G9742 Metal Cutting Bandsaw (Mfg. Since 11/06
Identification
l
B
C
i
figure 1. The.Model.G9742.
A. Blade.Tension.Knob
B. Blade.Guide.Knob
C. Blade.Guides
D. Pulley.Cover
E. Heavy.Duty.Motor
f.
Hydraulic.Cylinder.and.Feed.Rate.Dial
G. ON/OFF.Push-Button.Switch.Assembly
H. Table.Angle.Scale
I.
Cast.Iron.Stop
J.
Vise.Clamp.Handwheel
K. Gear.Box
L.
Blade.Tension.Gauge
