32

Using a manually assigned IP address

If you wish to set the IP address for your PC manually, use the
following settings:
IP address
Subnet mask
Default gateway

Checking the connection

The default IP address of the router module is 192.168.0.1. You
can use the Ping command to check the connection.
1. Open a command prompt on your PC and enter the following
command:
The router module responds and the Ping command displays the
following kind of message:
Response from 192.168.0.1: Bytes=32 Time=1ms TTL=64
2. If the response is missing or shows an error, check your
network settings using the following command:
This command displays the list of network cards installed in your
PC and the IP configuration.

Logging into the web server of the router module

To access the web server of the router module, enter the IP
address 192.168.0.1 in the address field of your web browser.
The router module displays the web server start page.
Commissioning and configuration
192.168.0.2
255.255.255.0
Not required
Ping 192.168.0.1<ENTER>
ipconfig / ALL<ENTER>
