Draytek Vigor2820 Series User Manual page 169

SIP Port
Domain/Realm
Proxy
Act as Outbound Proxy
Display Name
Account Number/Name
Authentication ID
Password
Expiry Time
NAT Traversal Support
Ring Port
Vigor2820 Series User's Guide
Call without Registration. Choosing Auto is recommended.
The system will select a proper way for your VoIP call.
Set the port number for sending/receiving SIP message for
building a session. The default value is 5060. Your peer must
set the same value in his/her Registrar.
Set the domain name or IP address of the SIP Registrar server.
Set domain name or IP address of SIP proxy server. By the
time you can type :port number after the domain name to
specify that port as the destination of data transmission (e.g.,
nat.draytel.org:5065)
Check this box to make the proxy acting as outbound proxy.
The caller-ID that you want to be displayed on your friend's
screen.
Enter your account name of SIP Address, e.g. every text
before @.
Check the box to invoke this function and enter the name or
number used for SIP Authorization with SIP Registrar. If this
setting value is the same as Account Name, it is not necessary
for you to check the box and set any value in this field.
The password provided to you when you registered with a SIP
service.
The time duration that your SIP Registrar server keeps your
registration record. Before the time expires, the router will
send another register request to SIP Registrar again.
If the router (e.g., broadband router) you use connects to
internet by other device, you have to set this function for your
necessity.
None – Disable this function.
Stun – Choose this option if there is Stun server provided for
your router.
Manual – Choose this option if you want to specify an
external IP address as the NAT transversal support.
Nortel – If the soft-switch that you use supports Nortel
solution, you can choose this option.
Set Phone, ISDN1-S0 or ISDN-TE as the default ring port for
this SIP account. If you choose Phone or ISDN1-S0, the
ISDN2-TE selection will be dimmed, vice versa. There are ten
161
