7.3.7 Restrictions on Judgement

Contents of Program Expressions
Up to 16 of contents and up to 102 of characters can be incorporated into Calculation 1.
Incorporatable
number
Item Up to 16
Character Up to 102
Incorporating a Judgement Result into Another Judgement Program
Judgments are output in the ascending order. Therefore, the incorporated output judgement must be the
lower number than the target judgement number.
Example:
Correct
JD01=GW01+GW02
JD02=JD01 * CA01
Wrong
JD01=JD02+CA01
JD02=GW01+GW02
In this case, the judgement result of JD02 referred by JD01 will
be the one of previous inspection.
Calculation Order
Calculations are performed in priority order as follows:
Higher (,)
/
*
#
Lower +
7.3.8 Error Messages Appears When You Set Judgement Output
When you set a judgement program expression (judgement program), the following messages may be
displayed. In any case, an error is included in the numeric expression. Recheck and correct it.
Message
E0061: Formula error
E0062: Calculation error
E0066: No setting error
164
Example of Count
Program Result of Count
/BW01 + CA01 4 = "/", "BW01", "+", "CA01"
/BW01 + CA01 10
Display timing Description
At registration Grammatical error
For example,
"JD01=CM01BW01
At copying If the numeric calculation No. to which is copied is lower than
from the the one quoted to the numeric calculation.
existing
For example,
calculation
Calculation expression which is to be copied:
expression
CA05 = JD03 + CM01
Calculation expression to which is to be copied: JD02
(Then, "JD02" becomes equal to "JD0303 + CM01", and the
quoted result of JD03 becomes the calculation results of the
previous inspection.)
At registration You attempted to incorporate an unspecified checker,
numeric calculation (CA), Judgement (JD) into the numeric
expression and register them.
