ABB MEASUREMENT & ANALYTICS | TECHNICAL DESCRIPTION | TD/ZIDC/TZIDC-200/ NON-CONTACT_SENSOR-EN REV. A
TZIDC, TZIDC-200
Digital positioner
—
Introduction
TZIDC
TZIDC-200
Devices from HW rev.: 5.01 can be equipped with
the order option "Contactless position feedback".
The position feedback then takes place via a 360°
sensor without mechanical end stops.
This allows a wider operating range of up to 350°.
The operating range can then be at any point in
the sensor range.
If the device's installation situation is different
from the standard described in the operating
instructions, such as gear rack actuators, further
parameter settings will be required.
The parameter settings are described in this
Technical description.
Technical description for manual
configuration of the contactless
360° sensor.
Additional Information
Additional documentation on TZIDC, TZIDC-200 is
available for download free of charge at
www.abb.com/positioners.
Alternatively simply scan this code:
