Cisco 880 Series ISRs
Figure 1-5
1 ISDN port—not available on 3G models
2 Primary WAN port
VDSL2oPOTS, ADSL2+oPOTS,
ADSL2+oISDN, or 10/100 FE
3 Antenna—captive omnidirectional dipole
WLAN antenna (wireless models only)
4 4-port 10/100 Ethernet switch
5 Serial port—console or auxiliary
1. Depending on the router model, the primary WAN port can be G.SHDSL, VDSL2oPOTS, or 10/100 FE. The VDSL2oPOTS
port is in the same location as the G.SHDSL port. The 10/100 FE WAN port is located at the bottom left corner. See
for location of the 10/100 FE WAN port.
Caution
Cisco 860 Series, Cisco 880 Series, and Cisco 890 Series Integrated Services Routers Hardware Installation Guide
1-6
Back Panel of the Cisco 888E and Cisco 888E-W Data Router
B
RX/TX
1 2
1
—RJ-45 only, G.SHDSL,
The primary WAN port is designed for an RJ-45 connector only. Damage to the primary WAN
port may occur if a non RJ-45 connector is inserted.
C
RX
3 4
6 PoE power connector—optional
7 Reset button
8 Power connector
9 Earth ground connection
10 Kensington security slot
