R911310379 / 02 | Rexroth IndraControl VCP 08

Interfaces

7 Interfaces
Electric Drives and Controls | Bosch Rexroth AG
Depending on the device variant, several interfaces are available:
Type Code
VCPxx.xxxx-xxx-NN-xx-xx
VCPxx.xxxx-xxx-DN-xx-xx
VCPxx.xxxx-xxx-PB-xx-xx
VCPxx.xxxx-xxx-SR-xx-xx

Fig. 7-1: Device Variants

7-1
Available Interfaces
- - X - - X
- - X X - X
- - X - X X
X X X - - X
