R911310379 / 02 | Rexroth IndraControl VCP 08

Technical Data

4 Technical Data
4.1

Front Panel and Enclosure

Front Panel and Enclosure
Enclosure
Front Panel
Front Panel Cover
Seal
Mounting Cutout
Mounting Depth
Degrees of Protection
Total Weight
4.2

Keyboard

Keyboard
Type
Number of Keys
Key Area (Raised)
Actuator Travel
Actuating Force
Switching Cycles
Lifetime (Min.)
Display Elements
Electric Drives and Controls | Bosch Rexroth AG
Steel Sheet, Galvanized
Aluminum, anodized natural finish
205 mm x 155 mm x 5 mm (8.071" x 6.102" x 0.196") -
(H x W x D)
Polyester Foil
Circumferential Rubber Seal on the Rear
199 mm x 139 mm (7.835" x 5.472") - (H x W)
About 55 mm (2.165")
Front: IP65
Rear: IP20
About 800 g
Membrane Keyboard
39
11 mm (0.433") - (H x W)
0.3 mm (0.011")
3 N
Approx. 3 millions under the following conditions:
Pressing Element: Test Plunger (DIN 42115)
Pressing Force: 10 N
Pressing Frequency: 1 Hz
2 Million Switching Cycles
15 Status LEDs
4-1
