  • Page 1 Tosaerba a batteria ISTRUZIONI PER L’USO Accugrasmaaier GEBRUIKSAANWIJZING MANUAL DE Cortadora de Cesped INSTRUCCIONES Cortadora de Grama a Bateria MANUAL DE INSTRUÇÕES Akku-plæneklipper BRUGSANVISNING Μηχανή γκαζόν με μπαταρία ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ Akülü Çim Biçme Makinasi KULLANMA KILAVUZU DLM480 DLM481 DLM538 DLM539...
  • Page 2 Fig.3 Fig.1 Fig.4 Fig.2 Fig.5...
  • Page 3 Fig.6 Fig.10 Fig.7 Fig.11 Fig.8 Fig.9 Fig.12...
  • Page 4 Fig.13 Fig.17 Fig.18 Fig.14 Fig.19 Fig.15 Fig.16 Fig.20...
  • Page 5 Fig.21 Fig.25 Fig.22 Fig.26 Fig.23 Fig.27 Fig.28 Fig.24...
  • Page 6 Fig.32 Fig.29 Fig.33 Fig.30 Fig.34 Fig.31 Fig.35...
  • Page 7 Fig.36 Fig.40 Fig.37 Fig.41 Fig.38 Fig.39...
  • Page 8 Fig.44 Fig.42 Fig.45 Fig.46 Fig.43 Fig.47...
  • Page 9 Fig.48...

  • Page 10: Specifications

    ENGLISH (Original instructions) SPECIFICATIONS Model: DLM480 DLM481 DLM538 DLM539 Mowing width (blade diameter) 480 mm 534 mm No load speed 3,100 min 3,000 min Part number of replacement Straight mower blade 191V97-3 191V96-5 / 191W87-2 mower blade Mulching blade 191Y64-6...

  • Page 11: Intended Use

    EN60335-2-77: declared value(s) depending on the ways in which Model DLM480 the tool is used especially what kind of workpiece Sound pressure level (L ) : 84 dB(A) is processed.

  • Page 12: Important Safety Instructions

    Save all warnings and instruc- Before using the lawnmower, always visually inspect to see that the blade and the blade tions for future reference. assembly are not worn or damaged. Worn or damaged parts increase the risk of injury. Training Check the grass catcher frequently for wear or Read the instructions carefully.
  • Page 13 Remove foreign matters such as rocks, wire, 14. Do not put hands or feet near or under rotating bottles, bones and large sticks from the work parts. Keep clear of the discharge opening at area before mowing to prevent personal injury all times.
  • Page 14 Maintenance and storage Follow all charging instructions and do not charge the battery pack or tool outside the Replace worn or damaged parts for safety. temperature range specified in the instruc- Use only genuine replacement parts and tions. Charging improperly or at temperatures accessories.

  • Page 15: Installing The Handle

    It will Avoid storing battery cartridge in a con- also void the Makita warranty for the Makita tool and tainer with other metal objects such as charger. nails, coins, etc.

  • Page 16: Removing The Mulching Plug

    4. Upper handle into the holes on the machine. ► Fig.14: 1. Mulching plug 2. Protrusion For DLM480/DLM538 ► Fig.2: 1. Bolt 2. Thumb nut 3. Lower handle 4. Upper handle FUNCTIONAL DESCRIPTION Turn the knob 90°...

  • Page 17: Overload Protection

    To turn on the machine, press the main power switch. If no improvement can be found by restoring protection The main power lamp lights up in green. To turn off the system, then contact your local Makita Service Center. machine, press the main power switch again. NOTICE:...

  • Page 18: Adjusting The Mowing Height

    100 mm or switch, stop the operation immediately and have them Hold the lower handle with one hand, and then move checked by your nearest Makita Authorized Service Center. the mowing height adjusting lever with the other hand. For DLM481/DLM539 ►...

  • Page 19: Electronic Function

    Release the switch lever and drive lever (for DLM481/ DLM539), or release the switch lever (for DLM480/DLM538). CAUTION: If the cut grass or foreign object blocks up inside of the mower body, be sure to Remove the lock key.

  • Page 20: Maintenance

    To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should Turn the knob on both sides 90°. Make sure that be performed by Makita Authorized or Factory Service the knobs are securely fixed. Centers, always using Makita replacement parts.

  • Page 21: Troubleshooting

    Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to disassemble the machine. Instead, ask Makita Authorized Service Centers, always using Makita replacement parts for repairs.
