Technical Data
4.4

Interfaces

Ethernet
X5 Ethernet
Serial Interfaces
Variable Baud Rates and Data Formats
X6 SER1 RS485
X6 SER1 RS232 / X6 SER2 RS232
Field Bus Interfaces
Variable Baud Rates and Data Formats
X6 PROFIBUS DP
USB
Corresponds to the "Universal Serial Bus Specification Rev. 2.0"
X9, X10 Host
4.5

Central Processing Unit and Memory

Central Processing Unit
Central Processing Unit
Clock Frequency
Other Features
Electric Drives and Controls | Bosch Rexroth AG
10/100 Base-T
In Accordance With DIN 66259-4
Transmission Length: 0 - 1200 m (up to 3937 feet),
Twisted Pair Wire, Shielded
Galvanically Isolated
In Accordance With DIN 66259 T1, CCITT V.28
Transmission Length: 0 - 15 m (up to 49.212 feet), Con-
ductors Layered in Strands, Shielded X6 SER1: Galvan-
ically Isolated
X6 SER2: Galvanically Not Isolated
Galvanically Isolated
Min.: 1.5 Mbit/s
Max.: 12 Mbit/s
Max. Output Current 100 mA per Output
RISC ARM9
200 MHz
Watchdog Timer, Real-Time Clock, Battery Monitoring
