Chip Tray & Cast
Iron Stop
The.chip.tray.directs.small.workpieces.into.a.buck-
et. when. the. cut. is. complete.. The. cast. iron. stop.
allows.you.to.repeat.cuts.at.the.same.length.
To install the chip tray and cast iron stop:
1.. Position.the.chip.tray.as.shown.in.figure 14.
if.you.choose.to.use.this.accessory.
figure 14..Chip.tray.installed.
2.. Insert.the.stop.rod.approximately.
saw.until.the.end.of.the.rod.is.just.flush.with.
the.inside.casting.surface.
3.. Using. the. 4mm. hex. wrench,. tighten. the. set.
screw.shown.in.figure 15.
Set.Screw
figure 15..Installing.stop.rod.
4.. Slide.the.cast.iron.stop.onto.the.stop.rod.
and.tighten.the.set.screw.
-16-
Chip.tray
⁄ ".into.the.
3
4
Set.Screw
Off Button Lever
After. you. have. removed. the. shipping. strap. and.
have.adjusted.the.headstock.stop.bolt,.you.must.
adjust. the. OFF. button. lever. stop. bolt,. so. the.
bandsaw.shuts.OFF.automatically.when.a.cut.is.
complete..
To set the Off button lever stop bolt:
1.. With. the. headstock. in. the. complete. down.
position,.loosen.the.12mm.stop.bolt.and.jam.
nut.(see.figure 16).
Stop.Bolt.and.
Jam.Nut
OFF.Button
figure 16..OFF.button.lever.and.stop.bolt.
2.. Push. down. on. the. OFF. button. lever. so. the.
button.is.completely.depressed.
3.. While.keeping.the.lever.depressed,.use.your.
fingertips.to.turn.the.stop.bolt.until.the.head.
touches.the.lever.
4.. Back.off.the.stop.bolt.
jam.nut.
G9742 Metal Cutting Bandsaw (Mfg. Since 11/06
⁄ .turn.and.tighten.the.
1
