Machine.data.sheet - Grizzly G9742 Owner's Manual

Customer service #: (570) 546-9663 · to order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9742 5" X 6" METAL-CUTTING BANDSAW W/
Product Dimensions:
Weight.............................................................................................................................................................. 150 lbs.
Width (side-to-side) x depth (front-to-back) x height............................................................... 39 x 23-3/8 x 54-3/4 in.
Footprint (length x Width)............................................................................................................... 26-1/2 x 20-1/2 in.
Shipping Dimensions:
type................................................................................................................................................... Wood slat Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 168 lbs.
length x Width x height....................................................................................................................... 41 x 18 x 22 in.
Must ship upright................................................................................................................................................... yes
Electrical:
power requirement............................................................................................. 110V or 220V, single-phase, 60 hz
prewired Voltage.................................................................................................................................................. 110V
Full-load Current rating...................................................................................................... 7a at 110V, 3.5a at 220V
Minimum Circuit size.......................................................................................................... 15a at 110V, 15a at 220V
switch...................................................................................................... sealed Button switch w/automatic shut-off
Cord length............................................................................................................................................................ 6 ft.
Cord gauge.................................................................................................................................................... 18 aWg
plug included.......................................................................................................................................................... yes
Motors:
Main
type................................................................................................................. tEFC Capacitor-start induction
horsepower............................................................................................................................................. 1/2 hp
phase............................................................................................................................................ single-phase
amps...................................................................................................................................................... 7a/3.5a
speed................................................................................................................................................ 1725 rpM
power transfer ............................................................................................................................... V-Belt drive
Bearings..................................................................................................... shielded & permanently lubricated
Main Specifications:
Operation Info
Blade speeds......................................................................................................................... 80, 120, 200 FpM
std. Blade length................................................................................................................................ 64-1/2 in.
Blade size range..................................................................................................................................... 1/2 in.
head swivel............................................................................................................................................ 45 deg.
The information contained herein is deemed accurate as of 1/31/2013 and represents our most recent product specifications.
Model G9742
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
G9742 Metal Cutting Bandsaw (Mfg. Since 11/06
Machine Data Sheet
MACHINE DATA
SWIVEL HEAD
SHEET
PAGE 1 OF 2
-3-
