ABB i-bus Contents Page Contents General ....................3 Using the product manual......................3 1.1.1 Structure of the product manual ....................4 1.1.2 Note..............................4 Product and functional overview....................5 Device Technology ................7 ...
Using the product manual This manual provides you with detailed technical information relating to the function, installation and ® programming of the ABB i-bus KNX VAA/S x.230.2.1. The application of the device is explained using examples. This manual is divided into the following sections: ...
ABB i-bus General 1.1.1 Structure of the product manual All parameters are initially described in chapter 3. Directly following the parameter descriptions you can find descriptions for the communication objects. Note A Valve Drive Actuator features 6 or 12 outputs. However, as the functions and communication objects for all outputs are identical, only the functions of output A will be described.
General Product and functional overview ® The ABB i-bus Valve Drive Actuators are modular installation devices in Pro M Design or installation in the distribution board. The devices are used for control of valves via Electrothermal Valve Drives e.g. TSA/K, for room temperature control.
35 mm mounting rails. The of the outputs. devices feature six or twelve ® The connection to the ABB i-bus semiconductor outputs for control of is implemented via a bus connection Thermoelectric Valve Drives in heating terminal.
Page 10
The ETS and the current version of the device application program are required for programming. The current version of the application program is available for download on the internet at www.abb.com/knx. After import it is available in the ETS under ABB/Heating, Ventilation, Air conditioning/Valve Drive Actuator.
Device Technology Assembly and installation ® The ABB i-bus KNX Valve Drive Actuator VAA/S x.230.2.1 is a modular installation device for quick installation in the distribution board on 35 mm mounting rails to EN 60 715. The mounting position can be selected as required.
Page 14
ABB i-bus Device Technology Supplied state The device is supplied with the physical address 15.15.255. The application program is preloaded. It is therefore only necessary to load group addresses and parameters during commissioning. However, the complete application program can be reloaded if required. A longer downtime may result if the application program is changed or after a discharge.
ABB i-bus Device Technology Manual operation General The outputs can be directly controlled using the buttons in manual operation. Accordingly, the wiring of the loads connected to the outputs can be verified during commissioning. You can, for example, ensure that the connected valve drives open or close the valves correctly. If bus voltage is not yet available at the time of commissioning, the device can be supplied with power for manual operation using the Power Supply NTI/Z.
ABB i-bus Device Technology 2.5.1 Display elements Indicator LEDs are located on the front of the device. All LEDs Output X indicate the actual state. In KNX operation the LED is off. The response of the display elements is described in the following table:...
ABB i-bus Device Technology 2.5.2 Operating controls Buttons for manual operation are located on the front of the device. If manual operation is activated, the current control value of the respective output is retained and the yellow LEDs on the outputs indicate the current status (ON/OFF). A target position, which may not have yet been achieved, is approached.
Commissioning Commissioning ® The ABB i-bus KNX Valve Drive Actuators VAA/S x.230.2.1 are actuators for control of electrothermal valve drives for room temperature control. The outputs each feature the same range of functions, whereby each output can be parameterized individually.
Note When the term “channels” is used in the ETS, inputs and/or outputs are meant. In order to ensure that ® the ETS language generally applies for as many ABB i-bus devices as possible, the word channels is used here.
ABB i-bus Commissioning 3.1.1.1 Procedure Insert the required device into the project. Import the current application program into the ETS. Perform parameterization and program the device. After you have parameterized a device, you can transfer the settings to a second device.
Note When the term “channels” is used in the ETS, inputs and/or outputs are meant. In order to ensure that ® the ETS language generally applies for as many ABB i-bus devices as possible, the word channels is used here.
ABB i-bus Commissioning 3.1.3 Procedure Insert the required device into the project. Import the current application program into the ETS. Click with the right mouse button on the product, whose outputs you wish to copy or exchange, and select the context menu Plug-in >...
ABB i-bus Commissioning 3.1.4 Copy/exchange channel dialog At the top left, you will see the source channel selection window for marking the source channel. Beside is located the selection window for the target channel or channels for marking the target channel or channels.
Parameters Programming of the Valve Drive Actuator is implemented with the Engineering Tool Software (ETS). The application program is available in the ETS3 at ABB/Heating, Ventilation, Air conditioning/Valve Drive Actuator. The following chapter describes the parameters of the device using the parameter window. The parameter window features a dynamic structure, so that further parameters may be enabled depending on the parameterization and the function.
ABB i-bus Commissioning 3.2.1 Parameter window General In this parameter, the parameters are defined that determine the overall behaviour of the device. Send communication object “In operation” Options: send value 0 cyclically send value 1 cyclically The communication object In operation (no. 0) indicates the presence of the device on the bus. This cyclic telegram can be monitored by an external device.
Page 27
ABB i-bus Commissioning Sending and switching delay after bus voltage recovery in s (2…255) Options: 2…255 Telegrams are only received during the send and switching delay. The telegrams are not processed, however, and the outputs remain unchanged. No telegrams are sent on the bus.
ABB i-bus Commissioning 3.2.2 Parameter window Manual operation In this parameter window all the settings for manual operation can be made. For a detailed description of manual operation see Manual operation, page 13. Manual operation Options: enabled disabled disable/enable via communication object...
Page 29
ABB i-bus Commissioning Enable communication object "Status man. operation" 1 bit Options: yes: The 1 bit communication object Status manual operation (no. 2) is enabled. An additional parameter appears: Send object value Options: no, update only after a change...
ABB i-bus Commissioning 3.2.3 Parameter window A: General Type of valve drive Options: de-energised opened de-energised closed This parameter defines the additional functions of the electrothermal valve drive output. Note De-energised closed valve drives (N.C. = normally closed) If no current flows in the valve drive, the valve is closed. If current flows in the valve drive, the valve opens.
Page 31
ABB i-bus Commissioning Control value in % [0...100] Options: 0…100 This parameter determines the control of the output after bus voltage recovery in %. If a control value is received via a 1 bit value, on parameter Cycle time of PWM in s [10…6,000],...
Page 32
ABB i-bus Commissioning 1 byte: The control value is sent by the thermostat as a continuous positioning telegram (0…255). The communication object byte, page 43 and further parameters Control value, continuous (PWM) 1 appear. Note 1 byte control For 1 byte control, a value of 0…255 (corresponds to 0…100 %) is preset by the room thermostat.
Page 33
The closing and opening times should be taken from the technical data of the valve drive or should be determined during set-up and commissioning. ® The ABB i-bus Valve Drives of types TSA/K 230.1 and TSA/K 24.1 have closing and opening times of about three minutes.
Page 34
ABB i-bus Commissioning Send object value (Object "Fault control value" 1 bit) Options: no, update only after a change after request after a change or request no, update only: The status is updated but not sent. after a change: The status is sent after a change.
ABB i-bus Commissioning 3.2.4 Parameter window A: Functions Functions, various functions for each output can be activated. Enable communication object "Block" 1 bit Options: yes: The 1 bit communication object Block, page 44, is enabled. The following parameter appears:...
Page 36
ABB i-bus Commissioning Control value on forced operation in % [0…100] Options: 0…30…100 This parameter determines the control value that the output should assume at forced operation. If a control value is received via a 1 bit value, a value must be entered on parameter...
Page 37
ABB i-bus Commissioning Enable valve purge Options: yes: The communication object purge, page 44, appears. Trigger valve Note Functions with higher priority are executed and interrupt valve purging. If the interruption duration is longer than the period of valve purge, the valve purge will no longer be executed after, the higher priority has been rescinded.
Page 38
ABB i-bus Commissioning Automatic valve purge Options: yes: The following parameters appear: Purge cycle in weeks [1…12] Options: 1…6…12 The internal automatic purge timer starts directly after a download. The time is reset each time it is downloaded.
ABB i-bus Commissioning 3.2.5 Parameter window A: Characteristic curve correction This parameter window is enabled if in Parameter window A: Functions, page 33, the parameter Enable characteristic curve has been parameterized with the option yes. In this parameter window, an adaptation of the valve drive to the valve that is employed can be undertaken using the characteristic curve correction.
Page 40
ABB i-bus Commissioning Example: Value pair 1 (VP1) Value pair 2 (VP2) Control value in % [0…100] Control value in % [0…100] Valve position in % [0…100] Valve position in % [0…100] Implemented characteristic curve correction: Control value Valve position 0...10%...
Page 41
ABB i-bus Commissioning Enable value pair 3 Options: yes: Value pair 3 appears. Value pair 3 Control value in % [0...100] Valve position in % [0...100] Options: 0…50…100 Enable value pair 4 Options: yes: Value pair 4 appears.
ABB i-bus Commissioning Communication objects 3.3.1 Brief overview of the communication objects Flags Data Point Function Name Length Type (DPT) In operation General DPT 1.002 1 bit Request status values General DPT 1.017 1 bit Status manual Operation General DPT 1.003...
ABB i-bus Commissioning 3.3.2 Communication objects General These communication objects are only available once per device and serve the interdisciplinary (interoperable) functions. Function Object name Data type Flags In operation General 1 bit C, R, T DPT 1.002 This communication object is enabled if in...
Page 44
ABB i-bus Commissioning Function Object name Data type Flags Reset overload/short circuit General 1 bit C, W, T DPT 1.015 All active error messages are reset using this communication object. Communication object Overload/short circuit Bit no. 1 Short circuit in status byte ...
ABB i-bus Commissioning 3.3.3 Communication objects Output A Function Object name Data type Flags Control value, switch Output A 1 bit C, W DPT 1.001 This communication object is enabled if in Parameter window A: General, page 28, the parameter Control value is received as is set with the option 1 bit.
Page 46
ABB i-bus Commissioning Function Object name Data type Flags Block Output A 1 bit C, W DPT 1.003 The communication object is enabled, if in Parameter window A: Functions, page 33, the parameter Enable communication object "Block" 1 bit is parameterized with the option yes.
Page 47
ABB i-bus Commissioning Function Object name Data type Flags Status valve purge Output A 1 bit C, R, T DPT 1.003 This communication object is enabled if in Parameter window A: Functions, page 33, the parameter Enable valve purge has been parameterized with the option yes and the parameter Enable communication object\ "Status valve purge"...
Page 48
ABB i-bus Commissioning Function Object name Data type Flags Status control value Output A 1 bit: C, R, T DPT 1.011 This communication object is enabled if in Parameter window A: Functions, page 33, the parameter Enable communication object "Status control value" is set with the option 1 bit.
In this section, you will find useful instructions concerning the planning and application of the Valve Drive Actuator. Application examples and practical tips on the topic of temperature control etc. can be found in the Application manual Heating/Ventilation/Air-Conditioning at www.abb.de/knx. Behaviour during a malfunction Fuse Three outputs each (e.g.
Page 50
ABB i-bus Planning and Application Reaction of the output after negative short-circuit test (no short circuit test) If a short circuit could not be determined after the fuse trips and the three outputs are tested, after about 40 seconds the 3 outputs of a group are checked for a possible overload. A 7 day test cycle commences.
ABB i-bus Planning and Application Bus voltage recovery General A control value can be predefined at bus voltage recovery. The corresponding communication object values are set, see Table page 50. Time-dependent functions are non-functional and must be restarted, e.g. valve purge.
ABB i-bus Planning and Application Bus voltage failure The device can no longer be controlled at a bus voltage failure. The outputs switch off and the valve drives assume their position in a no-current state (open or closed). Manual operation is not possible during a bus voltage failure.
ABB i-bus Appendix Appendix Scope of delivery The Valve Drive Actuator is supplied together with the following components. Please check the items received using the following list. 1 x VAA/S x.230.2.1, Valve Drive Actuator, x-fold, 230 V, MDRC ...
Page 60
Phone: +49 (0)6221 701 607 (Marketing) With regard to purchase orders, the agreed +49 (0)6221 701 434 (KNX Helpline) particulars shall prevail. ABB AG shall not be liable for any consequences arising from errors or Fax: +49 (0)6221 701 724 incomplete information in this document.
