8.1.4 Line Power Supply 3 x 525–690 V AC
Table 8.12. Line Power Supply 3x525–690 V AC - Normal overload 110% for 1 minute,
150 to 200 HP.
Type Designation, HVFD3D...
Typical shaft output at 575 V [hp]
Typical shaft output at 525 V [kW]
Typical shaft output at 690 V [kW]
Enclosure Size
IP21/NEMA 1
IP54/NEMA 12
Output Current
Continuous (3x525 V) [A]
Intermittent (3x525 V) [A]
Continuous (3x575/690 V) [A]
Intermittent (3x575/690 V) [A]
Continuous kVA (525 V AC) [kVA]
Continuous kVA (575 V AC) [kVA]
Continuous kVA (690 V AC) [kVA]
Maximum Input Current
Continuous (3x525 V) [A]
Continuous (3x575/690 V) [A]
Additional Specifications
Estimated power loss at 575 V [W]
Estimated power loss at 690 V [W]
Mains, motor, brake, and load share [AVG/(mm
Efficiency
1) Typical power loss is at normal conditions and expected to be within ±15% (tolerance relates to variety
in voltage and cable conditions). These values are based on a typical motor efficiency (IE/IE3 border
line). Lower efficiency motors add to the power loss in the drive. Applies to dimensioning of drive cooling.
If the switching frequency is higher than the default setting, the power losses can increase. LCP and typ-
ical control card power consumptions are included.Options and customer load can add up to 30 W to the
losses, though usually a fully loaded control card and options for slots A and B each add only 4 W.
2) Measured using 5 m (16.4 ft) shielded motor cables at rated load and rated frequency. Efficiency mea-
sured at nominal current. For energy efficiency class, see Chapter 8.4 Ambient Conditions.
89
2
1, 2
1, 2
2
)]
3D1500 3D2000
150 200
110 132
132 160
D1 D1
D1 D1
162 201
178 221
155 192
171 211
147 183
154 191
185 230
156 193
149 185
2101 2649
2167 2740
2x3/0 2x3/0
(2x95) (2x95)
0.98 0.98
