R911310379 / 02 | Rexroth IndraControl VCP 08

Display and Operating Components

6 Display and Operating Components
6.1

Display

6.1.1

Setting the Contrast

Electric Drives and Controls | Bosch Rexroth AG
Danger of intoxication!
If the display is damaged, avoid touching, swallowing or breathing in the
liquids or gases which may leak out.
Danger of corrosion!
If the display is damaged, avoid touching, swallowing or breathing in the
liquids or gases which may leak out.
The small operator terminal is equipped with a FSTN display.
To define the contrast setting, use the programming software to set up
the system variable LcdContrast in any screen.
To do so, follow the instructions listed in the programming software's
help topic "How do I specify the contrast setting for the operating de-
vice".
In the programming software, enter the following values as lower and
upper limits for the representation type.
System Vari- Lower Limit
able
LcdContrast

Fig. 6-1: Values for the representation type

If you do not configure the system variable LcdContrast, the default
setting is used when the device is initialized.
Adjust the contrast to the surrounding conditions at reached operating
temperature to be able to read the display optimally.
If you did set-up the system variable, you can set the contrast as fol-
lows. Open the screen where you set up the system variable and:
1. Press the data release key if the data release is not automatically ac-
tive.
2. Enter a new value for the contrast. To do so, use the keys 0 to 9 or
plus and minus.
3. Confirm with Enter.
4. Finally press the data release key.
Upper Limit
+ 1 + 31
6-1
Default Setting
+ 15
