Pulley.cover - Grizzly G9742 Owner's Manual

pulley Cover
When.opened,.the.pulley.cover.gives.you.access.
to.change.the.pulley.ratio.so.the.bandsaw.can.cut.
at.one.of.three.speeds.
E N T A N G L E M E N T
HAzARD!
install the pulley cover
before
Otherwise, severe injury
may occur.
To install the pulley cover:
1.. UNPLUG.THE.BANDSAW!
2.. Position. and. rotate. the. pulley. cover. into.
place.as.shown.in.figure 17.
3.. Install.the.two.
⁄ -20.x.
1
4
ers.that.secure.the.pulley.cover.
figure 17..Positioning.the.pulley.cover.
G9742 Metal Cutting Bandsaw (Mfg. Since 11/06
you MUST
operating!
⁄ ".hex.bolts.and.wash-
1
2
4.. Loosen. the. belt. tension. knob. enough. to.
install.the.belt.on.the.appropriate.pulley.that.
will. give. the. required. blade. speed.. Refer. to.
Blade Speed. on. page 19. for. blade. speed.
selections.
5.. Adjust.the.belt.tension.knob.(figure 18),.so.
the. belt. has. ⁄ ". deflection. when. pressed. in.
1
4
the.center,.and.close.the.cover.
figure 18..Belt.tension.knob.
Belt.Tension.
Knob
-17-
