- Page 1 INSTRUCTION MANUAL Cordless Stapler ST113D Read before use.
- Page 2 SPECIFICATIONS Model: ST113D Staple width 10 mm Applicable staples length 7 mm - 10 mm Staple magazine capacity 150 pcs Dimensions without hook (L x W x H) 211 mm x 81 mm x 159 mm Rated voltage D.C. 10.8 V - 12 V max...
- Page 3 Prevent unintentional starting. Ensure the When battery pack is not in use, keep it away switch is in the off-position before connecting from other metal objects, like paper clips, to power source and/or battery pack, picking coins, keys, nails, screws or other small metal up or carrying the tool.
- Page 4 SAVE THESE INSTRUCTIONS. also void the Makita warranty for the Makita tool and WARNING: DO NOT let comfort or familiarity charger. with product (gained from repeated use) replace...
- Page 5 Indicating the remaining battery capacity Only for battery cartridges with the indicator 1. Red indicator 2. Button 3. Battery cartridge while sliding the button on the front of the cartridge. battery cartridge with the groove in the housing and slip 1.
- Page 6 NOTE: the lamp. Be careful not to scratch the lens of lamp, or it may lower the illumination. ASSEMBLY CAUTION: Always make sure that the battery cartridge is removed before carrying out any work on the stapler. Staples 2. Switch trigger CAUTION: Do not use staples other than designated in this manual or staples that appear...
- Page 7 Load staples into the main magazine with their OPERATION feet facing up. Testing the safety system WARNING: Make sure all safety systems are in working order before operation. Failure to do so may cause personal injuries. 1. Staples 2. Main magazine After loading staples, push back the sub-maga- zine in place until it clicks.
- Page 8 You can operate the tool in either way of “single Single sequential actuation: WARNING: When loading staples, always make sure that the battery cartridge is removed tial operation. from the stapler. Hold both of the front part and the rear part of the When the number of remaining staples in the magazine becomes 5 - 8 pieces, the switch trigger can no longer be pulled.
- Page 9 NOTICE: Never use gasoline, benzine, thinner, alcohol or the like. Discoloration, deformation or cracks may result. be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. OPTIONAL ACCESSORIES CAUTION: These accessories or attachments...
- Page 12 M ak i t a C or por at i on 3- 11- 8, S um i y os hi - c ho, A njo, Aichi 446-8502 Japan 885534-925 20160809 www.makita.com...
