Summary of Contents for Cisco BTS 10200 Softswitch
Page 1
Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x December 9, 2008 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883 Text Part Number: OL-8001-10...
Page 2
MeetingPlace Chime Sound, MGX, Networkers, Networking Academy, Network Registrar, PCNow, PIX, PowerPanels, ProConnect, ScriptShare, SenderBase, SMARTnet, Spectrum Expert, StackWise, The Fastest Way to Increase Your Internet Quotient, TransPath, WebEx, and the WebEx logo are registered trademarks of Cisco Systems, Inc.
Page 3
Specific Trailing Digits Deletion Leading Digits Deletion if the Length Matches OL-8001-10 C O N T E N T S xiii xiii xiii 1-10 1-11 1-12 1-12 1-12 1-12 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x xiii 1-13...
Destination Route Trunk Group Policy NXX Call Type Profile Sample Provisioning Feature Interaction Routing C H A P T E R Introduction Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-13 1-13 1-14 1-14 1-14 1-15 1-15 1-16 1-17...
Page 8
LNP Route LNP Trigger = Y Not in DN2Sub POP 50 Block POP 50 No Block POP Block-ea = N POP Block-ea = Y Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x viii 4-11 4-11 4-13 4-15 4-16 4-18...
Page 9
Custom Dial Plan Profile Provisioning a Dial Plan with the Extensible Provisioning and Operations Manager Adding a Dial Plan to the Cisco BTS 10200 Softswitch Configuration Applying an EPOM Template to a Selected Dial Plan Editing a Dial Plan in the Cisco BTS 10200 Softswitch Configuration...
Page 10
Contents Deleting a Dial Plan from the Cisco BTS 10200 Softswitch Configuration 6-14 Adding Multiple Dial Plans to a Cisco BTS 10200 Softswitch Configuration 6-15 Editing Multiple Dial Plans in the Cisco BTS 10200 Softswitch Configuration 6-16 Deleting Multiple Dial Plans in the Cisco BTS 10200 Softswitch Configuration...
Page 11
Softswitch. It provides detailed digit manipulation, translation, and dial plan information for various routing scenarios. Additionally, this document provides dial plan configuration information. Objective The system administrator of a Cisco BTS 10200 Softswitch can use this document to better understand how to configure the Cisco BTS 10200 Softswitch dial plan. Audience This document is designed for engineers, technicians, and system administrators who setup and configure the Cisco BTS 10200 Softswitch dial plan.
Page 12
This document includes all of the information that was contained in the previous issue (the Release 4.5 Cisco BTS 10200 Softswitch Dial Plan Guide, OL-8001-08), and has been updated for the Release 4.5 Cisco BTS 10200 Softswitch Dial Plan Guide, OL-8001-09 as described in this Preface.
Nonregistered Cisco.com users can order documentation through a local account representative by • calling Cisco Systems Corporate Headquarters (California, USA.) at 408 526-7208 or, elsewhere in North America, by calling 800 553-NETS (6387). OL-8001-10 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Accessing all the tools on the Cisco TAC website requires a Cisco.com user identification (ID) and password. If you have a valid service contract but do not have a login ID or password, register at this URL: http://tools.cisco.com/RPF/register/register.do Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Preface OL-8001-10...
Page 15
You and Cisco will commit resources during normal business hours to restore service to satisfactory levels. Severity 4 (S4)—You require information or assistance with Cisco product capabilities, installation, or configuration. There is little or no effect on your business operations. OL-8001-10 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Information about Cisco products, technologies, and network solutions is available from various online and printed sources. The Cisco Product Catalog describes the networking products offered by Cisco Systems, as well as • ordering and customer support services. Access the Cisco Product Catalog at this URL: http://www.cisco.com/en/US/products/products_catalog_links_launch.html...
Page 17
The Cisco BTS 10200 Softswitch digit manipulation or digit translation function enables manipulating or translating either the digit string, or the nature of address (NOA), or both. Digit manipulation or...
Page 18
Trunk Group within a route. If the Called Party Number terminates within the Cisco BTS 10200 Softswitch, and the subscriber number points to a Trunk Group, then digit manipulation rules for ANI, DNIS, or both can be specified in the Trunk Group Table.
Digit Translations Digit Manipulation The following is an overview of what the digman tables provide for the Cisco BTS 10200 Softswitch. Digit manipulation or digit translation is performed based on as many as twenty different digit manipulation (digman) tables as designated by the digman-id and rule number, each of which can have a unique set of match-string and replace-string tokens and/or match-NOA and replace-NOA tokens.
Page 20
Ampersand (&) if specified, can appear by itself or be the last character of the string. Phrase "none" or "NONE" can only appear by itself. • Character Function The following subsections provide information on the Cisco BTS 10200 Softswitch character function. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x “Ampersand (&) Character”.
Replace string 5 MATCHED Output string = 51234 Example 3: Enter 1 to continue translations 1 Enter input string 222 Match string ^ Replace string 1 MATCHED Output string = 1222 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x OL-8001-10...
Page 22
Replace string 0000 MATCHED Output string = 4692550000 Example 3: Enter 1 to continue translations 1 Enter input string 469255 Match string $ Replace string 0000 MATCHED Output string = 4692550000 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x OL-8001-10...
Page 23
Replace string & Not MATCHED Output string = 14695551234 Example 4: Enter 1 to continue translations 1 Enter input string 222333 Match string ...33 Replace string none MATCHED Output string = 2223 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x OL-8001-10...
Page 24
Replace string none MATCHED Output string = 2551234 Example 2: Enter 1 to continue translations 1 Enter input string 4692551234 Match string ????$ Replace string none MATCHED Output string = 469255 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x OL-8001-10...
Page 25
Example 2: % - indicates match on any number of digits. Additional examples: Example 1: Enter 1 to continue translations 1 Enter input string 4692551234 Match string % Replace string 55555 MATCHED Output string = 55555 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x OL-8001-10...
Page 26
1. The resultant output string=14695551234. Additional examples: Example 1: Enter 1 to continue translations 1 Enter input string 4692551234 Match string ???255 Replace string 1& MATCHED Output string = 14692551234 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-10 OL-8001-10...
Page 27
Match string # Replace string & MATCHED Output string = *85# Delete Digits Function The Cisco BTS 10200 Softswitch digit manipulation function supports the following delete capabilities: Deletion of leading digits • Deletion of specific leading digits • Deletion of trailing digits •...
Page 28
Digit Manipulation Leading Digits Deletion The Cisco BTS 10200 Softswitch digit manipulation functions supports the deletion of leading digits per the following example: Add digman id=del3; match-string=???; replace-string=none; OR Add digman id=del3; match-string=^???; replace-string=none; ************************************************** Enter input string4692551234 Match string???
Digit Translations Leading Digits Deletion if the Length Matches The Cisco BTS 10200 Softswitch digit manipulation function supports the deletion of leading digits only if the length of input-string matches the length implied by the match-string per the following example: Add digman id=del310;...
Digit Manipulation Digits Prefix if Length Matches The Cisco BTS 10200 Softswitch digit manipulation function supports the prefixing of digits only if length matches per the following example: Add digman id=pfx469if7; match-string=^...; replace-string=469; OR Add digman id=pfx469if7; match-string=...; replace-string=469; ************************************************** Enter input string 5551234 Match string ^...
Chapter 1 Digit Translations Trailing Digits Replacement The Cisco BTS 10200 Softswitch digit manipulation function supports the replacing trailing digits per the following example: Add digman id=del4rep0000; match-string=????$; replace-string=0000; ************************************************** Enter input string 4692551234 Match string ????$ Replace string 0000...
Output string = 4692221234 ************************************************** Digits Replacement in a Specific Digit Position The Cisco BTS 10200 Softswitch digit manipulation function supports the digits replacement in the specific digit position per the following examples: Add digman id=rep456w222; match-string=...???...; replace-string=222; Add digman id=replast4; match-string=...????; replace-string=0000;...
Chapter 1 Digit Translations Any Input String Replacement The Cisco BTS 10200 Softswitch digit manipulation function supports the replacement of any input string with the replace-string per the following examples: Add digman id=replace; match-string=%; replace-string=4692550000; ************************************************** Enter input string none...
Sync is a restricted command and is intended for repairing data only. Improper use may corrupt database Caution and disrupt call processing. Use with caution. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-18 Description NOA used to specify non-unique international number (valid for Calling Party number).
Page 35
Description: Primary key. The NOA Route Profile id. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, delete, show, audit, sync Mandatory: add, change, delete Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Nature of Address Manipulation 1-19...
Page 36
Nature of Address Manipulation LIMIT MASTER ORDER PLATFORM_STATE Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-20 Description: Specifies the number of rows to display on the screen. Valid only for the show command. INTEGER: 1-100000000 (Default = 100000000).
The NOA Route (noa-route) table defines NOA-based routing on the Cisco BTS 10200 Softswitch. When the NOA-based routing is specified in the Dial Plan Profile table the Cisco BTS 10200 Softswitch uses the received NOA to index the NOA Route table and determine the destination id for further routing.
Page 38
Foreign Key Token(s): id, dest-id Syntax Description AUTO_REFRESH DEST_ID DISPLAY Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-22 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y).
Page 39
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Nature of Address Manipulation 1-23...
Page 40
Nature of Address Manipulation PLATFORM_STATE START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-24 Description: State of an active or standby system shared memory database; use to audit an active or standby system shared memory database. Valid for the audit database and audit table name commands.
Automatic Number Identification/Dialed Number Identification Service Manipulation The Cisco BTS 10200 Softswitch supports DNIS or ANI digit manipulation, it includes digit manipulation or nature of address manipulation or both. When ANI manipulation is defined, it usually refers to the calling party number (CPN) which is normally displayed when a call is terminated to a device with calling number delivery (CND) feature.
Sync is a restricted command and is intended for repairing data only. Improper use may corrupt database Caution and disrupt call processing. Use with caution. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-26 Match-NOA Replace NOA Remarks If first digit is a *, treat it as a VSC code.
Page 43
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-27...
Page 44
Automatic Number Identification/Dialed Number Identification Service Manipulation LIMIT MASTER ORDER PLATFORM_STATE Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-28 Description: Primary key. The NOA Route Profile id. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, delete, show, audit, sync...
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-29...
Page 46
• Syntax Description AUTO_REFRESH DESCRIPTION DISPLAY Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-30 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y). Y—Queries the database for the most current data.
Page 47
INTEGER: 1-100000000 (Default = 100000000). Valid for Command: show Default Value: 100000000 Possible Value: [1_100000000] Parser: DecimalParser Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-31...
Page 49
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-33...
Page 50
ACTIVE (Default)—System is active (currently running). STANDBY—System is in standby mode. EMS—Audits the active EMS to the standby EMS. Valid for Command: sync, audit Default Value: ACTIVE Possible Value: ACTIVE, STANDBY Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-34 OL-8001-10...
Page 52
Automatic Number Identification/Dialed Number Identification Service Manipulation REPLACE_STRING RULE START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-36 Description: If a match is found, the matched string is replaced with the replace-string. VARCHAR(40): 1-40 ASCII characters. The characters can be one of the...
It is critical to specify the correct NANP-DIAL-PLAN value. If the default Y value (North America) is Note used on an international switch (e.g., in Europe), then digman and dial-plan NOA matching and replacing will not work correctly. Table Name: DIAL_PLAN_PROFILE...
Page 54
Automatic Number Identification/Dialed Number Identification Service Manipulation ANI_DIGMAN_ID AUTO_REFRESH DESCRIPTION DISPLAY DNIS_DIGMAN_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-38 Description: Foreign key: Digman Profile table. ANI (calling party number) digit manipulation ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, audit, change, show...
Page 55
NXX-NXX-XXXX. CHAR(1): Y/N (Default = Y). Valid for Command: add, audit, change, show Default Value: Y Possible Value: Y, N Parser: BooleanParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-39...
Page 56
PROFILE_ID ORDER OVERDECADIC_ DIGITS_SUPP Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-40 retranslate dialed digits. This token is used only if the dial plan ID is different from the dial plan profile ID. VARCHAR(16): 1-16 ASCII characters (Default = dial-plan-profile-id).
Page 57
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-41...
Delete Rules: Id does not exist in any: dial-plan::id; sub-profile::dial-plan-id; pop::lnp-dp-id; trunk-grp::dial-plan-id; or carrier::dial-plan-id. Syntax Description AUTO_REFRESH DESCRIPTION Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-42 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y).
Page 59
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-43...
While the simple delete and/or prefix digit manipulation function is still supported, it is no longer Note necessary as the same function(s) can now be accomplished in the other two stages. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-44 Description: State of an active or standby system shared memory database;...
Change Rules: dial-plan id must exist. Delete Rules: dial-plan id must exist; NOA defaults to unknown. If NOA is other than unknown, NOA is required. OL-8001-10 Automatic Number Identification/Dialed Number Identification Service Manipulation Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-45...
Page 62
AUTO_REFRESH DEL_DIGITS DEST_ID DIGIT_STRING DISPLAY Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-46 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y). Y—Queries the database for the most current data.
Page 63
Parser: TextParser Description: Maximum number of digits allowed. SMALLINT: 1-64 (Default = 10). Valid for Command: add, audit, change, show, sync Mandatory: add Default Value: 10 Possible Value: [1_64] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-47...
Page 64
Automatic Number Identification/Dialed Number Identification Service Manipulation MIN_DIGITS ORDER PFX_DIGITS Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-48 Description: Minimum number of digits required for a call. SMALLINT: 1-64 (Default = 10). Valid for Command: add, audit, change, show, sync...
Page 65
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-49...
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-51...
Automatic Number Identification/Dialed Number Identification Service Manipulation LIMIT MASTER MAX_DIGITS MIN_DIGITS Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-52 Description: Primary key. Foreign key: International Dial Plan Profile table. International dial plan profile ID. VARCHAR(16): 1-16 ASCII characters.
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-53...
Trunk Group within a route. If the called number terminates within the Cisco BTS 10200 Softswitch, and the subscriber number points to a Trunk Group, then digit manipulation rules for ANI, DNIS, or both can be specified in the Trunk Group table.
Chapter 1 Digit Translations Although both pfx_digits and del_digits still work in the Cisco BTS 10200 Softswitch dial plan table, Note if the subscriber dials a 7-digit number, but local number portability (LNP) queries require a 10-digit DN, then the digman tables should be set up to add an NPA, making the called number a 10- digit DN before performing an LNP query.
Page 72
ACQ_LNP_QUERY ANI_DIGMAN_ID ANNC_ID AUTO_REFRESH Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-56 Description: Specifies whether an LNP Query is required. Applies only if the all-call-query token is set to Y and lnp-db-type=RN in the LNP Profile table. VARCHAR(32): 1-32 ASCII characters. Permitted values are: NA (Default)—Not applicable.
Page 73
Mandatory: add Default Value: 00 Possible Value: [2_2] Parser: HexParser Valid for Command: add, change, audit, sync, show Mandatory: add Default Value: NONE Possible Value: NONE, CHARGE_BAND, CHARGE_UNIT Parser: TextNoCaseParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-57...
Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-58 Description: Called party release control allowed indication. Indicates to the Cisco BTS 10200 Softswitch that this call requires called party control. CHAR(1): Y/N (Default = N). Valid for Command: add, change, audit, sync, show...
Page 75
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-59...
Page 76
PLATFORM_STATE ROUTE_GUIDE_ID ROUTE_ID ROUTE_TYPE Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-60 Description: State of an active or standby system shared memory database; use to audit an active or standby system shared memory database. Valid for the audit database and audit table name commands.
Page 77
Y—0+ calls are allowed to this destination. N—0+ calls are not allowed to this destination. Valid for Command: add, change, audit, sync, show Default Value: N Possible Value: Y, N Parser: BooleanParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-61...
Delete Rules: id does not exist in any <route-guide, policy-odr, policy-region, policy-percent, policy-tod, policy-prefix, policy-oli, or policy-pop>::policy-id where policy-type = route. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-62 Chapter 1 Digit Translations...
Page 79
Parser: TextParser Description: Foreign key: Digman Profile table. ANI (calling party number) digit manipulation ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, audit, change, show Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-63...
Description: Foreign key: Call Agent table. Valid home Call Agent ID for the dialed NPA or NPA-NXX. VARCHAR(8): 1-8 ASCII characters. Valid for Command: add, audit, change, show Possible Value: [1_8] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-65...
Page 82
CALL_AGENT_ID5 CALL_AGENT_ID6 CALL_AGENT_ID7 CALL_AGENT_ID8 CALL_AGENT_ID9 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-66 Description: Foreign key: Call Agent table. Valid home Call Agent ID for the dialed NPA or NPA-NXX. VARCHAR(8): 1-8 ASCII characters. Valid for Command: add, audit, change, show...
Page 83
Possible Value: [0_10] Parser: DecimalParser Description: Number of digits to delete. SMALLINT: 0-16 (Default = 0). Valid for Command: add, audit, change, show Default Value: 0 Possible Value: [0_10] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-67...
DEL_DIGITS6 DEL_DIGITS7 DEL_DIGITS8 DEL_DIGITS9 DISPLAY DNIS_DIGMAN_ID1 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-68 Description: Number of digits to delete. SMALLINT: 0-16 (Default = 0). Valid for Command: add, audit, change, show Default Value: 0 Possible Value: [0_10] Parser: DecimalParser Description: Number of digits to delete.
Page 85
Parser: TextParser Description: Foreign key: Digman Profile table. DNIS (called party number) digit manipulation ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, audit, change, show Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-69...
Page 86
Automatic Number Identification/Dialed Number Identification Service Manipulation DNIS_DIGMAN_ID7 DNIS_DIGMAN_ID8 DNIS_DIGMAN_ID9 LIMIT MASTER Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-70 Description: Foreign key: Digman Profile table. DNIS (called party number) digit manipulation ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, audit, change, show...
Page 87
Description: Digits to be prefixed for tgn2-id. Digits are prefixed after the number of digits specified have been deleted. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, audit, change, show Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-71...
Page 88
PFX_DIGITS4 PFX_DIGITS5 PFX_DIGITS6 PFX_DIGITS7 PFX_DIGITS8 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-72 Description: Digits to be prefixed for tgn3-id. Digits are prefixed after the number of digits specified have been deleted. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, audit, change, show...
Page 89
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-73...
Page 90
Automatic Number Identification/Dialed Number Identification Service Manipulation TG_SELECTION TG10 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-74 Description: Trunk group selection policy. VARCHAR(3). Permitted values are: LCR—Least cost routing P—Priority and weight-based routing RR—Round robin SEQ (Default)—Sequential order...
Page 91
This field can also be provisioned using tg instead of tgn-id. The EMS looks up the tgn-id based on the trunk group and then provisions it. INTEGER: 1-99999999. Valid for Command: add, audit, change, show Possible Value: [0_99999999] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-75...
Page 92
TGN6_ID TGN7_ID TGN8_ID TGN9_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-76 Description: Foreign key: Trunk Group table. The fifth trunk group within the route. This field can also be provisioned using tg instead of tgn-id. The EMS looks up the tgn-id based on the trunk group and then provisions it.
(CAS), Integrated Services Digital Network (ISDN), Signaling System 7 (SS7) and SOFTSW (Session Initiation Protocol (SIP)). The Trunk Group table defines common information based on the trunk group type. The Cisco BTS 10200 Softswitch supports announcement, CAS, ISDN, SS7 and SOFTSW (SIP) trunk group profiles.
Page 94
Set CUT_THRU_BEFORE_ANSWER (moved from ISDN-TG-PROFILE) to N. • Pre-check on 4.5 before upgrade, if POP_ID is null, provision a valid POP_ID at 4.5 side before • upgrade. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-78 Chapter 1 Digit Translations OL-8001-10...
Page 95
N—Perform normal routing. Y—Determine the subscriber ID based on the ANI Screening table. Valid for Command: add, change, audit, sync, show Mandatory: add Default Value: N Possible Value: Y, N Parser: BooleanParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-79...
Page 96
AUTO_REFRESH CALL_AGENT_ID CALL_CTRL_ ROUTE_ID CARRIER_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-80 Description: Mandatory if ani-screening=y. Foreign key: ANI Screening Profile table. ANI screening profile id. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, show, audit...
Page 97
Default Value: 0 Possible Value: [0_14] Parser: DecimalParser Description: Described by the service provider. VARCHAR(64): 1-64 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_64] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-81...
Page 98
DIAL_PLAN_ID DIRECTION DISPLAY DNIS_DIGMAN_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-82 Description: Foreign key: Dial Plan table. Specifies which dial plan ID to use. For trunk groups with a main subscriber id (CAS, ISDN), the Call Agent uses the dial-plan-id assigned to the trunk group (if available), else it uses the dial-plan-id assigned to the subscriber profile.
Page 99
Description: Primary key. Trunk group number. INTEGER: 1-99999999. Valid for Command: add, change, show, delete, audit, sync, control, status Mandatory: add, change, delete, control, status Possible Value: [1_99999999] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-83...
Page 100
Automatic Number Identification/Dialed Number Identification Service Manipulation LIMIT MAIN_SUB_ID MASTER Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-84 Description: Specifies the number of rows to display on the screen. Valid only for the show command. INTEGER: 1-100000000 (Default = 100000000).
Parser: TextParser Description: Not provisionable. EMS provisions this field when trunks are provisioned for this trunk group. SMALLINT: 1-9999. Valid for Command: audit, sync, show Possible Value: [0_2147483647] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-85...
Page 102
PERFORM_LNP_ QUERY PFX_DIGITS PLATFORM_STATE Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-86 Description: Specifies whether to display data on the screen in a sorted order. Valid only for the show command. VARCHAR(1024): 1-1024 (Default = all rows are displayed). Permitted values are any valid token that can be shown for this command.
Page 103
Description: Specifies whether the script package is supported by the trunk group. Used for prepaid service. CHAR(1): Y/N (Default = N). Valid for Command: add, change, audit, sync, show Default Value: N Possible Value: Y, N Parser: BooleanParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-87...
Page 104
Automatic Number Identification/Dialed Number Identification Service Manipulation SEL_POLICY SEND_EARLY_ BKWD_MSG Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-88 Description: Trunk selection policy. Control the Call Agent out-of-service, then in-service, after changing the selection policy. Then verify that the selection policy is changed.
Page 105
Description: Use when a call is forwarded and call routing is to the PSTN where Calling Party Number Screening is performed. If redirecting number information is available, the Cisco BTS 10200 Softswitch overwrites the calling party number with RDN. Otherwise, if Original Called number information is available, the Cisco BTS 10200 Softswitch overwrites the calling party number with the OCN.
Page 106
START_ROW STATUS STATUS_ MONITORING TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-90 Description: Foreign key: Service Provider table. The service provider ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16]...
Page 107
Valid for Command: add, audit, sync, show Mandatory: add Possible Value: ANNC, SOFTSW, CAS, ISDN, SS7, H323 Parser: TextParser Valid for Command: status Mandatory: status Default Value: N Possible Value: Y, N Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-91...
Page 108
TANDEM—Incoming local/tandem trunk group. Calls are allowed to a tandem trunk. USER—Cisco BTS 10200 acts as a user side (PBX) toward the network. Valid for Command: add, change, audit, sync, show Default Value: LOCAL Possible Value: LOCAL, TANDEM, PBX, USER Parser: TextParser Description: Unique key: softsw-tsap-addr+trunk-sub-grp.
Valid for Command: add, show, change, audit, sync Default Value: AUTO Possible Value: AUTO, G711_ULAW, G711_ALAW Parser: TextNoCaseParser Valid for Command: status, control Mandatory: status, control Default Value: N Possible Value: Y, N Parser: BooleanParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-93...
For each ROUTE if not null, add an entry into POLICY_PROFILE table if it does not exist yet. Syntax Description AUTO_REFRESH CARRIER DISPLAY Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-94 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y).
ACTIVE (Default)—System is active (currently running). STANDBY—System is in standby mode. EMS—Audits the active EMS to the standby EMS. Valid for Command: sync, audit Default Value: ACTIVE Possible Value: ACTIVE, STANDBY Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-95...
The Call Type Profile (call-type-profile) table defines the Call Type properties supported by the Cisco BTS 10200 Softswitch. Provision this table if the ALL-CALL-QUERY flag in the LNP-PROFILE table is set to Y and the ACQ-LNP-QUERY token in the Destination table is set to ACQ-BASED-ON-CALL-TYPE.
Page 113
Appendix G, “Call Types and Subtypes” for a list of valid call types. Valid for Command: add, change, delete, show, audit, sync Mandatory: add, change, delete Possible Value: [1_16] Parser: TextNoCaseParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-97...
Page 114
DISPLAY LIMIT LNP_QUERY MASTER ORDER Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-98 Description: Specifies what token information to display on the screen. Valid only for the show command. VARCHAR(1024): 1-1024 (Default = all tokens are displayed). Permitted values are any valid token that can be shown for this command.
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 1-99...
When a call is terminated to a subscriber with Call Forwarding activated, a feature interaction occurs when calls are forwarded out of the Cisco BTS 10200 Softswitch. In China, the Cisco BTS 10200 Softswitch uses H323 signaling to route calls to the PSTN; however, this scenario applies to any call which is forwarded over a non-SS7 signaling interface.
Revised: December 9, 2008, OL-8001-10 Introduction This chapter provides a basic understanding of the Cisco BTS 10200 Softswitch routing types and an explanation of all routing types and explanation of how they function. Additionally examples of the routing types are provided. This chapter is divided into the following sections: •...
(ID) tables. These are the main tables which determine call routing and are instrumental in determining other information needed to route a call, such as call type and destination. This section provides the Cisco BTS 10200 Softswitch routing type information. The following topics are covered in this section: Basic Subscriber •...
Step 8. If the call type is via a presubscribed interexchange carrier (PIC), proceed to Step 9. If the call type is toll free, 900, or 500, the Cisco BTS 10200 Softswitch will use the dial plan to select Step 7 the call route and to route the call.
Page 120
Get Subscriber Table (Sub-profileid) Get subscriber-profile Table (dial-plan-id) CALLTYPE TOLLFREE DP_Routing (SUB->DP) Select Route Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Basic Subscriber Routing Go to Dial-plan (based on DP-ID) CASUAL Carrier_Routing (CASUAL) NOT FOUND Chapter 2 Go to Destination...
10. If the call type is TG SP, proceed to Step 11. Step 6 If the call type is toll free, 900, or 500, the Cisco BTS 10200 Softswitch will use the dial plan to select the call route and to route the call.
Page 122
CALLTYPE TOLLFREE DP_Routing (TG->DP) Select Route NOT FOUND Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Go to dial-plan and Go to destination get destination table and get based on call type and route digits and dp-id...
Step 5. If a trunk group dial plan is not available, proceed to Step 6. If a trunk group dial plan is available, the Cisco BTS 10200 Softswitch will use the trunk group dial plan Step 5 to select the call route and to route the call.
If a carrier dial plan is configured, proceed to Step 7. If a carrier dial plan, is not configured proceed to Step 8. If a carrier dial plan is configured, the Cisco BTS 10200 Softswitch will use the carrier dial plan to select Step 7 the call route and to route the call.
Cisco BTS 10200 Softswitch will return an error and will drop the call. Determine the call type. If the call type is toll free, 900, or 500, the Cisco BTS 10200 Softswitch will Step 8 select the call route and to route the call using the destination carrier routing.
Page 127
Basic Dial Plan Routing If (dp1->idp) default_idp = dp1->idp INTL DIAL PLAN else default-idp = ca_config->idp Return NOT_FOUND Return SUB Return DEST->route_guide_idx Return DEST->route_idx Return ERROR CALLTYPE TOLLFREE (DEST->CARRIER) Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Routing Types Carrier_Routing 2-11...
Go to the destination table and the get the call type and call route. Step 4 Check for the ANI based routing flag. If the ANI based routing flag is available, the Cisco BTS 10200 Step 5 Softswitch will use the ANI to determine the subscriber characteristics and then will route the call based on the those characteristics.
Donor Switch—Processes a call originating from a subscriber or trunk to a called directory number • (DN) of a subscriber ported out of the given Cisco BTS 10200 Softswitch donor switch to a recipient switch. In some cases, the donor switch may also be the originating or intermediate switch.
Routing Types Query Types The Cisco BTS 10200 Softswitch performs queries of its internal database in order to route a call. It may also be configured to perform queries for another backward switch that is not capable of LNP queries.
Page 131
Intermediate or Donor Switch Performs ACQ for Another Switch or Network The Cisco BTS 10200 Softswitch may be required to perform ACQ for another switch that does not have that capability. For example, an international gateway exchange may not have access to the local country LNP database, so the ACQ is performed at the point of interconnect (POI) by the intermediate switch.
Page 132
Trunk Grp Destination ALL-CALL PERFORM-LN ACQ-LNP- -QUERY P-QUERY QUERY = NA Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-16 illustrate which token combinations result in a query. In general, a query must Destination (ACQ-LNP-QUERY = ACQ-BASED-ON- CALL-TYPE) Destination...
Page 133
ACQ-LNP- ACQ-LNP- QUERY = QUERY = (Call-Type-Profile PERFORM-LN NO-LNP-QUE for call type P-QUERY LNP-QUERY = Y Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Routing Types Destination (ACQ-LNP-QUERY ACQ-BASED-ON-C ALL-TYPE) (Call-Type-Profile for call type BTS ACQ not present or...
QOR. For a subscriber origination (originating switch), ACQ takes precedence over QOR, so the call will be initially correctly routed to the recipient switch, and no REL with cause value QOR: Ported Number (14) will be received (other than for a network routing error).
Page 135
RN and NOA for ported number, then the call is cleared with a cause 31 unspecified This case is normally not expected to occur. If the BTS is the donor switch in this case and receives a called party number with ported NOA, then REL with cause unallocated number is sent back to the originating switch.
Intermediate or Donor Switch Performing QoR for Another Switch or Network For QoR, the LNP query is only done on the originating switch, unless the BTS is required to perform the QoR query for another switch that does not have that capability. For example, an international gateway exchange may not have access to the local country-specific LNP database, so the query is performed by the intermediate switch.
If the LNP query does not find an RN, or returns the RN of this switch, then the subscriber is not ported yet (or has ported out and back in again), so the call is routed to the subscriber.
Page 138
In the DN2subscriber table on the donor switch, STATUS=ASSIGNED and LNP-TRIGGER=Y. Since the LNP-TRIGGER=Y, the donor switch performs a query. The query does not return a RN to the donor switch, indicating that the subscriber is not yet ported out.
Page 139
*** If RN found, assume other switch, send REL cause 14 IAM CdPN: NOA=8, 4003 7034841000 After CRD sync, operator should change: dn2subscriber STATUS=PORTED-OUT dn2subscriber LNP-TRIGGER=N Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Routing Types Query RN=4003 DN 703 484 1000...
Operators can choose different options among ACQ, ODBR, QoR, or a combination of these. Countries starting with only ODBR or QoR may eventually transition to ACQ as more numbers become ported. Therefore, during the transition, a given network or switch may be a combination of ACQ plus QoR or ACQ plus ODBR.
RN and DN may be the same. The NOA is used to distinguish a DN from a concatenated RN + DN combination. A new capability, NOA routing, is added to the Cisco BTS 10200 Softswitch for LNP in order to associate different dial plans for DN routing and RN routing.
Local Number Portability Query Returns Routing Number for Ported Directory Number When the Cisco BTS 10200 Softswitch performs an LNP query and finds an RN for a ported number that is not in this switch, the call is routed onward. The dial-plan-profile associated with the originating subscriber or trunk has NOA-ROUTING=Y, and the NOA Route Profile ID of the NOA Route that contains a destination ID.
Page 143
If PIC3 is not provisioned then use SUBSCRIBER.PIC1 to route the call. If neither PIC1 nor PIC3 is provisioned then route the call to POP.LECOSS. Filter: CARRIER: INTL Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Routing Types 2-27...
Enhanced preferred routing affects the entire system for CALL TYPE INTL_WZ1 routing. All Note subscriber originated CALL TYPE INTL_WZ1 calls use preferred carrier routing. In another words, the BTS 10200 does not allow one subscriber to use PIC1 while other subscribers use PIC3 for CALL TYPE INTL_WZ1 calls. Call Types This section provides detailed information on the Cisco BTS 10200 Softswitch call types.
Step 3 Check the subscriber table to determine if a PIC is defined. If a PIC is defined, the Cisco BTS 10200 Softswitch will select the call route and route the call based on the PIC information. If a PIC is not defined, proceed to Step 4.
Step 2 Step 3. If a 101XXXX number has not been dialed, proceed to Step 4. Check the carrier table for a carrier access code (CAC). If a CAC is available, the Cisco BTS 10200 Step 3 Softswitch will select the call route and route the call based on the CAC. If a CAC is not available, proceed to Step 3a.
Page 147
(ITP) Check No PIC Subscriber table for PIC2 PIC2 Specified Check Carrier table (Intra) Route based on PIC2 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Call Types Check POP table (PIC2 required) Block call Dial plan routing 2-31...
Step 2 Step 3. If a 101XXXX number has not been dialed proceed to Step 5. Check the carrier table for a CAC. If a CAC is available, the Cisco BTS 10200 Softswitch will select the Step 3 call route and route the call based on the CAC. If a CAC is not available, proceed to Step 4.
Step 2 a 101XXXX number was not dialed, proceed to Step 5. Check the carrier table for a CAC. If a CAC is available, the Cisco BTS 10200 Softswitch will select the Step 3 call route and route the call based on the CAC. If a CAC is not available, proceed to Step 4.
Page 150
Route to Carrier table annoucement (op-services) Route based Route based on PIC2 on CAC Route through LECOSS Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-34 Check POP table (ITP) Check No PIC Subscriber table for PIC2 PIC2 Specified...
Step 6 will perform an LNP query and port out the call. If the LNP trigger flag is not set, the Cisco BTS 10200 Softswitch will check the status field to determine if a LNP trigger has been assigned and will port out the call or terminate the call to the subscriber.
“translated-dn”. In this case, a new translation on the translated-dn occurs, and the new Destination call-type is used subsequently during the call. This is necessary to prevent problems related to a possible > NXX (800 toll-free) translation. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-36 office code...
Routing Policy Based Flexible Routing The Cisco BTS 10200 Softswitch policy based flexible routing use policy based routing tree decisions to select the call route and to route the call. Flexible routing allows service providers to provision policy based flexible routing by configuring the route guide table using the policy variables. Please note that the order of the policies is provisionable and one or more policies may be assigned.
The Policy Day of Year, Day of Week, and Time of Day enables the flexible routing of calls via the Cisco BTS 10200 Softswitch by day of year (DOY), day of week (DOW), time of day (TOD). Table Name: POLICY_TOD...
Page 157
Valid for Command (is): audit, sync, show Valid for Command (was): add, change, audit, sync, show Possible Value: ODR, PERCENT, PREFIX, OLI, POP, ROUTE, NXX, REGION Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-41...
Page 158
Policy Based Flexible Routing DISPLAY DOY1 DOY1_POLICY_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-42 Description: Specifies what token information to display on the screen. Valid only for the show command. VARCHAR(1024): 1-1024 (Default = all tokens are displayed). Permitted values are any valid token that can be shown for this command.
Page 159
Valid for Command: add, change, audit, sync, show Possible Value: [5_5] Parser: DateParser Description: See DOY1-POLICY-ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-43...
Page 160
DOY2_POLICY_ID DOY2_POLICY_TYPE Description: See DOY1-POLICY-TYPE. DOY3 DOY3_POLICY_ID DOY3_POLICY_TYPE Description: See DOY1-POLICY-TYPE. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-44 Description: See DOY1-POLICY-TYPE. VARCHAR(7): 1-7 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: ODR, TOD, PERCENT, PREFIX, OLI, POP, ROUTE, NXX,...
Page 161
Description: Month and day (day of year provisioning). CHAR(5): 5 characters in the format mm-dd. Valid for Command: add, change, audit, sync, show Possible Value: [5_5] Parser: DateParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-45...
Page 162
DOY6_POLICY_TYPE Description: See DOY1-POLICY-TYPE. DOY7 DOY7_POLICY_ID DOY7_POLICY_TYPE Description: See DOY1-POLICY-TYPE. DOY8 DOY8_POLICY_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-46 Description: See DOY1-POLICY-ID. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser VARCHAR(7): 1-7 ASCII characters.
Page 163
Description: Specifies the number of rows to display on the screen. Valid only for the show command. INTEGER: 1-100000000 (Default = 100000000). Valid for Command: show Default Value: 100000000 Possible Value: [1_100000000] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-47...
Page 164
Policy Based Flexible Routing MASTER ORDER PLATFORM_STATE POLICY_ID1 POLICY_ID10 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-48 Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Description: Specifies whether to display data on the screen in a sorted order.
Page 165
Description: ID of the Policy or Route table that matches the policy type. Indexes the ID to the type. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-49...
POLICY_ID8 POLICY_ID9 POLICY_TYPE1 POLICY_TYPE10 POLICY_TYPE2 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-50 Description: ID of the Policy or Route table that matches the policy type. Indexes the ID to the type. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show...
Page 167
Description: See POLICY-TYPE1. VARCHAR(7): 1-7 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: ODR, TOD, PERCENT, PREFIX, OLI, POP, ROUTE, NXX, REGION Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-51...
Page 168
POLICY_TYPE9 START_DOW1 START_DOW10 START_DOW2 START_DOW3 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-52 Description: See POLICY-TYPE1. VARCHAR(7): 1-7 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: ODR, TOD, PERCENT, PREFIX, OLI, POP, ROUTE, NXX,...
Page 169
Description: The time in hours and minutes (24-hour clock) that this policy starts (time of day provisioning). CHAR(5): HH:MM. Valid for Command: add, change, audit, sync, show Possible Value: [5_5] Parser: TimeParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-53...
Page 170
START_TIME2 START_TIME3 START_TIME4 START_TIME5 START_TIME6 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-54 Description: The time in hours and minutes (24-hour clock) that this policy starts (time of day provisioning). CHAR(5): HH:MM. Valid for Command: add, change, audit, sync, show...
STOP_DOW4 STOP_DOW5 STOP_DOW6 STOP_DOW7 STOP_DOW8 STOP_DOW9 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-56 Description: See STOP-DOW1. Valid for Command: add, change, audit, sync, show Possible Value: SUN, MON, TUE, WED, THU, FRI, SAT Parser: TextParser Description: See STOP-DOW1.
Page 173
Description: The time in hours and minutes (24-hour clock) that this policy ends (time of day provisioning). CHAR(5): HH:MM Valid for Command: add, change, audit, sync, show Possible Value: [5_5] Parser: TimeParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-57...
Page 174
STOP_TIME6 STOP_TIME7 STOP_TIME8 STOP_TIME9 TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-58 Description: The time in hours and minutes (24-hour clock) that this policy ends (time of day provisioning). CHAR(5): HH:MM Valid for Command: add, change, audit, sync, show...
Routing Policy Origin Dependent Routing The Policy Origin Dependent Routing enables the flexible routing of calls via the Cisco BTS 10200 Softswitch by the use of origin dependent routing (ODR). The numbering plan area (NPA) (or NPA-NXX) of the calling party number selects a route. If no match is found based on the calling party number, the route marked as default routes the call.
Syntax Description AUTO_REFRESH DIGIT_STRING DISPLAY LIMIT Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-60 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y). Y—Queries the database for the most current data.
Page 177
Description: ID of the Policy or Route table that matches the policy type. Indexes the ID to the type. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Mandatory: add Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-61...
Page 178
Policy Based Flexible Routing POLICY_TYPE START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-62 Description: Points to the next policy type table to use in the sequence. Policy routing continues until policy-type=route or policy-nxx is reached. All policy-types except route point to the Policy-$type table where $type = odr | tod | percent | prefix | oli | pop | nxx.
Routing Policy Originating Line Information The Policy Originating Line Information enables the flexible routing of calls via the Cisco BTS 10200 Softswitch by the use of originating line information (OLI). The Policy Originating Line Information performs routing based on the originating line information of the calling party number.
Page 180
Syntax Description AUTO_REFRESH DISPLAY LIMIT MASTER Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-64 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y). Y—Queries the database for the most current data.
Page 181
Description: ID of the Policy or Route table that matches the policy type. Indexes the ID to the type. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Mandatory: add Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-65...
Page 182
Policy Based Flexible Routing POLICY_TYPE START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-66 Description: Points to the next policy type table to use in the sequence. Policy routing continues until policy-type=route or policy-nxx is reached. All policy-types except route point to the Policy-$type table where $type = odr | tod | percent | prefix | oli | pop | nxx.
Routing Policy NXX The Policy NXX enables the flexible routing of calls via the Cisco BTS 10200 Softswitch when a number services call results in a translated number, carrier ID, translated number and a carrier ID, or a route ID.
Page 184
Syntax Description AUTO_REFRESH CARRIER DISPLAY LIMIT Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-68 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y). Y—Queries the database for the most current data.
Page 185
Description: Specifies to begin displaying data on the screen at a specific row. Valid only for the show command. INTEGER: 1-100000000 (Default = 1). Valid for Command: show Default Value: 1 Possible Value: [1_100000000] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-69...
TARGET TRANSLATED_DN Policy Percent The Policy Percent enables the flexible routing of calls via the Cisco BTS 10200 Softswitch based on percent allocation. This type of traffic distribution is used primarily for local 8XX routing and Tandem applications. Table Name: POLICY_PERCENT...
Page 187
Description: Defines the beginning percent range (beginning and ending percents) for the second destination. SMALLINT: 1-100. Valid for Command: add, change, audit, sync, show Possible Value: [1_100] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-71...
Page 188
Policy Based Flexible Routing BEGIN_RANGE3 BEGIN_RANGE4 BEGIN_RANGE5 DEFAULT_POLICY_ Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-72 Description: Defines the beginning percent range (beginning and ending percents) for the third destination. SMALLINT: 1-100. Valid for Command: add, change, audit, sync, show...
Page 189
Description: Defines the end of the percent range (beginning and ending percents) for the first destination. SMALLINT: 1-100. Valid for Command: add, change, audit, sync, show Mandatory: add Possible Value: [1_100] Parser: DecimalParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-73...
Page 190
END_RANGE2 END_RANGE3 END_RANGE4 END_RANGE5 LIMIT Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-74 Description: Defines the end of the percent range (beginning and ending percents) for the second destination. SMALLINT: 1-100. Valid for Command: add, change, audit, sync, show...
Page 191
Mandatory: add Possible Value: [1_16] Parser: TextParser Description: See policy-id1. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-75...
Page 192
Policy Based Flexible Routing POLICY_ID3 POLICY_ID4 POLICY_ID5 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-76 Description: See policy-id1. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser Description: See policy-id1.
Page 193
Description: See policy-type1. VARCHAR(7): 1-7 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: ODR, TOD, PERCENT, PREFIX, OLI, POP, ROUTE, NXX, REGION Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-77...
Page 194
Policy Based Flexible Routing POLICY_TYPE4 POLICY_TYPE5 START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-78 Description: See policy-type1. VARCHAR(7): 1-7 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: ODR, TOD, PERCENT, PREFIX, OLI, POP, ROUTE, NXX,...
Policy Point of Presence The Policy Point of Presence enables the flexible routing of calls via the Cisco BTS 10200 Softswitch based on the point of presence (POP). The POP based policy routing routes a call to the nearest trunk group when there are multiple trunk groups.
Page 196
Syntax Description AUTO_REFRESH DISPLAY LIMIT MASTER Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-80 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y). Y—Queries the database for the most current data.
Description: ID of the Policy or Route table that matches the policy type. Indexes the ID to the type. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Mandatory: add Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-81...
Policy Based Flexible Routing POLICY_TYPE POP_ID Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-82 Description: Points to the next policy type table to use in the sequence. Policy routing continues until policy-type=route or policy-nxx is reached. All policy-types except route point to the Policy-$type table where $type = odr | tod | percent | prefix | oli | pop | nxx.
TARGET Policy Prefix The Policy Prefix enables the flexible routing of calls via the Cisco BTS 10200 Softswitch based on prefix (type of call). Typical call types include 1+ dialing, international calls, toll-free, and so on. The Policy Prefix is used mainly for carrier routing.
For each POLICY_ID# if not null, add an entry into POLICY_PROFILE table. • Syntax Description AUTO_REFRESH DEFAULT_POLICY_ Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-84 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y).
Description: Primary key. Unique identifier for this policy-tod. Assigned by service provider. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, show, delete, audit, sync Mandatory: add, change, delete Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-85...
Page 202
LIMIT MASTER ORDER PLATFORM_STATE POLICY_ID1 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-86 Description: Specifies the number of rows to display on the screen. Valid only for the show command. INTEGER: 1-100000000 (Default = 100000000). Valid for Command: show...
Page 203
Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser Description: See policy-id1. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, audit, sync, show Possible Value: [1_16] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-87...
FSPTC (POTS/Tandem/Centrex Feature Server)—Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)—Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-93...
Syntax Description AUTO_REFRESH DIGIT_STRING DISPLAY Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-94 Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y).
Page 211
STANDBY—System is in standby mode. EMS—Audits the active EMS to the standby EMS. Valid for Command: sync, audit Default Value: ACTIVE Possible Value: ACTIVE, STANDBY Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-95...
TARGET Policy Region The Policy Region enables the flexible routing of calls via the Cisco BTS 10200 Softswitch based on the call region. The region is derived using the Region Profile table from the Route Guide table and the calling party number ANI. If ANI is not available or the Region Profile table is not provisioned, the region assigned to the trunk group is used for trunk origination.
Page 213
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-97...
Page 214
Policy Based Flexible Routing LIMIT MASTER ORDER PLATFORM_STATE Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-98 Description: Primary key. Unique identifier for this policy-tod. Assigned by service provider. VARCHAR(16): 1-16 ASCII characters. Valid for Command: add, change, show, delete, audit, sync...
Page 215
ROUTE—Go to Route table. TOD—Time-of-day routing. Valid for Command: add, change, audit, sync, show Mandatory: add Possible Value: TOD, PERCENT, PREFIX, OLI, POP, ROUTE, NXX, REGION Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Policy Based Flexible Routing 2-99...
Page 216
Policy Based Flexible Routing REGION START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 2-100 Description: Primary key. Region is derived from the Region Profile table based on the ANI. If the region cannot be derived from the region-profile, use the region assigned to the incoming trunk group.
Dial Plans and Routing Revised: December 9, 2008, OL-8001-10 Introduction This chapter provides detailed dial plan and routing information for the Cisco BTS 10200 Softswitch. The following subjects are discussed in this chapter: Originating Basic Call State Machine (CS2 Call Model) •...
Select route. The carrier-based information and routing address information is provided by the routing Step 9 server. Step 10 Authorize call setup. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x while reviewing the following detailed step-by-step explanation of the CS2+ call Chapter 3 Dial Plans and Routing OL-8001-10...
Page 219
OL-8001-10 Originating Basic Call State Machine (CS2 Call Model) t a n o e t Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Originating Basic Call State Machine (CS2 Call Model) n i l c i l x i f...
Chapter 3 Dial Plans and Routing Point of Presence Figure 3-3 provides an illustrated example of the Cisco BTS 10200 Softswitch ability to process and route calls between multiple points of presence (POPs). Figure 3-3 Dallas PSTN Carrier Operator OL-8001-10...
Chapter 3 Dial Plans and Routing Individual Individual is the Cisco BTS 10200 Softswitch default subscriber type. The individual subscriber type is assigned to individual subscribers. Centrex The Centrex (CTX) subscriber type is assigned to the main subscriber ID of a Centrex group.
Component Breakdown of Add Digit Map Command (Two-Digit Star Code) Description Casual dialing End of dialing or cut-through Vertical service code Maximum digit string (19 digits = 011+16 digits for international call) Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Digit Collection...
This section contains information related to the dialed digit analysis. The dialed digit analysis determines the destination and routing of the placed call. The following topics are discussed: • Destination Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 3-10 Chapter 3 Dial Plans and Routing...
Page 227
Chapter 3 Dial Plans and Routing Digit Analysis Local Serving Area • Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 3-11 OL-8001-10...
LSA area. If the dialed digits are found in the Lsa table, the call is converted to a local call. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 3-12...
Originating line information (OLI) restrictions for tandem calls • Account codes • Authorization codes • Routing This section provides information relating to the routing of calls by the Cisco BTS 10200 Softswitch. The following topics are discussed: • Office Code Ported Office Code • Route Guide •...
The Ported Office Code (ported-office-code) table specifies numbers, or ranges of numbers, that might have been ported-in to this switch. If a called number matches any of the ported numbers, or is within any of the specified ranges of numbers, the Call Agent queries the DN2subscriber table to determine the current status of the DN.
The ISDN Trunk Group Profile (isdn-tg-profile) table holds common information regarding an ISDN trunk group. This table is used to configure the Cisco BTS 10200 Softswitch to interact with various types of private branch exchanges (PBXs) having different configurations (such as non-facility associated signaling (NFAS), facility associated signaling (FAS), and so forth), initialization procedures (service or restart), or supporting different call control or maintenance timer values.
Figure 3-5 shows an illustrated example of generic address parameter (GAP) based routing. Figure 3-5 Toll network Local network Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 3-16 Generic Address Parameter Based Routing LNP query Direct route Recipent Donor...
The ANI Screening Profile (ani-screening-profile) table defines an id to perform ANI screening. The ID is assigned to a trunk group when ANI screening is required or when ANI-based routing is required for calls originating over a trunk group. OL-8001-10 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Tandem Provisioning 3-17...
When used for an incoming interface, the table maps normalized cause codes to a cause code sent over the incoming interface. If no entry is found in the table, the Cisco BTS 10200 Softswitch uses the cause code as is.
(ARQ), the gatekeeper uses the default technical prefixes. A group of one or more of technical prefixes can be provisioned in Cisco BTS 10200 Softswitch and this group can be associated to an H.323 gateway. The Cisco BTS 10200 Softswitch H.323 gateway process instance registers the technical prefixes from its technical prefix group with its primary gatekeeper.
These calls are prefixed with the 1+8XX service access codes. The seven digits following the 8XX codes are used for routing the call. For an inbound/outbound 8XX call, the Cisco BTS 10200 Softswitch checks the local toll-free database first. If the corresponding DN is not found in the local toll-free database, the system sends a query to the service control point (SCP) to request the corresponding DN.
When a translated number (for an original 8XX call) is received, the Analyzed Info Dial Plan (DP) triggers the FS. The Cisco BTS 10200 Softswitch looks up the DNIS and TG information for the call. The DNIS information is then outpulsed to the PBX. If an overflow condition is encountered, the call is routed to the overflow trunk.
ANI. If ANI is not available or the Region Profile table is not provisioned, the region assigned to the trunk group is used for trunk origination. If a record cannot be found based on the region, the record with region=default (if provisioned) is used for routing. Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 3-22 Chapter 3...
Call Agent. Carrier Based Routing Carrier based routing enables the routing of Cisco BTS 10200 Softswitch calls based on carrier. Carrier based routing provides multiple service provider support. Additionally, carrier based routing enables matching of the carrier ID and the trunk group to individual service providers. Individual dial plans can be configured for each service provider or default routing can be enabled.
Revised: December 9, 2008, OL-8001-10 Introduction This chapter provides a basic understanding of how the Cisco BTS 10200 Softswitch Command Line Interface (CLI) functions with of the routing types and call types. This chapter is divided into the following sections: •...
Subscriber Test1 Step 7 If the call type is toll free, 900, or 500, the Cisco BTS 10200 Softswitch will use the dial plan to select the call route and to route the call. If the call type is casual, the Cisco BTS 10200 Softswitch will use the carrier routing information to Step 8 select the call route and to route the call.
Basic Subscriber Routing Go to Dial-plan (based on DP-ID) Dial-Plan dp50 CASUAL 101XXX Carrier_Routing NOT FOUND Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Routing Types Go to Destination table (get call type and destination) PIC (1:3) Subscriber Test1...
10. If the call type is TG SP, proceed to Step 11. Example: Destination If the call type is toll free, 900, or 500, the Cisco BTS 10200 Softswitch will use the dial plan to select Step 6 the call route and to route the call.
Page 245
If the carrier routing is not found, the Cisco BTS 10200 Softswitch will user the dial plan to select the call route and to route the call. If the call type is TG SP, the Cisco BTS 10200 Softswitch will the SP routing to select the call route and Step 11 to route the call.
Page 246
TOLLFREE (destination) DP_Routing (TG->DP) (dial-plan) Select route (DN2sub) NOT FOUND Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Go to Destination Go to dial-plan and get table and get destination based on calltype and route digits and dp-id (destination)
Example: Carrier Use Dial-Plan “Y” Carrier 9999 Use Dial-Plan “N” If a carrier dial plan is configured, the Cisco BTS 10200 Softswitch will use the carrier dial plan to select Step 7 the call route and to route the call.
Page 248
Example: Carrier All = N Step 10 If the RTM_CP_CARRIER_2_LECOSS is not available, the Cisco BTS 10200 Softswitch will use the carrier guide index to select the call route and to route the call. Example: Carrier All = Y...
Example: Destination Carrier Determine the call type. If the call type is toll free, 900, or 500, the Cisco BTS 10200 Softswitch will Step 8 select the call route and to route the call using the destination carrier routing. If the call type is not toll free, 900, or 500, the Cisco BTS 10200 Softswitch will return an error and will drop the call.
Page 250
ROUTED (destination route) DESTINATION (destination RID) DESTINATION CARRIER (destination carrier) Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 4-10 Basic Dial Plan Routing If (dp1->idp) default_idp = dp1->idp INTL DIAL PLAN else default-idp = ca_config->idp Return NOT_FOUND Return SUB Return DEST->route_guide_idx...
BTS 10200 Softswitch will select the call route and route the call based on the carrier access code (CAC). If a 101XXXX number has not been dialed, proceed to Step 3. Check the subscriber table to determine if a PIC is defined. If a PIC is defined, the Cisco BTS 10200 Step 3 Softswitch will select the call route and route the call based on the PIC information.
Page 252
Step 5 If a LECOSS is defined in the POP table, the Cisco BTS 10200 Softswitch will select route the call via the LECOSS. If a LECOSS is not defined in the POP table, the Cisco BTS 10200 Softswitch will block the call.
Step 2 Step 3. If a 101XXXX number has not been dialed, proceed to Step 4. Check the carrier table for a CAC. If a CAC is available, the Cisco BTS 10200 Softswitch will select the Step 3 call route and route the call based on the CAC. If a CAC is not available, proceed to Step 3a.
Page 254
Determine if a LECOSS is defined in the POP table. If a LECOSS is defined in the POP table, the Cisco BTS 10200 Softswitch will select the call route and route the call via the LECOSS. If a LECOSS is not defined in the POP table, the Cisco BTS 10200 Softswitch will block the call.
Step 2 Step 3. If a 101XXXX number has not been dialed proceed to Step 5. Check the carrier table for a CAC. If a CAC is available, the Cisco BTS 10200 Softswitch will select the Step 3 call route and route the call based on the CAC. If a CAC is not available, proceed to Step 4.
Step 3 Check the carrier table for a CAC. If a CAC is available, the Cisco BTS 10200 Softswitch will select the call route and route the call based on the CAC. If a CAC is not available, proceed to Step 4.
Page 257
Cisco BTS 10200 Softswitch will route the call to the announcement server. Additionally, if a PIC is not specified in the subscriber table, the Cisco BTS 10200 Softswitch will check the POP table for a specified PIC. If a PIC is specified in the POP table, the Cisco BTS 10200 Softswitch will block the call.
LECOSS Ported-In Call Processing This section provides a detailed description of the Cisco BTS 10200 Softswitch routing and call flow for ported-in call processing calls and provides CLI example references. Refer to representation of the ported-in call processing call routing flow while reviewing the following detailed step-by-step ported-in call processing call routing flow.
Page 259
Determine if the LNP trigger flag is set. If the LNP trigger flag is set, the Cisco BTS 10200 Softswitch will perform an LNP query and port out the call. If the LNP trigger flag is not set, the Cisco BTS 10200 Softswitch will check the status field to determine if a LNP trigger has been assigned and will port out the call or terminate the call to the subscriber.
Page 260
Destination table (LNP Local Sub LNP Route) Subscriber Route terminator Play announcement and release the call Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 4-20 office code in Ported Office Code table (Ported-Office- Code in CA) Is the in-call-agent flag set?
POP ITP = Y • POP LEC-OSS • Ported-Office-Code in CA • Ported-Office-Code in CA = N • Service Provider • • Sub DP Dest Interlata OL-8001-10 Command Line Interface Routing Examples Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x 4-21...
• Creating a Dial Plan The Cisco BTS 10200 Softswitch can use two servers, an active and a standby, for maximum reliability. Note The dial plans discussed in this chapter apply to both the active and standby server. You need only create one dial plan and deploy that dial plan on both the active and standby server.
Set up the Cisco BTS 10200 Softswitch and install all required software. Step 2 Before you start the dial planning process, you should prepare the Cisco BTS 10200 Softswitch as described in the following manuals: Site Preparation and Network Communications Requirements •...
Extensible Provisioning and Operations Manager (EPOM) • You can use both the CLI and EPOM to provision the dial plan for a Cisco BTS 10200 Softswitch. Command Line Interface The Command Line Interface can be used to provision and deploy dial plans for the Cisco BTS 10200 Softswitch.
Creating a Dial Plan Extensible Provisioning and Operations Manager The EPOM visual interface can be used to provision and deploy dial plans for the Cisco BTS 10200 Softswitch. • For detailed instructions on using the CLI, refer to the Cisco Extensible Provisioning and Operations Manager Getting Started Guide.
Generate a DN2Subscriber. Control a media gateway. Equip a subscriber termination Control a subscriber termination. For additional Cisco BTS 10200 Softswitch provisioning information, refer to the Cisco BTS 10200 Softswitch Provisioning Guide. OL-8001-10 Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Page 288
Chapter 5 Preparing for Dial Plan Provisioning Creating a Dial Plan Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x OL-8001-10...
Provisioning a Dial Plan with the Command Line Interface This section provides the detailed instructions for managing dial plans in the Cisco BTS 10200 Softswitch configuration using the CLI. The CLI also allows you to perform show, add, change, and delete dial plans.
Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x “Dial Plan Profile” section on page “International Dial Plan” section on page 1-42.
Page 291
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Page 292
Provisioning a Dial Plan with the Command Line Interface FNAME LIMIT MASTER Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Description: Primary key. Foreign key: Feature table. Type of screening feature. VARCHAR(16): 1-16 ASCII characters. Permitted values are: SCR--Selective call rejection...
Page 293
CA--Network identifier of a Call Agent. FSPTC (POTS/Tandem/Centrex Feature Server)--Network identifier of a specific Feature Server. FSAIN (AIN Feature Server)--Network identifier of AIN Feature Servers. Valid for Command: sync Mandatory: sync Possible Value: [1_10] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Delete Rules: ID does not exist in any custom-dial-plan::id Syntax Description AUTO_REFRESH DESCRIPTION Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Description: Specifies whether to display cached data on the screen. Valid only for the show command. CHAR(1): Y/N (Default = Y).
Page 295
Multiple tokens can be entered by separating with a comma. Valid for Command: show Possible Value: [1_1024] Parser: TextParser Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Page 296
PLATFORM_STATE START_ROW TARGET Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x Description: State of an active or standby system shared memory database; use to audit an active or standby system shared memory database. Valid for the audit database and audit table name commands.
Provisioning a Dial Plan with the Extensible Provisioning and Operations Manager This section provides the detailed instructions for adding a dial plan to the Cisco BTS 10200 Softswitch configuration using the Extensible Provisioning and Operations Manager (EPOM). Additionally, detailed instructions are provided for using EPOM to manage configured dial plans. The EPOM also allows you to perform add, delete, and edit commands on multiple dial plans with a single operation.
Page 298
Provisioning a Dial Plan with the Extensible Provisioning and Operations Manager The Cisco BTS 10200 Softswitch Component window opens showing a list of dial plans. If this is the first dial plan (or device of this type) that you are adding, the list is empty.
Chapter 6 Provisioning Dial Plans You return to the Cisco BTS 10200 Softswitch Component window. The new dial plan is added to the list. To edit a single component, see the Configuration” section on page the Cisco BTS 10200 Softswitch Configuration” section on page Applying an EPOM Template to a Selected Dial Plan In a Domain view, select the desired domain >...
When you click Apply, the component is added, but you remain in the Add component window for • further operations. The new dial plan is added to the list when you return to the Cisco BTS 10200 Softswitch Component view.
Page 301
Click OK to save changes. EPOM will send only the checked elements along with the mandatory fields to Cisco BTS 10200 Softswitch, instead of sending whole edit page elements. This will update the Cisco BTS 10200 Softswitch Server with the new values along with the mandatory attributes.
Edit. The browser displays multiple templates. Click OK. Step 7 You return to the Cisco BTS 10200 Softswitch Component window. The edited dial plan appears in the list. To add a single component, see the Configuration”...
To add a single component, see the Configuration” section on page BTS 10200 Softswitch Configuration” section on page Adding Multiple Dial Plans to a Cisco BTS 10200 Softswitch Configuration In the ems-server window left pane, click a component. Step 1 The Component: name window appears.
When you click Apply, the component is added, but you remain in the Add component window for • further operations. You have now added multiple dial plans to the Cisco BTS 10200 Softswitch EMS network. Editing Multiple Dial Plans in the Cisco BTS 10200 Softswitch Configuration In the ems-server window left pane, click a component.
Page 305
Click OK. Step 4 You have now deleted multiple dial plans in the Cisco BTS 10200 Softswitch EMS network. OL-8001-10 Provisioning a Dial Plan with the Extensible Provisioning and Operations Manager Cisco BTS 10200 Softswitch Dial Plan Guide, Release 4.5.x...
Page 306
