INSTRUCTION MANUAL
Cordless Backpack Vacuum
Cleaner
DVC265
Read before use.

Advertisement

Table of Contents
loading

Related Manuals for Makita DVC265

Summary of Contents for Makita DVC265

  • Page 1 INSTRUCTION MANUAL Cordless Backpack Vacuum Cleaner DVC265 Read before use.

  • Page 2: Specifications

    SPECIFICATIONS Model: DVC265 Capacity Filter bag 2.0 L Dust bag 1.5 L Maximum air volume 1.8 m /min Vacuum 110 hPa Dimensions (L x W x H) 230 mm x 152 mm x 373 mm (excluding the harness) Rated voltage D.C.

  • Page 3: Ec Declaration Of Conformity

    15. CHECK DAMAGED PARTS. Before further use EC Declaration of Conformity of the cleaner, a guard or other part that is damaged should be carefully checked to deter- For European countries only mine that it will operate properly and perform The EC declaration of conformity is included as Annex A its intended function.
  • Page 4 Follow instruction for lubricating and chang- also void the Makita warranty for the Makita tool and ing accessories. charger. Keep handles dry, clean and free from oil and grease.

  • Page 5: Functional Description

    CAUTION: Do not install the battery cartridge 26. Do not insert any devices other than Makita forcibly. If the cartridge does not slide in easily, it is wireless unit into the slot on the tool.

  • Page 6: Overheat Protection

    Overheat protection Switch box position When the tool is overheated, the tool stops automati- The switch box can be hooked on either side of the cally. Let the tool cool down before turning the tool on lower belt. Arrange the cord so that the switch box again.

  • Page 7: Stand-By Switch

    Shoulder belts Stand-by switch The stand-by switch is the switch to turn on/off the wireless activation function. The vacuum cleaner is in the stand-by state regardless of the switch position and it runs when button is pushed. ► 1 . Strap 2. Fastener Upper belt ► 1 .

  • Page 8: Connecting The Tool

    Hose band Connecting the tool Hose band can be used for holding the hose or free If the bent pipe assembly is attached to the hose, nozzle. loosen the sleeve of bent pipe assembly and remove it. To secure the hose to the vacuum cleaner body, pass the hose band through the slot on the body.
  • Page 9 Follow the procedures below, depending on the Using as a cleaner type of the extension wand : NOTE: The slide-type extension wand and the ring- If you want to use this product as a cleaner, follow the type extension wand are not compatible with each below procedures.
  • Page 10 Hose hook For the ring-type extension wand Shoulder the vacuum cleaner body then twist and insert When you suspend the operation, the hook on the bent the extension wand into the bent pipe assembly. To pipe assembly can be used for hanging the wand on the disconnect, twist and extract it.

  • Page 11: Operation

    Insert the filter bag into the slit on the upper side of Align the hole of the filter bag with the hose cuff the room as illustrated. and push the cardboard portion to the end. Make sure that the rubber ring on the filter bag goes over the rim on the hose cuff. ► 1 . Rubber ring on the filter bag 2. Rim on the hose cuff 3. Cardboard portion of the filter bag 4. Hose cuff ► 1 . Slit 2. Filter bag When using the dust bag, insert the brim of the dust bag OPERATION into the slit.
  • Page 12 Shoulder the vacuum cleaner body and fas- Replace the filter bag when it becomes full. Open ten lower and upper belts. Adjust the tightness as the lid and take out the filter bag. Pull the strip on the necessary. side of the opening to shut the filter bag and dispose of the filter bag in whole. ► 1 . Strip Press button to start vacuuming. To change When using a dust bag, take out the dust bag and dis- the suction power, press button while the vacuum pose of the dust by releasing the latch.
  • Page 13 WIRELESS ACTIVATION NOTE: Wireless activation needs Makita tools equipped with the wireless unit. FUNCTION NOTE: Prior to the initial use of the wireless activa- tion function with each tool, the tool registration is required. Once the registration is finished with the What you can do with the wireless...
  • Page 14 Tool registration for the cleaner the lid. When inserting the wireless unit, align the projections NOTE: A Makita tool supporting the wireless activa- with the recessed portions on the slot. tion function is required for the tool registration. NOTE: Finish installing the wireless unit to the tool before starting the tool registration.
  • Page 15 If the cleaner and the tool are linked successfully, the Push the wireless activation button on the tool wireless activation lamps will light up in green for 2 briefly. The wireless activation lamp will blink in blue. seconds and start blinking in blue. NOTE: The wireless activation lamps finish blinking in green after 20 seconds elapsed. Press the wireless activation button on the tool while the wireless acti- vation lamp on the cleaner is blinking.
  • Page 16 Set the stand-by switch on the cleaner to " I (ON)". Erasing all tool registrations You can erase all tool registrations from the cleaner as follows. ► 1 . Stand-by switch Press the wireless activation button on the cleaner for 6 seconds. The wireless activation lamp blinks in green and then become red.
  • Page 17 Description of the wireless activation lamp status ► 1 . Wireless activation button 2. Wireless activation lamp The wireless activation lamp shows the status of the wireless activation function. Refer to the below table for the meaning of the lamp status. Status Wireless activation lamp Description...
  • Page 18 Troubleshooting for wireless activation function Before asking for repairs, conduct your own inspection first. If you find a problem that is not explained in the manual, do not attempt to dismantle the tool. Instead, ask Makita Authorized Service Centers, always using Makita replace- ment parts for repairs. State of abnormality Probable cause (malfunction) Remedy The wireless activation lamp does The wireless unit is not installed into the Install the wireless unit correctly.

  • Page 19: Maintenance

    Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. Cleaning the HEPA filter CAUTION:...

  • Page 20: Cleaning The Dust Bag

    These accessories or attachments Wash lightly by hand and rinse well with water. Dry are recommended for use with your Makita tool spec- completely before installing to the vacuum cleaner. ified in this manual. The use of any other accessories or attachments might present a risk of injury to persons.
