- Page 1 MODEL G0738 HANGING 3-SPEED AIR FILTER OWNER'S MANUAL (For models manufactured since 1/12) WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. Get other manuals https://www.bkmanuals.com...
- Page 2 This manual provides critical safety instructions on the proper setup, operation, maintenance, and service of this machine/tool. Save this document, refer to it often, and use it to instruct other operators. Failure to read, understand and follow the instructions in this manual may result in fire or serious personal injury—including amputation, electrocution, or death.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ..........2 SECTION 5: ACCESSORIES ......17 SECTION 6: MAINTENANCE ......18 SECTION 7: SERVICE ........19 SECTION 1: SAFETY ........5 SECTION 2: POWER SUPPLY ......8 SECTION 8: WIRING ........21 SECTION 9: PARTS ........23 SECTION 3: SETUP ........ -
Page 4: Introduction
INTRODUCTION Manual Accuracy Contact Info your machine may not exactly match the manual www.grizzly.com Get other manuals https://www.bkmanuals.com... - Page 5 Identification To reduce the risk of serious injury, read and understand this entire document before using the machine! Get other manuals https://www.bkmanuals.com...
- Page 6 Machine Data Sheet 0$&+,1( '$7$ 6+((7 Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901 02'(/ * +$1*,1* $,5 ),/7(5 &)0 Product Dimensions: Weight................................31 lbs. Width (side-to-side) x Depth (front-to-back) x Height..............20 in. x 17 in. x 10 in. Footprint (Length x Width)........................
-
Page 7: Section 1: Safety
SECTION 1: SAFETY For Your Own Safety, Read Instruction Manual Before Operating this Machine The purpose of safety symbols is to attract your attention to possible hazardous conditions. This manual uses a series of symbols and signal words intended to convey the level of impor- tance of the safety messages. - Page 8 DISCONNECTING POWER SUPPLY. GUARDS & COVERS. NEVER STAND ON MACHINE. APPROVED OPERATION. STABLE MACHINE. DANGEROUS ENVIRONMENTS. AWKWARD POSITIONS. ONLY USE AS INTENDED. UNATTENDED OPERATION. USE RECOMMENDED ACCESSORIES. MAINTAIN WITH CARE. CHILDREN & BYSTANDERS. CHECK DAMAGED PARTS. REMOVE ADJUSTING TOOLS. MAINTAIN POWER CORDS. SECURING WORKPIECE.
- Page 9 Additional Safety for Air Filters INTENDED USE. DISCONNECTING POWER SUPPLY. REGULAR CLEANING. HAZARDOUS DUST. LEAD PAINT DUST AND ASBESTOS FIBERS. SUSPENDED DUST PARTICLES AND IGNITION SOURCES. DUST ALLERGIES. FIRE SUPPRESSION. IMPELLER HAZARDS. WEAR RESPIRATOR. OPERATING LOCATION. EMPTYING DUST. Like all machinery there is potential danger when operating this air filter. Accidents are fre- quently caused by lack of familiarity or failure to pay attention.
-
Page 10: Section 2: Power Supply
SECTION 2: POWER SUPPLY Availability Serious injury could occur if you connect the machine to power before completing the setup process. DO NOT connect to power until instructed later in this manual. Circuit Requirements Nominal Voltage ........120V Cycle ............60 Hz Electrocution, fire, Phase ........... - Page 11 Grounding & Plug Requirements GROUNDED 5-15 RECEPTACLE Extension Cords 5-15 PLUG Figure 1. Minimum Gauge Size ......16 AWG Maximum Length (Shorter is Better)..50 ft. SHOCK HAZARD! Two-prong outlets do not meet the grounding requirements for this machine. Do not modify or use an adapter on the plug provided—if it will not fit the outlet, have a qualified electrician install the proper outlet with a...
-
Page 12: Section 3: Setup
SECTION 3: SETUP Inventory To reduce the risk of serious injury, read and understand this entire document before using the machine! Needed for Setup Shipping Inventory: (Figure 2) Description Installed & Not Shown Unpacking please call us immediately at (570) 546-9663 for advice. Otherwise, filing a freight claim can be difficult. - Page 13 Power Connection Test Run Connecting Power Troubleshooting Page 19 To test run the machine: Figure 3. Connecting power. Figure 5 Disconnecting Power Figure 4. Disconnecting power. Figure 5. Get other manuals https://www.bkmanuals.com...
- Page 14 Site Planning Figure 6 Figure 6. Get other manuals https://www.bkmanuals.com...
- Page 15 Figure 7 It is very important that the hanging air filter be supported properly. Figure 7. Below is a list of things to keep in mind when selecting a spot for the air filter: Get other manuals https://www.bkmanuals.com...
- Page 16 To mount the air filter to the ceiling: Mounting to Ceiling Figure 8 Figure 9 Figure 8. Important: The ceiling hooks must only be screwed into solid wood. Otherwise, they may pull out under load and cause the air filter to fall. ONLY mount the air filter unit to joists or table that can hold at least 100 lbs.
- Page 17 Note: Some positions for the ceiling hooks may be slightly uneven from each another. To make up for this, minor adjustments can be made to the length of the hanging assem- bly by adjusting the amount that the machine hook is threaded into the air filter housing (see Figure 10).
-
Page 18: Section 4: Operations
SECTION 4: OPERATIONS General Filtering Performance Turning ON & OFF Note: The remote control communicates with the air filter using infrared (IR) and must be pointed directly at the air filter control panel to work prop- erly. Changing Air Flow Speeds To calculate the recirculating rate for your shop space: Setting Timer... -
Page 19: Section 5: Accessories
To minimize this risk, only install accessories recommended for this machine by Grizzly. NOTICE Refer to the newest copy of the Grizzly Catalog for other accessories available for this machine. T10503—Inner Filter for Model G0738 T10504—Outer Filter for Model G0738 Figure 13. -
Page 20: Section 6: Maintenance
SECTION 6: MAINTENANCE Cleaning Filters Figure 15. Keep the air filter unit unplugged during DO NOT use compressed air to blow out the maintenance procedures. INNER filter in the following steps. This can Ignoring this warning may cause damage to the filter. result laceration amputation injuries from... -
Page 21: Section 7: Service
SECTION 7: SERVICE Note: Please gather the serial number and manufacture date of your machine before calling. Troubleshooting Motor & Electrical Air Filter Operations Get other manuals https://www.bkmanuals.com... - Page 22 Replacing Fuse Remote Control Battery Replacement Figure 17 Tool Needed To replace the machine fuse: Figure 16 Figure 17. Figure 16. Get other manuals https://www.bkmanuals.com...
-
Page 23: Section 8: Wiring
SHOCK HAZARD. WIRE/COMPONENT DAMAGE. MOTOR WIRING. MODIFICATIONS. CAPACITORS/INVERTERS. WIRE CONNECTIONS. CIRCUIT REQUIREMENTS. EXPERIENCING DIFFICULTIES. The photos and diagrams included in this section are best viewed in color. You can view these pages in color at www.grizzly.com. Get other manuals https://www.bkmanuals.com... - Page 24 Electrical Wiring Diagram Power Cord Control Panel 110VAC 5-15 Plug (As Recommended) Fuse F2A250V Motor Cabinet Impeller Housing READ ELECTRICAL SAFETY ON PAGE 21! Get other manuals https://www.bkmanuals.com...
-
Page 25: Section 9: Parts
SECTION 9: PARTS Cabinet & Remote Control REF PART # DESCRIPTION REF PART # DESCRIPTION PHTEK15M TAP SCREW M4 X 10 T10503 INNER FILTER 421 X 241 X 160MM P0738002 CABINET T10504 OUTER FILTER 421 X 241 X 45MM PS14M PHLP HD SCR M6-1 X 12 P0738016 RUBBER FOOT... - Page 26 Control Panel REF PART # DESCRIPTION REF PART # DESCRIPTION PN06M HEX NUT M5-.8 P0738058 CONTROL PANEL PLATE P0738012 GROUND WIRE 18AWG 335MM P0738059 INSULATED FLAT WASHER 3MM P0738050 POWER CORD 18G 3W 72" 5-15 PHTEK31M TAP SCREW M4 X 14 P0738051 STRAIN RELIEF 6P-4 P0738061...
- Page 27 Motor & Impeller REF PART # DESCRIPTION REF PART # DESCRIPTION PHTEK15M TAP SCREW M4 X 10 P0738106 SQUIRREL CAGE IMPELLER P0738067 WIRE 18AWG 6-3/4" P0738107 REAR IMPELLER HOUSING COVER P0738100 CAPACITOR COVER P0738108 IMPELLER HOUSING PTLW01M EXT TOOTH WASHER 4MM P0738109 RUBBER SPACER PW05M...
- Page 28 Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes off or becomes unreadable, the owner of this machine MUST replace it in the original location before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com. Get other manuals https://www.bkmanuals.com...
- Page 29 WARRANTY CARD The following information is given on a voluntary basis. It will be used for marketing purposes to help us develop better products and services. Of course, all information is strictly confidential. Note: We never use names more than 3 times. _____________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________...
- Page 30 Get other manuals https://www.bkmanuals.com...
-
Page 31: Warranty & Returns
WARRANTY & RETURNS 1 year Get other manuals https://www.bkmanuals.com... - Page 32 ® Buy Direct and Save with Grizzly – Trusted, Proven and a Great Value! ~Since 1983~ Visit Our Website Today For Current Specials! ORDER 24 HOURS A DAY! 1-800-523-4777 Get other manuals https://www.bkmanuals.com...
