Stand Parts List - Grizzly G9742 Owner's Manual

REF PART # DESCRIPTION
9 P9742009 WHEEL
11 PB03 HEX BOLT 5/16-18 X 1
16 P9742016 MOTOR CABLE
17 P9742017 PIVOTING ROD
19 P9742019 WORK STOP
20 PSS17 SET SCREW 5/16-18 X 5/16
21 P9742021 STOCK STOP ROD 1/2 X 216
27 P9742027 HANDWHEEL HANDLE
28 P9742028 HANDWHEEL
44 P9742044 POWER CABLE
50 PB07 HEX BOLT 5/16-18 X 3/4
51 PW07 FLAT WASHER 5/16
54 P9742054 PIVOT
74 PK12M KEY 5 X 5 X 30
85 P9742085 MOTOR 1/2 HP
85-1 P9742085-1 MOTOR FAN COVER
85-2 P9742085-2 MOTOR FAN
85-3 P9742085-3 CAPACITOR COVER
85-4 P9742085-4 S. CAPACITOR 200MFD 125VAC
86 P9742086 MOTOR PULLEY
86-1 PSS17 SET SCREW 5/16-18 X 5/16
111 P9742110A PULLEY COVER ASSEMBLY
124 P9742124 SHIPPING BRACKET
125 PB09 HEX BOLT 5/16-18 X 1/2
126 PS04 PHLP HD SCR 1/4-20 X 1/2
194 P9742194 FENDER WASHER 1/4
196V2 P9742196V2 KNOB #8 X 3/4 V2.06.08
254 P9742254 SUPPORT ROD
255 PSS04 SET SCREW 1/4-20 X 5/16
256 PW08 FLAT WASHER #8
257 P9742257 HEX BOLT #8-32 X 1/2
258A P9742258A CYLINDER ASSEMBLY V2.06.06
259 P9742259 CYLINDER UPPER SUPPORT
261 PSS47 SET SCREW #8-32 X 5/16
262 PSB05 CAP SCREW 1/4-20 X 3/4
263 PLW02 LOCK WASHER 1/4
300 P9742300 BASE
301A P9742301A VISE BASE V2.01.08
-36-

Stand parts List

REF PART #
302A P9742302A
303A P9742303A
304 P9742304
305A P9742305A
306 P9742306
307A P9742307A
308 P9742308
309 PLW01
310 PSB30
311 PB07
312 PW07
313 PB12
314 PSS03
315 P9742315
316 PN06
318 PB27
319 PN08
321 P9742321
322 P9742322
323 P9742323
324 P9742324
325 PCB19
328 P9742328
329 PS06
330A P9742330A
330A-1 G8988
333 P0561096
334 P9742334
338 P9742338
359 P9742359
361A P9742361A
362 PB26M
363 PLW04
364 PN03M
366 P9742366
367 PW03M
368 PS14M
G9742 Metal Cutting Bandsaw (Mfg. Since 11/06
DESCRIPTION
VISE JAW BRACKET-FRONT V2.01.08
VICE JAW BRACKET-REAR V2.01.08
SWIVEL BASE UPPER
BRACKET W/NUT V2.01.08
ACME NUT
ACME SCREW V2.01.08
BUSHING
LOCK WASHER 5/16
CAP SCREW 5/16-18 X 1/2
HEX BOLT 5/16-18 X 3/4
FLAT WASHER 5/16
HEX BOLT 5/16-18 X 1-1/4
SET SCREW 1/4-20 X 3/8
POSITIONING RING
HEX NUT 1/2-12
HEX BOLT 1/2-13 X 2-1/2
HEX NUT 3/8-16
POSITION PIN
POSITION KNOB
BUSHING
HANDLE
CARRIAGE BOLT 3/8-16 X 1 3/4
SWITCH BASE
PHLP HD SCR #10-24 X 3/8
PADDLE SWITCH W/SWITCH BOX V2.11.06
PADDLE SWITCH V2.11.06
COTTER PIN 3 X 25
CHIP TRAY
SCALE
DELUXE STAND ASSEMBLY
WHEEL ROD 21" TO 22" V2.04.04
HEX BOLT M8-1.25 X 30
LOCK WASHER 3/8
HEX NUT M8-1.25
RUBBER FOOT 3/8-16 X 1"
FLAT WASHER 6MM
PHLP HD SCR M6-1 X 12
