+” into the method together with a specified time after the crest.
NOTE If any of the above conditions exist, an error will occur. Stream Step Stream Step begins the automatic sample purge of the sample stream being analyzed. It must occur after completion of the sample inject for this stream. This is particularly important when the current stream being analyzed requires multiple sample injections.
Skip Next TCF If Stream = This allows you to skip the next time-coded function when this stream value equals the stream number entered in the method table. This function allows you to skip a TCF on a particular stream, usually because that TCF does not apply to that stream.
6. Press the F1 soft key as necessary to return to the Background screen. Printing Tables 1. On the Background screen, press the F1 (Exit to Commands) soft key. 2. On the Commands screen, cursor down to PRINTER and then press the F2 (Print Tables) soft key.
operator orders a different sequence. Figure 4-28 shows the Random Streams screen and Figure 4- 29 shows the printed table. ****** Random Streams ****** Stream 0001 0002 0001 0003 0004 0001 0005 0006 More Below Insert Delete Exit Line Line Figure 4-28.
Time Table This table contains the schedules for automatic calibrations, benchmarks and stream analyses (see Figure 4-30). The Time Table lists information by the day of the month and time of day (using a 24- hour clock). If you enter “00” as the day, hour, or minute, the specified event will occur every day, hour, or minute.
10. Cursor right one column and select the value for the desired function (method number, valve number, Vista Basic program, etc.). Use the keyboard number keys to enter the number and then press ENTER. 11. Add more lines by inserting lines and repeating steps 6 through 10 as needed. 12.
4. When you finish editing the stream data, press the F1 (Exit) soft key. 5. On the next screen, press the F2 (Exit and Update) soft key to save the new stream data, or press the F1 (Escape) soft key to retain the original data. 6.
Short Report This report (see Figure 4-34) gives basic information on the analysis, which you can use to check analyzer operation periodically. It is a one-line report which provides the stream number, injection time, and concentration for each component by number. The Short Report comes in two forms: •...
will reduce the classification to Nonhazardous/General Purpose. Since the Y and Z Purge systems are identical except for nomenclature, the following explanation applies to both. The purge air enters the analyzer system through a pressure regulator, an orifice, and a gauge used to set purge flow, and then into the electronics housing where purge air flow is maintained until a fault condition exists.
The X Purge cycle time depends totally on the application, but it may vary with analyzer configuration and condition. Refer to the analyzer label or Data Package for specific purge specifications. Once X Purge applies power to the analyzer, power continues to the analyzer as long as the electronics housing maintains air purge pressure.
6. With X Purge reset, the air purge timed cycle begins in the electronics housing. When you use Override during start-up, it overrides the X Purge control of power to the analyzer, but the air purge timed cycle continues. Once the electronics housing has pressurized and X Purge completes its timed purge cycle, the analyzer will have power from the X Purge.
CAUTION Saving tables and functions from RAM to E2PROM erases tables or functions already residing in E2PROM. Since these tables and functions in RAM will replace the tables already in E2PROM, be certain they are correct before you perform this sequence.
CAUTION Restoring tables and functions from E2PROM will erase any tables or functions already residing in RAM. Since these tables and functions in E2PROM will replace the tables already in RAM, be certain they are correct before you perform this sequence.
Temperature Configuration Table Low/High Alarm Limits Zone Name Temperature Control Table Zone relationship Set Point, by entry number in method Ramp Rate, by entry number in method Temperature Check Table Zone relationship Alarm Temperature value, by entry number in method Action (Display or Abort), by entry number in method Zone Controller Type...
4. On the Manual Temperature Control Mode screen (see Figure 4-38), select the desired field using the Up and Down cursor keys. Enter two digits for valve numbers (e.g. 04), as some installations have more than nine valves. **** Manual Temperature Control Mode **** Zone Config...
3. On the Pres and Temp Control screen (see Figure 4-39), cursor to TEMP CONFIGURATION and press the F3 (Names and Limits) soft key. **** Pres and Temp Control **** TEMP CONTROL PRES CONTROL TEMP CONFIGURATION Names Escape Zone Controller Config Limits Type...
5. In the Names field you can change the zone name by typing a new name, up to a maximum of ten characters long. When you have completed the name, cursor to another field. 6. In the low and high alarm limits field, type the desired alarm value and then cursor to another field.
12. Enter a set point temperature within T-Rating limits by repeating steps 5 through 10. 13. If you do not hold the switch long enough, * TEMP BD ALARM * will also display and the new setting will not be accepted. Check the temperature with the T-Rating on the Manual Temperature Control Mode screen and the temperature setting specified in the Data Package and repeat steps 5 through 10.
6. Cursor to the Function field and scroll to Temp Contrl. In Figure 4-41, with Temp Contrl in the Function field the Value column lists Two as the function to be performed from the Temperature Control Table. ***** Method Table #01 ***** Time Function...
8. On the Temperature Control screen, move the cursor as necessary to select the Zone Name from among the names in the list, and to change Set Point and Ramp Rate values of the desired entries. CAUTION When you exit the Temperature Control screen, the value in the Entry line highlighted when you exit becomes the Value entry in the Method Table.
7. Move the cursor to the Value column and the Temperature Check Table appears, with the cursor on Entry line 01 (see Figure 4-43). Note the Entry line number when you enter the table so you can exit the table from the same, if desired. ***** Temperature Check *****...
4. On the Controller Type screen (see Figure 4-44), verify that the controller type is the same as specified in the Data Package. ***** Controller Type ***** Controller Type: Regular Exit Escape Update Figure 4-44. CONTROLLER TYPE SCREEN 5. If you want to change the controller type, use the cursor arrow keys to select the desired type and then press the F2 (Exit and Update) soft key to save the changes, or press the F1 (Escape) soft key to retain the original controller type.
4. On the Temp Config Table screen (see Figure 4-45), select the desired field using the cursor keys. **** Temp Config Table **** Remove Heat On Config Sensor Air Loss Probe Probe INACT Probe INACT Probe Exit Figure 4-45. TEMP CONFIG TABLE SCREEN 5.
10. “Hold Switch on Temp Board” will appear on the screen. CAUTION Before opening any analyzer doors, ensure the area is safe and hazard-free, and will remain so the entire time the analyzer is open. If the analyzer has X Purge, operate the override function as described in "X Purge Override Option."...
NOTE On power loss, Set Points and Ramp Rates for all programmable zones (PROG and PROG/C) are lost. You must re-enter the Values manually or execute the method stored in the Method Table. Alarms Digital Temperature Controller alarms are described in "Temperature Board" alarms in Section 6. When a temperature alarm occurs, it appears as *** ALARM *** flashing on the Background screen and * TEMP BD ALARM * flashing on the Manual Temperature Control Mode screen.
1. On the Background screen press F2 (Manual Control). 2. On the Manual Control Mode screen press F4 (Press. & Temp. Control). 3. On the Pres and Temp Control screen (see Figure 4-46), cursor to PRES CONTROL and press F2 (Manual Pressure Control). **** Pres and Temp Control ****...
4. On the Manual Pressure Control Mode screen (see Figure 4-47), select the desired field to change using the cursor arrow keys. Enter two digits for valve numbers (e.g., 04), as some installations have more than nine valves. **** Manual Pressure Control Mode **** Zone Config...
3. On the Pres and Temp Control screen, cursor to PRES CONTROL and press F3 (Pressure Config). 4. On the Pressure Config Table screen (see Figure 4-48), select the desired field using the cursor keys. **** Pressure Config Table **** Zone Name Config...
13. If the GCC accepts the change, an acknowledging message appears. Release the switch and close the front panel. 14. On the Pres and Temp Control screen, cursor to PRES CONTROL and press F3 (Pressure Config). 15. Verify that changes have been accepted and then press F1 as necessary to return to the Background screen.
11. If the Set Point is not accepted, the Pres Zone name flashes and * PRES BD ALARM * flashes on the message line. If this happens, release the switch and check the pressure with the pressure limits prescribed for this zone. 12.
6. Cursor to the Function field and scroll to Pres Contrl. In Figure 4-49, with Pres Contrl displayed, the Value column lists Two as the function to be performed. ***** Method Table #01 ***** Time Function Value [0001] Pres Contrl 0010 Pres Check 0120 Noise Calc 0125 Noise Calc...
8. On the Pressure Control screen, move the cursor as necessary to select the Zone Name from among the names in the list, and to change Set Point and Ramp Rate values of the desired entries. CAUTION When you exit the Pressure Control screen, the Entry line highlighted when you exit becomes the Value entry in the Method Table.
7. Move the cursor to the Value column and the Pressure Check Table appears, with the cursor on Entry line 01 (see Figure 4-51). Note the Entry line number when you enter the table so you can exit the table from the same, if desired. ***** Pressure Check *****...
The raw chromatogram storage and reprocessing option allows only one chromatogram of each type to be saved (last, calibration, benchmark, typical or alarm), regardless of the length of the cycle. When the chromatogram is saved, the Raw Data Report is saved also (but method tables are not saved).
2. On the Display Saved Data screen, cursor to MEMORY USED/LEFT and press the F2 (Execute the Command) soft key. The Raw Chromatogram Memory Used/Left screen will appear (see Figure 4-53). **** Raw Chromatogram Memory Used/Left **** Total Used = 038208 bytes Total Left = 272916 bytes Start Bytes...
3. On the Define Save/Release screen, cursor to MANUAL RELEASE and then press the F2 (Execute The Command) soft key. 4. On the Manually Release Analysis screen, select the type of data to release and press the F2 (Manually Release Analysis) soft key. If you want to release more than one analysis, you must select the type of data separately for each analysis released.
4. Note the number under Alarm Mask. This represents the alarm configuration set on the Define Alarm Mask screen. If you want to verify or change the alarm mask, press the F4 (Expand Alarm Mask) soft key. ****** Automatically Save Analyses ****** Save This Type Alarm...
Page 145
2. On the Graphics Setup screen, select the type of chromatogram to save: Calibration (Cal), Benchmark (Bench), most recent (Last), Alarm, or typical (Typ). 3. Next select the amount of screen offset, which determines where on the screen the chromatogram will display. Start with “0” and adjust if necessary. 4.
Reprocessing Saved Chromatograms The Reprocess Saved Data Screen (soft key F3 on the Command Screen) allows you to select type of raw data to reprocess, how to process it. Reprocessing takes saved data and sends it back through peak detection in an off-line mode, then produces a report available to VistaNET (but not displayed on the screen).
REMOTE GC OPERATION OPTION The analyzer can operate with other ABB GCC front panels. To implement this option requires the following changes to the analyzer: an optional PCB and several changes in wiring connections and switch settings. This section of the manual explains how to prepare the analyzer for remote operation and how to operate it in this configuration.
The first five switch positions on SW1 (labeled 0 through 4 on the PCB), determine the analyzer's address. Switch positions 6, 7 and 8 are always ON ("1"). Figure 4-58 shows how to identify the address from the switch positions. Switch No.
When you set the No Analyzer switch ON, the front panel will communicate only with other GC’s; the front panel will not communicate with an attached analyzer. When the Lock Out Remote switch is ON, another front panel on the network cannot access this front panel, but this front panel can access other network front panels.
3. Enter the number of the remote analyzer you want to access. Verify you have entered the number correctly and then press the F3 (EXECUTE) soft key. 4. If you entered the remote number incorrectly, press the F2 (CLEAR ENTRY) soft key, re-enter the number, and then press the F3 (EXECUTE) soft key.
ANALOG OUTPUT OPTION This option provides analog outputs to a printer, computer, or other external device. Up to two optional PCBs, installed in the GCC Card Cage, provide different combinations of current and voltage outputs. These combinations are: • one current board, with up to 16 output channels •...
6. When you have completed the changes to this Trend Table screen, review them to ensure all items are correct and then press the F1 (Exit) soft key. ****** Trend Table ****** Range Range Chan Stream Comp High 1.0000 100.00 0.5000 100.00 1.0000 100.00 0.5000 100.00...
range values for that component (see Figure 4-62). If you select stream “00” for a particular channel, the specified component will apply on that channel for all streams. ****** Digital Table ****** Range Range Chan Stream Comp High 1.0000 100.00 0.5000 100.00 0.5000...
NOTE Before making changes to VistaNET screens, verify all data with your Network Administrator to ensure proper connection and operation with VistaNET. 1. On the Background screen press the F1 (Exit to Commands) soft key. 2. On the Commands screen, cursor to TESTING/SETUP and then press the F4 (Status Display) soft key.
6. On the VistaNET Essential Addresses screen (see Figure 4-64), enter the GCC's identification number on the Name line. ******* VistaNET Essential Addresses ******* Name: [GCC10 Tag: GCC10 Board Address: 0.10 Domain 1: Domain 2: VNSA Address: 0.1.0.199 Router Address: 0.1.0.199 Exit Escape Update...
SOLENOID VALVES The PGC2000 uses two different types of solenoid valves in the Purge Air Panel, a vented type and a non-vented type (see Figure 4-65). Since these solenoids are not interchangeable, you must ensure that a replacement solenoid is the same type as the solenoid being replaced.
SECTION 5. MAINTENANCE PREVENTIVE MAINTENANCE The analyzer design eliminates the need for extensive and complex maintenance. Where preventive maintenance procedures require specific time frames or intervals, you should maintain an inspection log and inspection data. Figure 5-1 lists inspection routines, with recommended time intervals for each routine.
(100 psig or less). When your check indicates an exhausted cylinder, replace the cylinder with another containing the specified gas. When you use a single cylinder to supply a gas, you should check this cylinder regularly and replace it when the pressure falls below 100 psig, using another cylinder containing the specified gas. Cleaning Clean the analyzer as often as environmental conditions require.
2. On the Commands screen (see Figure 5-2), cursor down to TESTING/SETUP and then press the F2 (Diagnostic Tests) soft key. ***** COMMANDS ***** ANALYSIS CONTROL REPORTS TABLE EDIT PRINTER STORAGE & CONFIG. NAMES MISC. [TESTING/SETUP] CHROMATOGRAM STORAGE VISTANET Diagnostic Diagnostic Exit Tests...
4. When the test is complete, this message will appear on the screen: “ROM Check PASSED. Any key to continue.” Press any soft key to return to the Diagnostic Tests screen. If the ROM check fails, contact your service representative. 5.
4. On the Diagnostic Tests screen (see Figure 5-4), cursor to DIAGNOSTIC TOOLS and press the F2 (Digital Output Test) soft key. ***** Diagnostic Tests ***** DIAGNOSTIC TESTS [DIAGNOSTIC TOOLS] Digital Trend Exit Output Output Test Test Figure 5-4. DIAGNOSTIC TESTS SCREEN (TOOLS SELECTED) 5.
6. Cursor down to the line marked “Pin Number” and enter the desired Chroma I/O Board pin number. On the corresponding line below the pin number, the digital value will change from 0 to 1 or from 1 to 0. 7.
9. On the Manual Control of Trend Outputs screen (see Figure 5-6), select the trend channel you want to check. 10. Cursor down and enter the desired trend value. This value is a percentage of the total trend range. Check your output to verify the trend value changed. If it did not change, try a different value.
3. On the Serial Configuration screen (see Figure 5-7), verify that the setup data is the same as that specified in the Data Package. Serial Configuration Printer Setup Baud Rate: 300 1200 2400 4800 9600 Parity: None Even Odd Data Bits: Stop Bits: Exit Test...
4. On the Commands screen, cursor to STORAGE & CONFIG and then press the F4 (Update Digital Config) soft key. 5. On the first Digital Configuration screen, enter RESETDIGIO as the password and then press the F2 (Accept Entered Password) soft key. 6.
2. On the first Chroma Board 1 Digital Output screen, cursor to VistaII and press the F1 (Continue) soft key. 3. On the second Chroma Board 1 Digital Output screen (see Figure 5-9), verify each pin and function. ***** Chroma Board 1 Digital Output ***** Function Number State...
2. On the Digital Board 1 Digital Input screen (see Figure 5-10), verify each pin and function. ***** Digital Board 1 Digital Input ***** Function Number State TB6-1 VistaBasic TB6-2 VistaBasic TB6-3 VistaBasic TB6-4 VistaBasic TB6-5 VistaBasic TB6-6 VistaBasic TB6-7 VistaBasic TB6-8 VistaBasic More Below Exit...
2. On the Digital Board 1 Digital Output screen (see Figure 5-11), verify each pin and function. ***** Digital Board 1 Digital Output ***** Function Number State TB5-18 Stream TB5-19 Stream TB5-20 Stream TB5-21 Stream TB5-22 Stream TB5-23 Stream TB5-24 Stream TB5-25 Stream More Below Exit...
Trend and Detector 1. Cursor to Other on the second Digital Configuration screen and press the F2 (Trend & Detector) soft key. 2. On the Trend And Detector Config screen (see Figure 5-12), verify each trend setting and detector configuration. ***** Trend And Detector Config *****...
Page 170
2. On the screen with instructions on saving the tables, press any soft key. 3. On the Commands screen, cursor to STORAGE & CONFIG. and press the F2 (Save or Restore Tables) soft key. 4. On the Table Storage screen cursor to SAVE TABLES TO E2PROM and press the F2 (Save Tables) soft key.
SECTION 6. TROUBLESHOOTING TROUBLESHOOTING GUIDELINES This section provides troubleshooting information by category. Included in this information are symptoms, causes, and suggested tests for further fault isolation. These tests are described in Section 7, listed by Test Procedure (TP) number. BASELINE PROBLEMS Baseline or Signal Offset (TCD) Symptom: Baseline (detector signal) is continually offset to the positive or the negative with no short term drift up or down scale (see Figure 6-1).
8. A continuous presence of sample at the detector due to sample valve leakage. Perform Test Procedure 3 (Sample Valve Leaking/Column Flooding). 9. Filament failure. Perform Test Procedure 6 (Filament TCD Test). Cyclic Short Term Drift Symptom: Baseline (detector signal) is experiencing a cyclic short term drift (see Figure 6-2) indicated by detector signal, graphics display, or strip chart recorder (if used).
Perform Test Procedure 3 (Sample Valve Leaking/Column Flooding); or Test Procedure 30 (Checking Temperature Table Values), steps 1 to 3, 8, and 9. Another possible cause could be detector filament deterioration. Baseline Continuous Noise Symptom: Baseline (detector signal) with no sample injection appears as noise similar in appearance to “grass”...
b. The gases may be pure, but contaminated tubing or hardware components in the analyzer or cylinder regulator(s) contaminate the makeup gases as they pass through them. The FID detects theses contaminants, resulting in a noisy baseline. c. An FID is generally equipped with a catalytic air cleanup unit to remove hydrocarbon impurities from the burner air.
Perform Test Procedure 11 (Common Usage of Gases), Test Procedure 13 (Burner Air Catalytic Cleanup Unit), or Test Procedure 14 (Coaxial Cable), as applicable. Replace or clean the FID (see "FID REPAIR" in Section 8). Signal Offset (FPD) NOTE Because of the sulfur addition in the FPD detector, the FPD will always have a background level.
a. Electrical noise from the FPD amplifier could result from a noisy power supply or defective component of the PCB. b. Loose electrical connections can cause electrical signals to be sporadic. c. Since the FPD amplifier input impedances are extremely high, low noise coaxial cable connects the detector and the FID amplifier.
5. Baseline offset extreme. See "Baseline or Signal Offset (TCD)" or "Baseline or Signal Offset (FID)." 6. Column broken or connection in the column train disconnected. Perform Test Procedure 7 (Column Train Problems). 7. TCD Failure. Perform Test Procedure 5 (TC Detector Balance) and Test Procedure 6 (Filament TCD Test), as applicable.
Additional Peaks of Unknown Origin (Mystery Peaks) Symptom: Chromatograph displays extra peaks or a noted difference in composite chromatograph appearance from that of the calibration (see Figure 6-10). Unknown TIME TIME NORMAL MYSTERY PEAKS Figure 6-10. MYSTERY PEAKS Cause: If only present on calibration sample and not on process, verify that the correct calibration and proto fuel samples are being analyzed.
above the bubble point of the sample, the sample will bubble in the sample chamber, causing an inconsistent liquid fill of the sample loop. This results in a continuously variable sample size. A defective sample valve stem or leaking seal(s) can also cause nonrepeatability. Perform Test Procedure 20 (Variable Sample Size).
Cause: The gating in the method needs to be modified to ensure gating of the missing peak in the report. This can be done by modifying the gate ON/OFF time in the method table. See "PEAK DETECTION" in Section 4 for detailed instructions. Peak Inversion Symptom: The peaks on the strip chart recorder are reversed or negative (see Figure 6-13).
The peaks may in fact be too large and saturating the detector or column. The splitter may be out of adjustment, or the liquid sample size may be too large. Possibly the detector gain jumper at the detector electronics is not setup correctly. The sample valve may be injecting an excessively large sample volume due to deformation or a scratch in sample stem or worn seals.
Peak Discrimination Symptom: Discrimination is the non linear unequal dilution of hydrocarbons in the column train. Typically the heavier components will tend to dilute more than the lighter components. Cause: Discrimination is usually the result of a leak or incorrectly adjusted sample splitter. The leak or split might cause more of the heavier components to be exhausted out the splitter vent or leak exit than the lighter components;...
Any one of the following alarm messages or conditions could be present: On Background Screen ***ALARM:*** (flashing) On Manual Temperature Zone (3) (flashing) Control Mode Screen *Temp Bd Alarm* (flashing) On Alarm Screen Temperature Board: *Zone Specific *Analysis Shutdown *** TEMP ZONE (#) Alarm *** *Reasonableness Test *Probe Open/Shorted or TC Faulty *Low Temp...
Any one of the following alarm messages or conditions could be present: On Background Screen ***ALARM:*** (flashing) On Manual Temperature Zone (#) (flashing) Control Mode Screen *Temp Bd Alarm* (flashing) On Alarm Screen Temperature Board: *Zone Specific *Analysis Shutdown *** TEMP ZONE (#) Alarm *** *Overtemp *Reasonableness Test *Probe Open/Shorted or TC Faulty...
*Reasonableness Test If the T-Rating is in question, refer to final documentation provided with the chromatograph or contact the ABB Service Department. Remedy: The T-rating jumpers for Micro #1 and Micro #2 must be set up identically. Determine the correct setting and configure the jumpers for both identically.
INACTive in the software. Cause: The exclusion jumper is not set up correctly. Remedy: Select correct exclusion jumper configuration. If in doubt contact ABB Service Department. Oven Temperature is Greater Than T-Rating Symptom: The temperature board has been shut down. If the trouble is in Micro #1 then all LED’s are Off on the Temperature Control board and the zone temperature is greater than the T-Rating.
Any one of the following alarm messages or conditions could be present: On Background Screen ***ALARM:*** (flashing) On Manual Temperature Zone (#) (flashing) Control Mode Screen *Temp Bd Alarm* (flashing) On Alarm Screen Temperature Board: *Zone Specific *** TEMP ZONE (#) Alarm *** *Reasonableness Test Cause: Micros #1 and #2 disagree by more than 30 deg C.
Any one of the following alarm messages or conditions could be present: On Background Screen ***ALARM:*** (flashing) On Manual Temperature *Temp Bd Alarm* (flashing) Control Mode Screen On Alarm Screen Temperature Board: *Overtemp Test Fail* possible zone specific Triac failures Cause: Temperature control did not detect over-temperature condition when tested.
CAUTION See "AIR PURGING" in Section 4 for the override function. Do not perform override until you have read Section 4 completely and you understand and can perform the procedure requirements. Install a temperature monitor and verify ambient temperature. Ensure air flow into the Controller housing.
CAUTION See "AIR PURGING" in Section 4 for the override function. Do not perform override until you have read Section 4 completely and you understand and can perform the procedure requirements. The temperature controllers must be stable with respect to tracking the set point. Symptom: The actual temperature is not stabilizing at the set point temperature.
Low Oven Temperature CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
2. Air supply pressure is low. Verify correct air pressures. If necessary make adjustment. 3. Vortex cooler not adjusted. Perform Test Procedure 41 (Programmed Temperature Oven Cool Down). 4. Listen for cool down solenoid to operate and introduce increased vortex cooler air flow. If this does not happen, perform Test Procedure 41 (Programmed Temperature Oven Cool Down).
No Analyzer Keypad Response Symptom: Pressing keypad on analyzer front panel produces no response on CRT or other analyzer output. Cause: No response by keypad could indicate defective keypad or malfunction or defect in keypad cabling from keypad to keypad assembly PCB. The CRT Control PCB or associated wiring or connections may be defective.
6. Replace LOCOM PCB (set-up address switch). Symptom: Cannot contact or use remote networking feature. Cause: Previous remote communication was not terminated. 7. Search for analyzer that is accessing another remote, or that is itself being accessed, then terminate the access. See "REMOTE GC OPERATION OPTION"...
Low Carrier Pressure Hardware Alarm Symptom: Low carrier gas alarm. If carrier is in short supply and not corrected, carrier flow rates will reduce as the gas is depleted. Analyzer data will become erroneous as carrier pressure drops below the analyzer requirement. Causes: The following can be causes for low carrier pressure alarm.
Symptom: If X purge system is installed, analyzer power will be removed and cannot be restored until purge air is restored. Causes: The following can be the causes of loss of purge. 1. Air supply to analyzer has been shut off. Perform Test Procedure 1 (Carrier, Makeup, and Utility Gas Supplies).
Page 197
Cause: Possible causes for analyzer not powering up are as follows: 1. If attempting to Override X-Purge, light intensity may not be sufficient to energize Override, or cover to X-Purge electronics housing is not removed. 2. Power is disconnected. Check power distribution circuit breakers and local disconnect switch. (Watch for lock-out tag-out).
ELECTRONIC PRESSURE CONTROL TROUBLESHOOTING The Pressure Control Assembly (see Figure 6-15) requires special tools and equipment for repair. If you suspect a problem with this assembly please contact your ABB service representative. Figure 6-15. EPC PRESSURE CONTROL ASSEMBLY 6-28 2000-OSM, F1...
CONTROLLER PROBLEMS Input Power Input power is connected to one or more of the following locations on the Backplane PCB in the Controller Housing (see Figure 6-16): TB1, which is called VAC #1 J1A, which is called VAC #2 J1B, which is called VAC #3 1 2 3 4 5 6 1 2 3 4 5 6 Figure 6-16.
Power Distribution The analyzer uses three power distribution circuits to route the power (see Figure 6-17): VAC #1, which provides heater power VAC #2, which powers the electronics through the Power Supply PCB VAC #3, which power the detectors, solenoid drivers, and EPC 115 to 230 VAC Neut VAC #1...
When checking input power make sure to note the connections for source power to determine how power is routed. Poor Display Contrast If the analyzer is ON but it is difficult to read the LCD display, you may need to adjust the display. 1.
When an alarm signal appears on the Background Screen, press the F4 (Alarms) soft key to display the ALARMS screen with the alarm message (see Figure 6-19). ****** ALARMS ****** ****** ALARM ****** Post Analysis Error: *Valve Manually Switched Clear Exit Alarms and Exit...
Sensors Active When “Sensors Active:” appears as the main alarm, one or more sensor alarms appears below the main alarm. “Sensors Active” appears when an alarm is active at the time you look at the Alarms screen. Typical Sensors Active alarms and their descriptions are: NOTE Sensor Alarms 1 to 5 are application-specific alarms.
* Retention Time High—activates when retention time exceeds the upper setpoint. * Response Factor High—activates when response factor exceeds the upper setpoint. Component Low When “Component Low:” appears as the main alarm, one or more component alarms appears below the main alarm. Typical Component Low alarms and their descriptions are: * Component Low Low—activates when a component is below "low low"...
* Auto Zero During Slope Detect—activates when auto zero is performed during slope detection. * Gated During Noise—activates when slope detection is turned on at the same time that a noise calculation is being performed. * Gated During Slope Detect—activates when slope detection is turned on at the same time as a peak is being force gated.
Communications Error When “Communications Error:” appears as the main alarm, one or more communications alarms appears below the main alarm. Typical communication alarms and their description are: * Block not transmitted—activates when a VistaNET message is passed to the Communication PCB and no acknowledgement is received.
* Set Point Failed—activates when Zone is inactive; zone is SWITCH zone and switch not depressed or set point is greater than the configured pressure range. * Ramp Rate Failed—activates when the ramp rate settings exceed an acceptable range. * Reconfiguration Failed—activates when switch not depressed. * High Alarm—activates when the maximum pressure limit set in configuration is too low.
Page 208
* Analysis Shutdown—activates when the Temperature Board alarm has signaled the SBC with information that will be used to determine whether to abort the analysis. If the “*Zone Specific” subordinate alarm appears, at least two additional lines appear below that. The first line identifies which zone produced the alarm and the second line identifies the specific alarm condition.
Raw Chromatogram Storage When “Raw Chromatogram Storage:” appears as the main alarm, one or more chromatogram alarms appears below the main alarm. Typical chromatogram alarms and their descriptions are: * Memory Below 20%—activates when the memory pool used for chromatogram storage is below 20%.
Page 210
• not report the alarm to VistaREPORTER (if the GC is configured to send reports to VistaREPORTER); • not report the alarm to the printer (if the GC is configured to send reports to a printer); • report the alarm to the OPC Server (if the GC is configured to send reports to the OPC Server). The purpose of the Indicate setting is not to invalidate the data but to notify the control system that the event has occurred.
3. On the Control Parameters screen (see Figure 6-20), press the F3 (Alarm Mask) soft key. ***** Control Parameters ***** Analyzer Name: [ABB Analytical GCC Unknown Peak Alarm: Missing Comp Alarm: Update Trends on Alarm: Auto Update of RF: Max RF Variation: 0.000000...
6. If the selected alarm has "(Expanded)" after the alarm name, the alarm has subordinate indicators. To view these subordinates, cursor to the desired alarm line and press the F2 (Expand Mask) soft key. 7. On the expanded alarm screen, repeat steps 4 and 5 to change a specific alarm's output. 8.
3. On the Control Parameters screen (see Figure 6-23), press the F4 (Common Digital Out. Mask) soft key. ***** Control Parameters ***** Analyzer Name: [ABB Analytical GCC Unknown Peak Alarm: Missing Comp Alarm: Update Trends on Alarm: Auto Update of RF: Max RF Variation: 0.000000...
4. On the Common DO Mask, Main screen (see Figure 6-24), cursor down to the desired alarm name and verify the selection in the right-hand column. ***** Common DO Mask, Main ***** Active Sensors: (Expand) Common DO Component High: Common DO Component Low: Common DO Hardware:...
SECTION 7. TEST PROCEDURES TP 1: CARRIER, MAKEUP AND UTILITY GAS SUPPLIES If you suspect a gas supply (flame, fuel, air) problem, perform the following test. 1. Stop Analysis at end of current analysis, and make no sample injection until procedure is completed.
CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
4. Leak check every connection outside the analyzer on the entire carrier flow path. Perform step 5 only after step 4 has been completed and all leaks are repaired. 5. Loosen inlet fitting nut and check for presence of carrier or makeup gas using a leak detector solution.
CAUTION See "AIR PURGING" in Section 4 for the override function. Do not perform override until you have read Section 4 completely and you understand and can perform the procedure requirements. 1. Stop Analysis at the end of the current analysis cycle, and make no sample injection until procedure is completed.
1. Stop Analysis at the end of the analysis and make no sample injection until procedure is completed. 2. Reduce isothermal and programmed temperature oven air temperatures by reducing oven air pressures to zero psig. 3. Open Isothermal oven. 4. Inspect for disconnected or loose tubing connections or broken column in the column train from the carrier regulator outlet to the column vent.
2. Perform Test Procedure 30 (Checking Temperature Table Values) and Test Procedure 9 (Baseline Cyclic Carrier Regulator), as applicable. TP 11: COMMON USAGE OF GASES 1. Are other analyzers serviced from the same burner air, carrier, or burner fuel source, experiencing noise? If Yes, then the noise problem is most likely related to a common utility gas, tubing, fitting, or regulator.
2. Gently move or touch coaxial cable, while monitoring detector output on recorder. Some movement of signal is normal, but spikes of noise should not occur. 3. If noise spikes are systematically generated, check the coaxial cable connections. 4. If the connections are correct and tight, replace coaxial cable. TP 15: FID REDUCED SENSITIVITY CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard-...
TP 16: FID WILL NOT LIGHT CAUTION Do not ignite the FID flame if the temperature is below operational level. Low oven temperature will result in condensation damage to the flame cell. 1. Ensure burner air and burner fuel are adjusted to the values shown on application data sheets. 2.
1. Disconnect the cell vent and hold a reflective surface such as a mirror, wrench or other suitable object at such an angle that you can see the reflective surface. 2. If the flame is ignited, you will be able to see the condensed water vapor form on the reflective surface.
14. Remove power and disconnect the cable between J9A and J9. Check continuity between J9A terminals 1, 2, and 3 and J9 terminals 1, 2, and 3, respectively. If any wires are open replace the cable, apply power and repeat step 11. 15.
4. Compare the temperature zone temperatures with those of your application data sheets sent with your chromatograph. Perform Test Procedure 30 (Checking Temperature Table Values) and make any necessary table corrections. Bubbles at the sample valve effluent generally indicate the sample temperature is above the bubble point of the sample. Carrier gas displacement of sample stem groove volume may be occurring due to leaking valve seals, causing varying sample size.
Temperature J48A Zone Board Terminals Assignment 4 & 5 Isothermal Oven 4 & 5 Programmed Temperature Oven 4 & 5 4 & 5 Detector 4 & 5 Methanizer/Air Cleanup 5. If temperature probe is open, replace the temperature probe. 6. Close and tighten the Controller side door. TP 22: SHORTED TEMPERATURE SENSOR CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard-...
CAUTION See "AIR PURGING" in Section 4 for the override function. Do not perform override until you have read Section 4 completely and you understand and can perform the procedure requirements. 1. Disconnect power and shut off air to analyzer. 2.
TP 24: ISOTHERMAL OVEN OVERTEMP SENSOR OPEN CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
extremely high, the RTD is open. Replace the RTD. The respective probes may be tested at the locations given below: Temperature J49A Zone Board Terminals Assignment 4 & 5 Isothermal Oven 4 & 5 Programmed Temperature Oven 4 & 5 4 &...
9. Close and tighten the Controller side door. TP 27: OPEN FUSE TO AC CONDITIONING BOARD CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
4. Connect a DC voltmeter from Detector Amplifier TB16 terminal 5 to chassis ground. The meter should indicate -110 volts DC. If voltage is -110 VDC, Test Procedure 29 is complete. If the voltage is less than -110 VDC continue with step 5. 5.
1. Stop Analysis at the end of analysis cycle and make no sample injections until procedure is completed. 2. Perform Test Procedure 1 (Carrier, Makeup, and Utility Gas Supplies) and Test Procedure 2 (Carrier and Makeup Gas Flow Adjustments), if not previously checked. 3.
1. Press the F1 soft key until the Background screen is displayed (see Figure 7-3). ********** B A C K G R O U N D ********** ABB Analytical GCC Remote 0.1 803V029-1R (Std GCC) (C) 2001 **ALARM**...
5. Press the F3 (Names and Limits) soft key to view the 5 Zone Names and Limits Table screen (see Figure 7-6). This table is factory set and is NOT intended to be field modified. In the unlikely event that one of the parameters was changed, the values should be compared to those in the table listing provided with the analyzer.
9. On the Pressure and Temperature Control screen (Figure 7-5), cursor up or down until TEMP CONTROL is highlighted. Press the F2 (Manual Temp Control) soft key to access the Manual Temperature Control Mode screen (see Figure 7-7). **** Manual Temperature Control Mode **** Zone Config...
14. On the Commands screen(see Figure 7-8), cursor up or down to highlight TABLE EDIT. Then press the F2 (Methods) soft key to access the methods tables. ****** COMMANDS ****** ANALYSIS CONTROL REPORTS TABLE EDIT PRINTER STORAGE & CONFIG. NAMES MISC.
17. Move the cursor up or down to highlight the time associated with Temperature Control Function Two. Then move the cursor to the right to highlight the value “Two”. The Temperature Control screen appears (see Figure 7-10). ***** Temperature Control ***** Entry Zone Set Point Ramp Rate...
3. Extinguish flame by reducing burner air, fuel and carrier to zero by rotating regulator adjustment counterclockwise until burner air fuel and carrier gauges indicate zero. When flame is out, the “Flame Out” LED will illuminate. 4. Connect flow meter (e.g. bubble tower) to FID vent. 5.
Verify the method configuration tables as follows: 1. Press the F1 soft key until the Background screen is displayed (see Figure 7-11). ********** B A C K G R O U N D ********** ABB Analytical GCC Remote 0.1 803V029-1R (Std GCC) (C) 2001 **ALARM**...
3. On the Commands screen (see Figure 7-12) cursor to highlight TABLE EDIT. Then press the F2 (Methods) soft key. ****** COMMANDS ****** ANALYSIS CONTROL REPORTS TABLE EDIT PRINTER STORAGE & CONFIG. NAMES MISC. TESTING/SETUP SIM DISTILLATION Go to Other Background Methods Tables...
Page 242
6. Refer to the table listings provided with your chromatograph. The function scheduling should be similar to the following: PROCESS STREAM METHOD TABLE Method Table #01 Time Function Value 0001 Temp. Contrl 0128 Auto Zero N/A 0130 Skp, Nxt,Str= Nine 0132 Valve On 0155...
Page 243
CALIBRATION STREAM METHOD TABLE Method Table #10 Time Function Value 0001 Temp. Contrl 0120 Noise Calc On 0125 Noise Calc Off 0128 Auto Zero N/A 0132 Valve On 0155 Valve Off 0160 Slope Detect On Now 0160 Peak Width Eight 0175 Component One 0175...
0120 Noise Calc 0125 Noise Calc This function samples the baseline to determine the random noise level of the baseline and is applicable only to slope detection. 0128 Auto Zero This function establishes a baseline zero reference point in the controller. It in effect compensates for the detector offset from electrical zero.
TP 35: PRINTER TEST 1. On the Background screen, press the F1 (Exit to Commands) soft key. 2. Cursor to PRINTER and then press the F2 (Test Printer) soft key. A string of characters should print. 3. If characters do not print, cursor to TESTING/SETUP and then press the F3 (Hardware Setup) soft key.
Page 246
1. Remove power from analyzer. 2. Remove access cover to terminals on right hand side of electronics housing. 3. Verify if trend board output is set up for 4 to 20 ma or 0 to 5 VDC. 4. If current output, disconnect one wire from the output to be tested, and place the milliammeter in series with the load.
a. With authorized permission, remove one wire from input device of loop to be tested and connect the ammeter in series (voltage parallel). Perform step 9 to determine if loop wiring to input device is functional. b. Check and verify input device input requirement and configuration. c.
3. Disconnect oven carrier pressure switch at J23A terminals 1 and 2. 4. Connect ohmmeter leads between the two wires previously disconnected from J23A terminals 1 and 2. 5. Apply carrier pressure of at least 80 psi. 6. The switch contacts should close. Remove carrier pressure; switch contacts should open. 7.
Page 249
2. Check air pressure for correct adjustment. Perform Test Procedure 1 (Carrier, Makeup, and Utility Gas Supplies). 3. Check all temperature control parameters. Perform Test Procedure 30 (Checking Temperature Table Values), and correct any errors. 4. Access the Manual Temperature Control Mode by performing steps 1 to 3, 8 and 9 of Test Procedure 30 (Checking Temperature Table Values).
20. Check vortex cooler efficiency as follows. Access the Manual Temperature Control Mode by performing steps 1 to 3, 8 and 9 of Test Procedure 30 (Checking Temperature Table Values). Change zone 2 set point to 0 deg and rate to 0.1. 21.
9. Loosen the four screws that retain the front cover of the heater box. 10. Request an analysis for the stream in question. At stream step the stream will begin to purge as indicated on the background screen. Connect voltmeter leads across the stream switch soleniod valve (process) or the calibration solenoid valve (calibration).
NOTE If the Photomultiplier Tube has very high gain, the reading of step 5 might not be adjustable to a value less than 80 mV. TP 44: FPD FLAME WILL NOT LIGHT CAUTION Do not ignite the FPD flame if the temperature is below operational level. Low detector temperature will result in condensation damage to the flame cell.
TP 45: “FLAME OUT” LED REMAINS ON AFTER FPD FLAME IGNITION CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
Page 254
11. Connect an ohmmeter between the two thermocouple leads. The ohmmeter reading should indicate continuity. If it does not, the thermocouple is open. Replace the thermocouple (see “FID REPAIR/Replacing the Thermocouple Assembly” in Section 8). 12. Connect the ohmmeter between one of the thermocouple leads and chassis ground. The resistance should be high.
SECTION 8. REPAIR REPLACING HEATERS Refer to Figure 8-1 for component location when replacing heaters. Temperature Sensor Detector Thermocouple Liquid Sample Methanizer Valve Oven Heater Column Figure 8-1. ANALYZER OVEN COMPARTMENT CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open.
9. Connect the wires from the new heater assembly to the feeder wire pulled through the tubing. 10. Install the new heater assembly using the reverse procedure, pulling the wires through the tubing. Sample Valve Heater WARNING Sample will spill or leak out during this procedure. Consult MSDS sheets on file at your location for safety requirements.
SAMPLE VALVE REPAIR The Liquid Sample Valve (LSV) utilizes two different connection methods for the sample lines. Earlier analyzers had these sample lines connected directly to the LSV, as shown in Figure 8-2. Putting a loop in the tubing or using flexible hose reduces any sideways force at the connection.
Page 258
It is also important to use two wrenches when tightening the sample line connections to the sample chamber. One wrench must be used to back up the force applied to tighten the fitting (direct wrench force will bend the stem). WARNING Sample will spill or leak out during this procedure.
Disassembly on the Analyzer See Figure 8-4 for typical sample valve component location. Figure 8-4. LIQUID SAMPLE VALVE COMPONENT LOCATION 1. Stop the analysis at the end of a cycle. 2. Turn off power, carrier, sample, and air to the analyzer. 3.
Reassembly on the Analyzer NOTE In all steps the lubricant used is High Vacuum Grease, ABB part number 006904-1. 1. Clean the seals with acetone and air dry them. 2. Clean the sample chamber with acetone and air dry it.
10. Lightly lubricate the body O-rings. 11. Install the body O-rings onto the body and the piston. 12. Insert the piston and the piston rod into the sleeve, being careful not to cut the O-ring. Fully insert the piston until it contacts the stops. 13.
25. The sample chamber should be loose in the assembly at this point. If not, back out the sleeve until the sample chamber is loose. Use the end of a 0.156 Allen wrench in the slot of the sleeve to adjust to the point of eliminating the longitudinal play of the sample chamber. 26.
11. Separate the vaporizer assembly from the vaporizer chamber. 12. Remove the LSV to the workbench. Disassembly on the Workbench See Figure 8-6 for typical sample valve component location. Figure 8-6. LIQUID SAMPLE VALVE COMPONENT LOCATION 1. Perform “Removing the LSV from the Analyzer.” 2.
Reassembly on the Workbench NOTE In all steps the lubricant used is High Vacuum Grease, ABB part number 006904-1. 1. Clean the seals with acetone and air dry them. 2. Clean the sample chamber with acetone and air dry it.
13. Stack the 15 Belleville springs onto the 1/4-inch thin wall plastic tubing, as shown in Figure 8-7. Figure 8-7. STACKING THE BELLEVILLE SPRINGS 14. Using the tubing only as a guide, slide the Belleville springs over the stem into the bore of the body.
30. Install two cone point set screws into the cylinder and tighten into the groove on the body. 31. Perform “Installing an LSV on the Analyzer.” Installing the LSV on the Analyzer 1. Open the isothermal oven door. 2. Install the vaporizer assembly around the vaporizer chamber. 3.
14. Remove the insulation cover from the vaporizer assembly. 15. Remove the insulation from around the vaporizer assembly. 16. Remove the four bolts fastening the two parts of the vaporizer assembly. 17. Remove the two parts of the vaporizer assembly. 18.
7. Allow zone temperatures to stabilize. 8. Check and adjust carrier and makeup gases flow rates. 9. Ignite FID (if applicable). Capillary Column Installation 1. Inspect the ends of the column. The ends should be round and burr free. If either column end is not round or burr free, the column end must be trimmed as described in "Cutting Capillary Columns."...
NOTE Do not use high speed cutting wheels or grinders to cut capillary columns. This type of cutting generates heat that can damage the column and the resultant column cuttings could plug the column. 1. Use a diamond or ceramic scoring tool to score the surface of the outside tubing wall approximately one inch from the end of the column.
FID Cell Access CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
9. Install the detector outlet adapter into the breather and finger tighten. Finish tightening using 3/4- inch and 1/2-inch open-end wrenches. 10. Install the 1/4-inch male connector into the breather using 3/4-inch and 1/2-inch open-end wrenches. 11. Connect the 1/4-inch detector vent tubing to the breather. Finger tighten, then tighten with a 9/16-inch open-end wrench and a 1/2-inch backup wrench.
15. Slide the heat shrink over the soldered connection and shrink it with a heat gun. 16. Reconnect the red coaxial cable to the top of the detector. 17. Close and secure the isothermal oven door. Accessing the Polarizer and Ignitor Elements 1.
9. Spread or expand the end of approved heat shrink to allow easy installation over the solder connection. 10. Install heat shrink over each wire and slide it as far as possible from the connection. This will prevent premature shrinking when the connection is soldered. 11.
2. Route the wiring up through the top of the detector housing . NOTE Steps 3 through 6 are required only for Temperature Programmed analyzers. 3. Slide the housing down over the insulation and detector body onto the base. The housing must slide over the circular base and rest on the mounting bracket.
8. Extract the jet with the adapter fitting from the jet cavity in the detector. 9. Inspect the end of the jet for damage. It should not be pitted or plugged. If pitted, replace with a new jet. 10. Insert a 0.016-inch diameter piano wire into the jet and rod it out. If the piano wire will not pass through, replace the jet.
11. Close and secure the isothermal oven door. Replacing the FID Cable Assembly NOTE This procedure requires a special tool, Insertion Tool ABB P/N TL799M013-1, to assist in passing the cable through the insulation between the Control Housing and the Oven.
FILAMENT TCD REPAIR Refer to Figure 8-10 for Filament Thermal Conductivity Detector (TCD) component location. Measure Filament Reference Filament Reference Vent Sample In Sample Vent TC Assembly Reference In Figure 8-10. FILAMENT TC DETECTOR CAUTION This repair should only be attempted by people who are properly trained and possess the expertise for this repair.
2. Remove the mounting bracket cover by sliding it out and away from the detector assembly. 3. Remove the insulating material from the mounting bracket. 4. If they are not already labeled, label the wire pair connected to the measurement filament “M” and the wire pair connected to the reference filament “R”.
Filament Checkout 1. Obtain a multimeter and select the ohms function and a range capable of measuring 40 ohms. 2. Connect one multimeter lead to each wire of the measurement filament (installed in the detector cavity labeled “M”). The resistance measurement should be approximately 40 ohms. 3.
5. Slide the insulating sheath of each filament back to reveal the stranded wire, install approved heat shrink over each of the four filament wires, and slide it as far from the free wire end as possible. 6. Select a harness assembly wire with the “R” label designation and overlap the “tinned” ends of this harness wire with one of the reference filament wires.
8. Install the mounting bracket cover and secure it with two Phillips head screws. 9. Close and secure the isothermal oven door. THERMISTOR TCD REPAIR Refer to Figure 8-11 for Thermistor Thermal Conductivity Detector (TCD) component location. Top Cover Cable Standoffs Top Sleeve Measure...
3. Open the isothermal oven door. Removing the Thermistors 1. Use a Phillips screwdriver to loosen the two Phillips head screws located on the top cover. 2. Remove the top cover by sliding it out and away from the detector assembly. 3.
2. Connect one multimeter lead to each wire of the measurement thermistor (installed in the detector cavity labeled “M”). The resistance measurement should be approximately 40 ohms. 3. Connect one multimeter lead to each wire of the reference thermistor (installed in the detector cavity labeled “R”).
6. Select a harness assembly wire with the “R” label designation and overlap the “tinned” ends of this harness wire with one of the reference thermistor wires. 7. Solder the wires using a 40 watt soldering iron and approved high temperature solder. Apply solder sparingly, allowing it to flow evenly.
Replacing the Photomultiplier Assembly Refer to Figure 8-12 as you perform this procedure. FPD Electrometer (in Controller Housing) Electrometer Cables Cables Nuts Nuts Photomultiplier Photomultiplier Early Version Current Version FPD Electrometer in Controller Housing FPD Electrometer in FPD Enclosure Box Figure 8-12.
Replacing the Burner Block Refer to Figure 8-13 as you perform this procedure. Heater Vent Line Mounting Screws Thermocouple Sample Temp Sensor (804A005-3 only) H2 and/or Carrier Thermocouple Heater Sulfur Addition Wafer Figure 8-13. BURNER BLOCK 1. Remove power from the analyzer. 2.
Replacing the Burner Block O-Rings Refer to Figure 8-14 when performing this procedure. 1. Perform steps 1 through 4 of "Replacing the Burner Block." 2. To remove a particular O-Ring, carefully remove the associated connector and then remove the O-Ring. O-Ring O-Ring 45051-4-106...
5. Carefully install and tighten the Electrode Nut. METHANIZER/AIR CLEANUP REPAIR CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open. This responsibility includes ensuring adequate ventilation in analyzer shelter and obtaining proper work permits, etc.
Refer to Figure 8-16 for Methanizer/Air Cleanup Assembly component location. Removing the Methanizer/Air Cleanup Assembly 1. Remove power from the analyzer. 2. Turn off oven air to the isothermal oven and allow all temperature zones to cool. 3. Turn off air supply to air cleanup unit. 4.
CAUTION Wait 30 minutes before proceeding to open the Methanizer/Air Cleanup Assembly. 11. Mark the top and bottom caps and housing with a grease pencil or permanent marker. When the caps are replaced with the marks aligned, the support bracket holes will be correctly aligned. 12.
8. Bend and position the coiled tubing such that the end fitting can be inserted into the corresponding air or methanizer outlet connection port located on the bottom of the top cap. 9. Tighten all inside catalytic tube inlet and outlet fittings, using a 1/4-inch open-end wrench. Packing the Housing 1.
8. Connect the temperature sensor wires to terminals 1 through 6, as follows: Overtemp Thermocouple: yellow (+) to 1 Overtemp Thermocouple: red (-) to 2 RTD sensor: 4 and 5 Shield (individual): Composite Shield: 9. Close and secure the isothermal oven door, and the Controller front and side doors. Air Cleanup Testing 1.
2. After sufficient air purge time and when authorized by your safety administrator, apply power to the analyzer. 3. Verify that all Digital Temperature Control setpoint values are correct. Refer to the engineering data package supplied with your analyzer for the correct values. 4.
4. In the isothermal oven, remove tubing connections as shown in Figure 8-18. (4) Remove tubing connections (2) unscrew feedthroughs Figure 8-18. FRONT RIGHT SIDE OF OVEN 5. In the isothermal oven, unscrew the feedthroughs (see Figure 8-18) and pull them down approximately 0.5 inches;...
11. Carefully remove the Carrier Gas Panel. Replacing a Regulator 1. Remove the Carrier Gas Panel from the analyzer. 2. Disconnect the lines from the back of the regulator. 3. Remove the regulator adjusting knob. 4. Remove the nut securing the regulator to the panel. 5.
4. In the Control Housing access area, screw the alarm switches into the manifold (see Figure 8-19) and plug the wire harness into their original locations on the mother board. 5. In the isothermal oven, reinstall the feedthroughs (see Figure 8-18). 6.
Removing the EPC Control Assembly CAUTION Be sure that the EPC Control Assembly has cooled to ambient temperature (approximately one hour) before proceeding. Perform the “Preparation” procedure. 2. Open the Control Housing access panel. 3. Remove the two screws holding the EPC cover and remove the cover panel. 4.
14. In the Control Housing access area, remove the plugs from the manifold. 15. In the Control Housing access area, remove the five screws from the manifold. 16. On the right side of the analyzer, remove the screw on the side of the EPC Control Assembly.
2. Remove the two screws holding the EPC cover and remove the cover panel. 3. Remove the ten screws holding the EPC Control Assembly cover using ABB Tool TL1009 and remove the cover. Be careful not to damage the flame-proof or explosion- proof surfaces of the cover or the body of the Control Assembly.
5. Locate the Sensor PCB to be replaced. NOTE There are two types of Sensor PCBs: a square PCB assembly (old type) and PCB assembly that is at right angles to the sensor (new type). 6. Unplug the Sensor PCB from the Controller PCB. 7.
7. Tighten one screw, using torque limiting screwdriver ABB Tool 801Z003-1, set at 1 in.-oz. 8. Tighten the second screw to 2 in.-oz. 9. Retighten the first screw to 3 in.-oz. 10. Retighten the second screw to 4 in.-oz 11. Retighten the first screw to 5 in.-oz.
You may need to remove the Sensor PCB cable from the Control PCB to allow access to the connector of some zones. 7. Using 3 mm hex socket wrench ABB Tool TL1009, remove the screws and washers that secure the valve in place.
3. Align RTDs with the holes in the enclosure and ensure the RTDs are inserted in the holes flush with the enclosure. 4. Using 2.5 mm hex socket wrench ABB Tool TL1007, attach the Control PCB to the enclosure with four screws and washers.
3. Remove the ten screws holding the EPC Control Assembly cover using ABB Tool TL1009 and remove the cover. Be careful not to damage the flame-proof or explosion- proof surfaces of the cover or the body of the Control Assembly.
3. Eliminate any back pressure to the zone by loosening the feedthrough fitting associated with the zone to be calibrated (see Figure 8-23). Figure 8-23. LOCATION OF ZONE FITTINGS 4. On the Controller, verify the Background screen is displayed and then press the F2 (Manual Control) soft key.
6. On the Pres and Temp Control screen (see Figure 8-24), cursor to PRES CONTROL and press the F2 (Manual Pressure Control ) soft key. ***** Pres and Temp Control ***** TEMP CONTROL PRES CONTROL TEMP CONFIGURATION Manual Pressure View Escape Pressure Config...
8. Press the F3 (Calibrate Zone) soft key. The GCC displays “Calibrate zone, hold switch on board.” 9. Hold down the switch on the EPC Multibus PCB. The GCC displays “Are You Sure?” 10. Continue holding down the switch and press “Y” on the keyboard to save the new calibration. 11.
8. Install the sealing gasket and fasten the nut securing the regulator to the panel. 9. Install the adjusting knob on the regulator. 10. Reinstall the lines on the back of the regulator. 11. Install the Purge Air Panel in the analyzer. Replacing a Gauge 1.
Backplane PCB The Controller Backplane PCB has six jumpers to set up (see Figure 8-27). Figure 8-27. BACKPLANE PCB JUMPER LOCATIONS Jumpers JP1 and JP5 are used to bypass pressure switch connection points for certain analyzer configurations. Since the purge switches are daisy chained in series, it is necessary to jumper across switches that are not connected.
• Revision E or later: the shunt goes between pins 1 and 2 for normal operation (a Chroma I/O PCB dedicated to a single detector amplifier); the shunt is installed between pins 2 and 3 when the outputs of two detector amplifiers are applied to a single Chroma I/O PCB. DTC Backplane PCB The Digital Temperature Controller (DTC) PCB has eight jumpers and one switch to set up (see Figure 8-28 for location).
JP1 is the service diagnostics jumper. For normal operation the shunt is installed between pins 1 and 2. For service diagnostic screen use (only) the shunt is installed between pins 2 and 3. After servicing, the shunt must be reinstalled between pins 1 and 2. JP4 is the VAC Conditioning Board jumper.
VAC Conditioning PCB There can be either one or two VAC Conditioning PCBs, depending on the application. Each board has two jumpers to be set, JP4 and JP5 (see Figure 8-30). These jumpers are set according to the voltage supplied to the board, as follows (JP4 is the hot side and JP5 is the neutral side): Applied Voltage JP4 Shunt JP5 Shunt...
FID Amplifier PCB The jumper on this PCB relates to intercolumn detector usage. For normal operation shunts should be installed in the first two positions at the right side of J18. These shunts are removed for an application using intercolumn detectors (see Figure 8-32). Figure 8-32.
The carrier jumper is normally connected between WT9 and WT10 (single carrier). For dual carrier applications this jumper is connected between WT7 and WT8. The temperature jumpers are normally connected between WT1 and WT2 and between WT4 and WT5 (low temperature). For high temperature applications these jumpers are connected between WT1 and WT3 and between WT4 and WT6.
EPC Multibus PCB This board has one jumper and one switch to set up (see Figure 8-35). JP1 is the service diagnostics jumper. For normal operation the shunt is installed between pins 1 and 2. For installation and service the shunt is installed between pins 2 and 3. After installation or service, the shunt must be reinstalled between pins 1 and 2.
Chroma I/O PCB (old type) CAUTION This board can only be used when the analyzer also has the old type Single Board Computer PCB (identified by a toggle Reset switch). This board, part number 3528515-2, has two jumpers which are mutually exclusive. When there is only one Chroma I/O PCB in the analyzer, or the board is used as Chroma I/O PCB #1 in a simultaneous dual detector analyzer, the jumper will be located between the terminals of JP1 (see Figure 8-37).
JP1: When there is only one Chroma I/O PCB in the analyzer, or the board is used as Chroma I/O PCB #1 in a simultaneous dual detector analyzer, the shunt is installed between pins 1 and 2. When the board is used as Chroma I/O PCB #2, the shunt is installed between pins 2 and 3. JP2 through JP6: These jumpers are installed between pins 2 and 3 on the Chroma I/O PCB (later revisions of this board will have the jumpers hard-wired).
3. Using a 9/64-inch hex key wrench, remove the screw from the valve cap (see Figure 8-41). Figure 8-41. EXPLODED VIEW OF VALCO DIAPHRAGM VALVE 4. Carefully remove the valve cap from the two alignment pins. 5. Set the cap aside, with the polished side up so that it does not get scratched. 6.
The VistaNET Communications Board has a connector that allows a serial cable to be connected to the board. ABB Aftermarket Spares can provide this cable (P/N 3617695-1). The RS-232 communications protocol allows the use of a laptop PC for access. Included in Windows 95 is the Hillgraeve HyperTerminal Application, which emulates several popular devices.
Startup When you have set up the terminal application and connected to the communications board, press <CTRL> A to invoke the Main Menu (see Figure 8-43). Vistanet Debugger - HyperTerminal File Edit View Cell Transfer Help VistaNet Monitor Firmware Rev 803V025-1CH IRQ: 5 Adapter Segment: C800H Dump Memory...
Menu Items Dump Memory: Entered as DM XXXX where XXXX is the hexadecimal address to be examined. Memory is dumped by screen. Pressing the Enter key will scroll to the next block. The Escape key aborts the command. Figure 8-44 illustrates this screen. Vistanet Debugger - HyperTerminal File Edit...
Show Registers: Entered as SR (see Figure 8-45). The internal register contents of the 80C152 microcontroller are shown. Refer to the manufacturer’s data sheet for an explanation of the contents. Type MM to return to the Main Menu. Ignore Token: Entered as IT, used for software loading tests. In this mode, the communications board remains part of the token bus, however tokens are merely passed, and no UDP packets are transmitted or received at this node.
CAUTION The Dump History command is rather invasive, and may cause this station to drop tokens. Dump History: Entered as DH, the history buffer maintained at this node is displayed (see Figure 8- 46). Displayed are the source addresses of the last 255 stations to send a token on the wire. Note that the address of the station displaying this buffer is not seen.
Page 324
Retries: Number of UDP transmissions retried. Under normal conditions, such as a station off-line, this will be exactly twice the number of Transmit Errors. Collisions: Number of times this station has detected a loss of transmission on the wire due to collision with another station or overcome by noise.
Page 325
General Statistics Address: This station’s wire address. Mode: Indicates the Software State of this station. These conditions are additive, bits encoded as follows: 1. Receive Request Pending - A UDP packet has been received and needs processing. 2. Receive Buffer Needed - The receiver buffer pool is full. When one is available, re-enable the receiver.
DUAL AIR CLEANUP REPAIR The Dual Air Cleanup Assembly appears in analyzers having two detectors. Refer to Figure 8-47 for Dual Air Cleanup Assembly component location. Harness Assembly Air Cleanup Air Cleanup Tube #2 Tube #1 Figure 8-47. DUAL AIR CLEANUP ASSEMBLY CAUTION It is the customer’s responsibility to ensure that the area is safe and and hazard- free, and will remain so the entire time the analyzer is open.
2. Turn off oven air to the isothermal oven and allow all temperature zones to cool. 3. Turn off air supply to air cleanup unit. 4. Open the isothermal oven door. 5. Label the tubing on both sides of the associated unions with temporary numbered tape labels. The labels are later used to ensure correct tubing connections when the air cleanup is reinstalled.
Installing the Air Cleanup Tubes 1. To install an air cleanup tube, insert the short end of the catalytic air tube through the larger tube passage of the body and align it with the inside air inlet port connection of the top cap. 2.
2. Connect the tube connections to their respective reducing unions while matching the numbers on the temporary labels. 3. Remove the temporary tape labels. 4. Apply carrier and air to the air cleanup assembly. 5. Using a liquid leak detection solution, test for leaks and make necessary repairs before proceeding.
11. The temperature of the air cleanup assembly can also be monitored from this screen. The time required to achieve stability is two hours. 12. Press the F1 soft key as necessary to return to the Background screen. Air Cleanup Final Preparation 1.
CAUTION See “AIR PURGING” in Section 4 for the X Purge override function. Do not perform override until you have read Section 4 completely and you understand and can perform the procedure properly. NOTE To ensure the integrity of the components within the CP Valve, use the tools in CP Valve Tool Kit 754K003-1 when assembling or disassembling the CP Valve.
Replacing the Wedges The four wedges (part number 3527279-1), located on the Carrier Assembly, center the Valve Plate on the Carrier Assembly. To replace the wedges: 1. Perform the "Preparation and Safety" procedure. 2. Open both Carrier Assembly latches by pulling down on the end of the latches. 3.
Replacing the O-Rings Since the o-rings are inside the valve, you will have to remove the Valve Body from the analyzer. The o-rings come in a kit, with different kits for 40-psig and 60-psig CP valves (see Figure 8-49). The rework procedure is the same for both valves.
12. Wipe all surfaces of the piston and piston rod to remove contamination. 13. Verify that the screw holding the piston rod to the piston is tight. 14. Lubricate one o-ring part number 45051-4-11 with Molykote 33. 15. Position O-Ring Tool part number 3122-1 over the piston rod (see Figure 8-50). PISTON SCREW PISTON O-RING...
Page 335
23. Insert the piston and piston rod into the Valve Body. Before seating the piston, ensure the flat surface on the piston rod is facing up. 24. Insert the Carrier Assembly into the Valve Plate. 25. Close the back Carrier Assembly latch. This ensures the Carrier Assembly is locked into the hole in the piston stem.
Equipment Identification The following information, found in the Data Package and on the analyzer nameplate, should be included in any communication concerning replacement parts or components: • ABB Sales Order Number. • Analyzer Model Number. • Analyzer Part Number (P/N) and serial number.
Software Configuration Identification The software configuration appears at the top of the Background screen just below "ABB Analytical GCC." In Figure 9-2 the software configuration is 803V029-1G. Software Configuration ABB Analytical GCC Remote 0.1 803V029-1R (Std GCC) 2001 **ALARM** **ALARM**...
GC CONTROLLER Back of Front Panel (see Figure 9-3) Description Part Number Kit, Front Panel PCB with LCD 81943A059-2 Lo Comm PCB 733A037D-1 Figure 9-3. BACK OF FRONT PANEL Card Cage (see Figure 9-4) Description Part Number Chroma I/O PCB (old type) 3528515-_ Chroma I/O PCB (new type) 802A028D-_...
PURGE AIR PANEL (SEE FIGURE 9-7) Description Part Number Heater Air Pressure Switch 3617302-1037 1/4-inch Tubing 3617355-2 1/8-inch Tubing 3617355-1 Solenoid Valve Kit (vented) 800K005-1 Solenoid Valve Kit (non-vented) 800K005-2 See SOLENOID VALVES in Section 4 for information on the differences between types of solenoid valves Solenoid Valve Gasket 3617331-1 Pressure Relieving Regulator, 0-40 psig...
ISOTHERMAL OVEN COMPONENTS (SEE FIGURE 9-10) NOTE Part Numbers are incomplete without dash numbers. See the Recommended Spare Parts List (in the Engineering Data Package) for application-specific information. Description Part Number Oven Heater Kit, 115 V 1000W 800K007-1 Oven Heater Kit, 230 V 1000W 800K007-2 Oven Heater Kit, 115 V 500W 800K007-3...
Liquid Sample Valve (see Figure 9-11) Description Part Number O-Ring Seal Kit 791K003N-1 0.125 inch Stem (per application) 791A008B-_ 0.125 inch Seal (per application) 791M001B-_ 0.062 inch Stem (per application) 791A009B-_ 0.062 inch Seal (per application) 791M028B-_ Vaporizer (per application) 805A015-_ Seal Insertion Tool TL-791A006B...
Thermistor Type Thermal Conductivity Detector (see Figure 9-14) Description Part Number Thermistor Assembly, matched pair 798A002B-1 Wire Splice Kit 800K001-1 Figure 9-14. THERMISTOR TYPE TCD COMPONENTS M2CP Valve (see Figure 9-15) Description Part Number 10 port Slider (per application) 764M005-_ 6 port Slider (per application) 764M006-_ 8 port Slider (per application)
Type 781 Methanizer/Air Clean Up System (see Figure 9-16) Description Part Number Methanizer Tube 781A002C-1 Air Cleanup Tube 781A003C-1 115V Heater Kit 805K001-1 230V Heater Kit 805K001-2 Sensor Kit 805K002-1 Crimper 3617469-1 Harness Assy Air Cleanup Tube Methanizer Tube Figure 9-16. TYPE 781 METHANIZER/AIR CLEAN UP SYSTEM Type 805 Methanizer/Air Clean Up System (see Figure 9-17) Description Part Number...
Dual Air Clean Up System (see Figure 9-18) Description Part Number Air Cleanup Tube 805A018-1 Heater 3617474-1 Sensor Kit 805K002-1 Crimper 3617469-1 Metric Hex Wrench TL-161 Figure 9-18. DUAL AIR CLEAN UP SYSTEM Valco Diaphragm Valve (see Figure 9-19) Description Part Number Valve, 10-port 8230442-3...
Flame Ionization Detector with Heater Block (see Figure 9-23) Description Part Number Heater Block 795A002B-1 Flame Ionization Detector 799A001B-2 (see "Flame Ionization Detector" for FID component parts) Figure 9-23. FID WITH HEATER BLOCK Filament Type TC Detector with Heater Block (see Figure 9-24) Description Part Number Heater Block...
SECTION 10. VISTA BASIC INTRODUCTION Vista BASIC is for the user familiar with the fundamentals of BASIC programming languages and general programming techniques. This information is provided for reference only, not as a tool for teaching BASIC programming. "ALPHABETIC LISTING" lists the Vista BASIC commands, functions and statements in alphabetical order, with descriptive information included in each listing.
• The maximum number of programs allowed is 8. In each program, • the maximum number of source program lines allowed is 50; • the maximum number of variables allowed is 49; • the maximum number of characters allowed in a string is 255; •...
For exponential form floating point numbers, a fixed point constant is followed by the letter E and an optionally signed integer with no blanks separating them. Numbers between 0 and 1.0E ±38 approximately can be represented. Negative values are indicated with the unary negation operator (-). Examples of valid floating point constants are: 0.123 -10.123...
and those values can then be accessed by another BASIC program. Thus, the COMMON! array is a mechanism whereby information and data values can be passed between BASIC programs. Another characteristic of the COMMON! array is that the memory allocation is static. That is, the COMMON! array stays around forever and the values are retained between program modifications and compilations.
< <= <> = >= > Relational Logical Logical Logical ALPHABETIC LISTING This section lists the Vista BASIC commands, functions and statements alphabetically, with descriptive information in each listing to guide you in using the listing. VistaNET commands are listed separately at the end of this section. ABSOLUTE VALUE Function Description: Returns the absolute value of a floating point expression.
A Forced Gate TCF is added to method table 1 at 100 seconds. Note: In the example, N represents one of the following numbers which is used to indicate if the function was successful, or why it was unsuccessful, where: 0 means the TCF was successfully added to the method table.
Syntax: CHAIN n% Comments: n% is the BASIC program (1-8) to be chained to. Example: 0010 IF PREV_STRM = 2 THEN CHAIN 2 Transfers control to program two, when stream two was analyzed in the previous analysis cycle. CHR$ Function Description: Converts an integer to a one character long string.
COMMUNICATION ERROR ALARM Function Description: Returns the state of GCC Communication Error Alarms. Syntax: COMM_ERROR_ALARM Example: 0010 IF COMM_ERROR_ALARM GOTO 100 COMPONENT NAME Function Description: Returns the name of the component. Syntax: COMP_NAME$(method%,component%) Comments: method% is method table (1-8). component% is the sought for component. Example: 0010 LPRINT COMP_NAME$(1,1) COMPONENT TYPE Function...
Example: 0010 IF CUR_STRM = 2 GOTO 100 Note: use PREV_STRM for the stream that has just been analyzed. CYCLE TIME Function Description: Returns the Cycle Time for the specified method table. Syntax: CYCLE_TIME(method%) Comments: method% is the method table (1-8). Example: 0010 A% = CYCLE_TIME(1) Gets the cycle time from analysis method one and assigns it to integer...
Note: In the example, N represents one of the following numbers that indicates if the function was successful, or why it was unsuccessful, where: -1 means method% is not in the 1-8 range. -2 means the method table does not exist. -3 means function$ did not have a valid TCF.
FOR...NEXT Statements Description: Does an iteration loop. Syntax: FOR variable = x TO y [STEP z] NEXT [variable[,variable]..] Comments: variable is an integer used as a counter. x is the initial value of the counter. y is the final value of the counter. z is the increment for the counter.
Syntax: GET_BLEND(stream) Example: 0010 LPRINT GET_BLEND(1) The Blend Number for stream one is printed. GET CALIBRATION CONCENTRATION Function Description: Returns the component’s calibration concentration. Syntax: GET_CAL_CONC(method%,component%) Comments: method% is the method table (1-8). component% is the component number for which the calibration concentration is to be retrieved.
GET MAXIMUM PEAK PARAMETER Function Description: Returns the Sim Dis Maximum Peak parameter from the Sim Dis Setup Screen (Sim Dis analyzers only). Syntax: GET_MAX_PEAK_PARM Example: 0010 LPRINT GET_MAX_PEAK_PARM Prints Max Peak from the Sim Dis Setup Screen. GET MULTIPLIER EXPONENT Function Description: Returns the method table’s multiplier exponent.
Comments: time! is the time to convert to a percent off. time_vs_bp_table% is the Time vs. Boiling Point Table (1-8) to use for the conversion. Example: 0010 PERCENT! = TIME_TO_OFF(100.0,1) Returns the percent off that occurred at 100.0 seconds. GET PERCENT OFF TABLE Command Description: Returns the percent off column of one of the eight Time vs.
Comments: percent_off! is the percent off to convert to a temperature. time_vs_bp_table% is the Time vs. Boiling Point Table (1-8) to use for the conversion. Example: 0010 TEMP! = GET_TEMP(50.0,1) Returns the temperature for 50.0 percent off. GET TEMPERATURE FOR A TIME Command Description: Returns a temperature for a given time using a specified Time vs.
Comments: temperature! is the temperature to convert to a time. time_vs_bp_table% is the Time vs. Boiling Point Table (1-8) to use for the conversion. Example: 0010 TIME! = TEMP_TO_TIME(212.0,1) Returns the time that 212.0 degrees occurred. GET TIME VS. BOILING POINT TABLE Command Description: Returns one of the eight Time vs.
IDLE ALARM Function Description: Returns the state of GCC Idle Alarm. Syntax: IDLE_ALARM Example: 0010 IF IDLE_ALARM THEN LPRINT “ALARM” IF Statement Description: Makes a decision. Syntax: IF expression THEN stmt [ELSE stmt] IF expression GOTO line [ELSE stmt] Comments: expression is a logical expression whose result is TRUE or FALSE.
Syntax: INT(fp!) Comments: fp! is a floating point expression. Example: 0010 I = INT(A!) Converts the value of floating point variable A! to an integer and assigns it to integer variable I. LENGTH OF CORRELATION FACTOR TABLE Function Description: Returns the number of entries in the specified Sim Dis Correlation Factor Table (Sim Dis analyzers only).
LET Statement Description: Assigns the value of an expression to a variable. Syntax: [LET] variable = expression Comments: variable is the scalar or aggregate variable to receive the expression value. expression is a string or numeric expression. Example: 0010 LET A! = 0.0 0020 N = 0 0030 A$ = “THIS IS A STRING”...
Page 370
“p” is an optional number that specifies the precision, or number of digits to the right of the decimal point. If “p” is not specified, it is assumed to be 2. Example: 0010 LPRINT USING %9.2R;-0.12, 0020 :100.23 will print “-0.12 100.23” “%w.pE”...
Example: 0010 LPRINT USING %3I;0,-1,10,100 will print “0 -1 10 100” Note: With USING, all data items contained in the LPRINT statement must be of the same data type and agree in type with the format specification. MAXIMUM SIM DIS PEAK HEIGHT Command Description: Returns the maximum Sim Dis peak height (Sim Dis analyzers only).
Example: 0010 IF OP_MSG_ALARM THEN LPRINT 0020 :”ALARM” PEAK AREA Function Description: Returns the peak’s corrected area. Syntax: PK_AREA(peak%) Comments: peak% is the peak number (1 to N_PEAKS). Example: 0010 FOR I = 1 TO N_PEAKS 0020 LPRINT PK_AREA(I) 0030 NEXT I The example prints the area under each peak.
PEAK END TIME Function Description: Returns the end time for the peak. Syntax: PK_END_TIME(peak%) Comments: peak% is the peak number (1 to N_PEAKS). Example: 0010 FOR I = 1 TO N_PEAKS 0020 LPRINT PK_END_TIME(I) 0030 NEXT I Prints the time of each peak’s end. PEAK HEIGHT Function Description: Returns the peak’s height at crest.
POWER FAIL ALARM Function Description: Returns the state of the GCC Power Fail Alarm. Syntax: POWER_FAIL_ALARM Example: 0010 IF POWER_FAIL_ALARM THEN LPRINT 0020 :“ALARM” PREVIOUS INJECT TIME Function Description: Returns a string containing date and time for the sample injection performed in the most recently completed analysis cycle.
PUT ACTUAL RETENTION TIME Command Description: Changes actual (measured) retention time for a particular component. Syntax: PUT_ACTUAL_RT(method%,component%,retention_time!) Comments method% is the method table (1-8). component% is the component number for which the actual retention time is to be updated. retention_time! is the new actual retention time for specified component. Example: 0010 PUT_ACTUAL_RT(1,2,123.64) The measured retention time of the peak for the second component is set at...
Example: 0010 PUT_CAL_CONC(1,2,10.1234) The concentration of 10.1234 is stored in the calibration concentration for component two of analysis method one. PUT COMPONENT CONCENTRATION Command Description: Updates the component concentration. Syntax: PUT_CC(method%,component%,concentration!) Comments: method% is the method table (1-8). component% is the component number for which the concentration is to be updated.
PUT MULTIPLIER EXPONENT Command Description: Updates the multiplier exponent for a particular method. Syntax: PUT_MULTIPLIER_EXP(method%,value%) Comments: method% is the method table (1-8). value% is the new multiplier exponent for the specified method. Example: 0010 PUT_MULTILPIER_EXP(1,4) The value of 4 is stored in multiplier exponent of analysis method one. PUT PERCENT OFF TABLE Command Description: Writes an array into the %off column of a Time vs Boiling Point Table (Sim...
PUT RESPONSE FACTOR Command Description: Updates the response factor for a particular component. Syntax: PUT_RF(method%,component%,response_factor!) Comments: method% is the method table (1-8). component% is the component for which the response factor is to be updated. response_factor! is the new response factor for the specified component. Example: 0010 PUT_RF(1,2,0.98) The value of 0.98 is stored in the response factor for component two of method one.
Comments: channel is the analog to digital converter channel (0 or 1). On the Chroma Board, channel 0 is read from J106 pins 1 and 2, channel 1 is read from J106 pins 4 and 5. NOTE The Chroma I/O Board must have A/D Converter ICs UG1 and UH1 installed (see Figure 10-1) in order for this function to operate.
type: 10, channel: 0; input description: low hydrogen alarm type: 11, channel: 0; input description: remote start/stop input REMARKS Command Description: Used for placing remarks in the BASIC program. Syntax: REM remark Example: 0010 REM CLEAR OUT COMMON!(1) 0020 COMMON!(1) = 0.0 REPORT TYPE Function Description: Returns an integer indicating the report selected in the Printer Report Type...
RESET TIME LIMIT Command Description: Resets BASIC’s time limit allowing the program more time to execute (Sim Dis analyzers only). Syntax: RESET_TIME_LIMIT Example: 0010 FOR I = 1 TO 10000 0020 NEXT I 0030 RESET_TIME_LIMIT The time limit is reset to allow the program to continue executing past the normal time limit.
START ANALYSIS Command Description: Starts an analysis cycle. Syntax START STOP ANALYSIS Command Description: Stops the analyzer from performing further analyses. Syntax: STOP(n%) Comments: n% If n = 0, analysis stops immediately; otherwise it stops at the end of the analysis.
Comments: 0 = Temperature Units in Fahrenheit 1 = Temperature Units in Celsius 2 = Temperature Units in Kelvin Example: 0010 IF T_UNITS = 1 THEN 0020 :T!=9.0/5.0*T!+32.0 Temperature in degrees Celsius is converted to Fahrenheit when the Temperature Units Parameter in the Control Parameters Screen has been to Fahrenheit.
Example: 0010 AREA! = SD_TOTAL_AREA Returns the total measured Sim Dis area. UCT TO TIME Conversion Routine Description: Converts time expressed as UCT array to time as time and date. Syntax: UCT_TO_TIME$(T!) Example: 0010 DIM T!(2) 0020 TIME_UCT(T!) 0030 TM$ = UCT_TO_TIME$(T!) 0040 LPRINT TM$ VALUE Function Description:...
Comments: channel% is the output channel (1-96). value% is the trend output value. Example: 0010 FOR I = 1 TO 96 0020 WTO(I,0) 0030 NEXT I All trend outputs that exist are set to their lowest value. Y2X Function Description: Returns the value of Y raised to the X power.
Page 386
msg_type% is the message type; for Vista BASIC this is always 0. block_type% is the block type; for Vista BASIC this is always 0. flags% is the message flag; for Vista BASIC this is always 0. Example: shown below SEND MESSAGE Command Description: Sends a UDP message from one VistaNET device to another.
The string variable DATA$ now contains “THIS IS THE MESSAGE” To reply, at 0.1.0.4: A reply message is constructed: 0040 REPLY$ = “GOT THE MESSAGE” Using the header received in line 0010 above, the reply is sent: 0050 SND_RPL(HDR$,REPLY$) SUBJECT LISTING This lists the Vista BASIC commands, functions and statements (shown on the left side of the page) in subject order.
GCC Commands and Functions ACT(stream%) ACTIVE STREAM ACTIVATED_BY ACTIVATED BY ALARM ALARM ASSIGN(stream%,method%) ASSIGN STREAM CLEAR CLEAR CLOCK_ERROR_ALARM CLOCK ERROR ALARM COMM_ERROR_ALARM COMMUNICATION ERROR ALARM COMP_NAME$(table%,component%) COMPONENT NAME COMP_TYPE$(method%,component%) COMPONENT TYPE COPY_ARRAY(src_array,dst_array) COPY ARRAY CUR_METHOD CURRENT METHOD CUR_STRM CURRENT STREAM CYCLE_TIME(method%) CYCLE TIME DACS_EVT_MSG(message$)
PUT_ACTUAL_RT(method%,component%,retention!) PUT ACTUAL RETENTION TIME PUT_BENCH_CONC(method%,component%,concentration!) PUT BENCHMK CONCENTRATION PUT_CAL_CONC(method%,component%,concentration!) PUT CALIB CONCENTRATION PUT_CC(method%,component%,concentration!) PUT COMP CONCENTRATION PUT_COMP_NAME(method%,component%,name$) PUT COMPONENT NAME PUT_EXPECTED_RT(method%,component%,retention%) PUT EXPECTED RETENTION TIME PUT_MULTIPLIER_EXP(method%,value%) PUT MULTIPLIER EXPONENT PUT_PRESS(zone%,set point!,ramp rate!) PUT PRESSURE OF A ZONE PUT_REPORT_TYPE(type%) PUT REPORT TYPE PUT_RF(method%,component%,response!) PUT RESPONSE FACTOR PUT_TEMP(zone%,set point!,ramp rate!)
POFF_TO_TIME(percent_off!,time_vs_bp_table%) GET TIME FOR A % OFF PUT_ASTM(integer%) PUT ASTM PUT_BLEND(stream%,blend%) PUT BLEND PUT_FACT_TBL(array!,table%) PUT CORREL FACTOR TABLE PUT_POFF_TBL(array!,table%) PUT % OFF TABLE PUT_TEMP_TBL(array!,table%) PUT TEMPERAURE TABLE PUT_TVSBP_TBL(array!,table%) PUT TIME VS BOIL POINT TABLE RESET_TIME_LIMIT RESET TIME LIMIT SD_PEAK_HEIGHT MAXIMUM SIM DIS PEAK HEIGHT SD_TOTAL_AREA TOTAL SIM DIS AREA TEMP_TO_TIME(temperature!,time_vs_bp_table%)
(”). Illegal Character: A character not recognized by the compiler has been encountered. This error should not occur and should be reported to ABB Lewisburg. Syntax Error: The compiler has encountered something which does not conform to the rules for proper syntax of the language.
Illegal DIM Number: An array dimension (extent) of zero is not allowed in the DIM statement. Internal Error: No Such Error: This is an error that should never occur, but if it does, indicates a design or modification error to the internal software that should be reported to ABB Lewisburg. Run-Time Error Messages Illegal Opcode: This is an error that should never occur, but if it does it indicates a design or modification error to the internal software that should be reported to ABB Lewisburg.
Ratio Table Number Out of Range: This error occurs when you chain to a nonexistent Vista BASIC program. Interpreter Called without Program: The Interpreter was called at end-of-analysis for a program to be executed according to the program-to-stream assignment, but the program was nonexistent. The corrective action for this case would be to compile the program.
Three screens support Real-Time Vista BASIC. These screens are accessed from the Background Screen (see Figure 10-2). ********** B A C K G R O U N D ********** ABB Analytical GCC Remote 0.1 803V029-1R (Std GCC) (C) 2001 **ALARM**...
This screen allows you to start and stop Real-Time Vista BASIC. Real-Time Vista BASIC uses two other screens: one to display Real-Time Status, and one to Edit/View the COMMON! Area. To review the state of the Real-Time Vista BASIC program (running or idle), any text sent to it (using RT_TEXT), and the state of any input requested from it (using RT_INPUT$), press the F2 (View Basic Output) soft key.
Real-Time Vista BASIC Commands While all standard Vista BASIC commands are available for use with Real-Time Vista BASIC, the following commands are specifically for running in real time. WARNING When using Real-Time Vista BASIC, do not use these commands: LPRINT and DACS_EVT_MSG! The Real-Time Vista BASIC program can generate LPRINT and DACS_EVT_MSG information FASTER than it can be processed.
Page 397
Sleep Description: Stops program execution for a specific amount of time. Syntax: SLEEP(tick%) Comments: tick% is the amount of time to wait, where each tick represents 1/32 of a second. Example: 0100 SLEEP(20) Temperature Description: Returns the temperature of a zone of the Five Zone Temperature Controller. Syntax: temp = TEMPS(zone) Comment:...
SECTION 11. DRAWINGS AND DIAGRAMS Since analyzer configuration depends on the particular application, this manual does not contain generic engineering drawings and diagrams. You should utilize the drawings, diagrams and replacement parts lists provided in the Data Package supplied with your analyzer to ensure they are the correct ones for your system.
