WM821-M MiniPCI Module
To connect to a Cisco AP through the RADIUS server, select CCX EAP/LEAP. WEP is the Encryption Method, and the key is gener-
ated automatically.
Figure 23: Security Tab-CCX EAP/LEAP Authentication
If Allow Fast Roaming (CCKM) is selected, Fast Roaming (Cisco Centralized Key Management (CCKM)) is enabled.
Clicking the CCX Configuration button displays the CCX LEAP RADIUS Configuration window. Enter all the required information.
Figure 24: CCX EAP/LEAP RADIUS Configuration Window
Field
Login Name
Password
Domain
Click OK to set the configuration.
3.2.2.3 Encryption Methods
The following encryption methods are available, depending on the authentication mode:
•
.
Security Off
•
.
WEP
16
Table 8: CCX EAP/LEAP RADIUS Configuration Window Description
Description
Login name to the RADIUS server
Password to login to the RADIUS server
Domain name for login to the RADIUS server (optional)
—Using the Wireless Utility
